– Push the retaining tab -1- with a flat-head screwdriver and pry up the Luggage Compartment Lamp - W3- -2-. – Disconnect the connector -3-. the following: engage on the opposite side. – Perform a function test. 1.20.2 Luggage Compartment Lamp - W3- , Removing and Installing, Wagon Removing Caution Risk of damaging the component surfaces. ♦ When positioning a prying tool, put commercially available adhesive tape over the component in the visible area. – Push the Luggage Compartment Lamp - W3- -1- in the direc‐ tion of the -arrow A- with a flat-head screwdriver. – Fold the Luggage Compartment Lamp - W3- in the direction of the -arrow B- out of the roof trim panel. – Release and disconnect the connector -3-. the following: engage on the opposite side. – Perform a function test. 1.21 Bulb for Luggage Compartment Lamp - W3- , Removing and Installing ⇒ “1.21.1 Bulb for Luggage Compartment Lamp W3 , Removing and Installing, Sedan”, page 249 and Installing, Wagon”, page 250 1.21.1 Bulb for Luggage Compartment Lamp - W3- , Removing and Installing, Sedan Removing ⇒ “1.20.1 Luggage Compartment Lamp W3 , Removing and . |
