Toyota Corolla (2019 year). Instruction - part 26





401

6-4. Other interior features

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

Press and hold the 2 outside but-
tons  for  10  seconds  until  the
HomeLink

®



indicator

light

changes  from  continuously  lit
orange to rapidly flashing green.

If you sell your vehicle, be sure to
erase  the  programs  stored  in  the
HomeLink

®

 memory.

■

Codes stored in the HomeLink

®

 memory

●

The  registered  codes  are  not  erased  even  if  the  battery  cable  is  discon-
nected.

●

If  learning  failed  when  registering  a  different  code  to  a  HomeLink

®

  button

that already has a code registered to it, the already registered code will not
be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the Home-
Link

®

.

■

Certification for the garage door opener

For the U.S.A.

FCC ID: NZLAECHL5
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence,  and  (2)  this  device  must  accept  any  interference  received,  including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

For Canada

NOTE:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.
REMARQUE:
Le  present  appareil  est  conforme  aux  CNR  d’Industrie  Canada  applicables
aux appareils radio exempts de licence. L’exploitation est autorisee aux deux
conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur  de  l’appareil  doit  accepter  tout  brouillage  radioelectrique  subi,
meme si le brouillage est susceptible d’en compromettre le fonctionnement.

Erasing the entire HomeLink

®

 memory (all three codes)

402

6-4. Other interior features

COROLLA_TMMMS_TMMC_U

■

When support is necessary
Visit on the web at www.homelink.com/toyota or call 1-800-355-3515.

WARNING

■

When programming a garage door or other remote control device
The  garage  door  or  other  device  may  operate,  so  ensure  people  and
objects are out of danger to prevent potential harm.

■

Conforming to federal safety standards
Do  not  use  the  HomeLink

®

  compatible  transceiver  with  any  garage  door

opener or device that lacks safety stop and reverse features as required by
federal safety standards. This includes any garage door that cannot detect
an interfering object. A door or device without these features increases the
risk of death or serious injury.

■

When operating or programming HomeLink

®

Never allow a child to operate or play with the HomeLink

®

 buttons.

403

6-4. Other interior features

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

To  turn  the  compass  on  or  off,
press  the  button  for  more  than  3
seconds.

Compass

: If equipped

The compass on the inside rear view mirror indicates the direc-
tion in which the vehicle is heading.

Operation

Displays and directions

Display

Direction

N

North

NE

Northeast

E

East

SE

Southeast

S

South

SW

Southwest

W

West

NW

Northwest

404

6-4. Other interior features

COROLLA_TMMMS_TMMC_U

The direction display deviates from the true direction determined by
the earth’s magnetic field. The amount of deviation varies according to
the geographic position of the vehicle.

If you cross over a map boundary shown in illustration, the compass will
deviate.
To obtain higher precision or perfect calibration, refer to the following.

■

Deviation calibration

Stop the vehicle.
Press and hold the button for
6 seconds.

A  number  (1  to  15)  appears  on
the compass display.

Press the switch and referring to the map above, select the num-
ber of the zone where you are.

If the direction is displayed several seconds after adjustment, the cali-
bration is complete.

Calibrating the compass

1

2

3

405

6-4. Other interior features

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

■

Circling calibration

Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold the button for
9 seconds.

C appears on the compass dis-
play.

Drive the vehicle at 5 mph
(8  km/h)  or  less  in  a  circle
until a direction is displayed.

If  there  is  not  enough  space  to
drive in a circle, drive around the
block  until  the  direction  is  dis-
played.

1

2

3

406

6-4. Other interior features

COROLLA_TMMMS_TMMC_U

■

Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:

●

The vehicle is stopped immediately after turning.

●

The vehicle is on an inclined surface.

●

The vehicle is in a place where the earth's magnetic field is subject to inter-
ference by artificial magnetic fields (underground car park/parking lot, under
a steel tower, between buildings, roof car park/parking lot, near an intersec-
tion, near a large vehicle, etc.).

●

The vehicle has become magnetized.
(There is a magnet or metal object near the inside rear view mirror.)

●

The battery has been disconnected.

●

A door is open.

WARNING

■

While driving the vehicle
Do  not  adjust  the  display.  Adjust  the  display  only  when  the  vehicle  is
stopped.

■

When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the neigh-
borhood. Do not violate any local traffic rules while performing circling cali-
bration.

NOTICE

■

To avoid compass malfunctions
Do not place magnets or any metal objects near the inside rear view mirror.
Doing this may cause the compass sensor to malfunction.

■

To ensure normal operation of the compass

●

Do  not  perform  circling  calibration  of  the  compass  in  a  place  where  the
earth's magnetic field is subject to interference by artificial magnetic fields.

●

During calibration, do not operate electric systems (moon roof, power win-
dows, etc.) as they may interfere with the calibration.

408

COROLLA_TMMMS_TMMC_U

7-1. Maintenance and care

● Working  from  top  to  bottom,  liberally  apply  water  to  the  vehicle

body, wheel wells and underside of the vehicle to remove any dirt
and dust.

● Wash  the  vehicle  body  using  a  sponge  or  soft  cloth,  such  as  a

chamois.

● For hard-to-remove marks, use car wash soap and rinse thoroughly

with water.

● Wipe away any water.
● Wax the vehicle when the waterproof coating deteriorates.

If  water  does  not  bead  on  a  clean  surface,  apply  wax  when  the  vehicle
body is cool.

■

Automatic car washes

●

Fold the mirrors before washing the vehicle. Start washing from the front of
the vehicle. Make sure to extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle's paint.

●

Vehicles with a rear spoiler: In certain automatic car washes, the rear spoiler
may  interfere  with  machine  operation.  This  may  prevent  the  vehicle  from
being cleaned properly or result in damage to the rear spoiler.

■

High pressure car washes

●

Do not allow the nozzles of the car wash to come within close proximity of
the windows.

●

Before using the car wash, check that the fuel filler door on your vehicle is
closed properly.

Cleaning and protecting the vehicle

exterior

Perform  the  following  to  protect  the  vehicle  and  maintain  it  in
prime condition:

409

7-1. Maintenance and care

7

Mainten

ance an

d ca

re

COROLLA_TMMMS_TMMC_U

■

When using a car wash (vehicles with a smart key system)
If the door handle becomes wet while the electronic key is within the effective
range, the door may lock and unlock repeatedly. In that case, follow the fol-
lowing correction procedures to wash the vehicle:

●

Place  the  key  in  a  position  6  ft.  (2  m)  or  more  separate  from  the  vehicle
while the vehicle is being washed. (Take care to ensure that the key is not
stolen.)

●

Set the electronic key to battery-saving mode to disable the smart key sys-
tem. (

P. 124)

■

Aluminum wheels (if equipped)

●

Remove any dirt immediately by using a neutral detergent.

●

Wash detergent off with water immediately after use.

●

To protect the paint from damage, make sure to observe the following pre-
cautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driv-

ing or parking in hot weather

■

Bumpers
Do not scrub with abrasive cleaners.

WARNING

■

When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.

■

Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When  washing  the  vehicle,  be  careful  not  to  touch  the  pipe  until  it  has
cooled sufficiently, as touching a hot exhaust pipe can cause burns.

410

7-1. Maintenance and care

COROLLA_TMMMS_TMMC_U

NOTICE

■

To prevent paint deterioration and corrosion on the body and compo-
nents (aluminum wheels etc.)

●

Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the

paint surface

• After driving in an area contaminated with soot, oily smoke, mine dust,

iron powder or chemical substances

• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing the wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.

●

Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.

■

To prevent damage to the windshield wiper arms
When lifting the wiper arms away from the windshield, pull the driver side
wiper  arm  upward  first,  and  then  the  passenger  side.  When  returning  the
wipers to their original position, do so from the passenger side first.

■

When using a high pressure car wash
Do  not  bring  the  nozzle  tip  close  to  boots  (rubber  or  resin  manufactured
cover), connectors or the following parts. The parts may be damaged if they
come into contact with high-pressure water.

• Traction related parts

• Steering parts

• Suspension parts
• Brake parts

411

7-1. Maintenance and care

7

Mainten

ance an

d ca

re

COROLLA_TMMMS_TMMC_U

● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces

with a cloth dampened with lukewarm water.

● If dirt cannot be removed, wipe it off with a soft cloth dampened with

neutral detergent diluted to approximately 1%.
Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

● Remove dirt and dust using a vacuum cleaner.
● Wipe it off with a soft cloth dampened with neutral detergent diluted

to approximately 1%.

● Wring out any excess water from the cloth and thoroughly wipe off

remaining traces of detergent and water.

Cleaning and protecting the vehicle

interior

The following procedures will help protect your vehicle’s interior
and keep it in top condition:

Protecting the vehicle interior

Cleaning the synthetic leather areas

412

7-1. Maintenance and care

COROLLA_TMMMS_TMMC_U

■

Shampooing the carpets
There are several commercial foaming-type cleaners available. Use a sponge
or  brush  to  apply  the  foam.  Rub  in  overlapping  circles.  Do  not  use  water.
Wipe dirty surfaces and let them dry. Excellent results are obtained by keep-
ing the carpet as dry as possible.

■

Seat belts
Clean  with  mild  soap  and  lukewarm  water  using  a  cloth  or  sponge.  Also
check the belts periodically for excessive wear, fraying or cuts.

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehicle.
Doing  so  may  cause  electrical  components  etc.  to  malfunction  or  catch
fire.

●

Do not get any of the SRS components or wiring in the vehicle interior wet.
(

P. 36)

An electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or serious injury.

■

Cleaning the interior (especially instrument panel)
Do not use polish wax or polish cleaner. The instrument panel may reflect
off the windshield, obstructing the driver’s view and leading to an accident,
resulting in death or serious injury.

413

7-1. Maintenance and care

7

Mainten

ance an

d ca

re

COROLLA_TMMMS_TMMC_U

NOTICE

■

Cleaning detergents

●

Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat  portions:  Organic  substances  such  as  benzene  or  gasoline,

alkaline or acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alco-

hol

●

Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.

■

Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:

●

Remove any dust or dirt from leather surfaces immediately.

●

Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.

●

Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.

■

Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.

■

When cleaning the inside of the windshield
Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
(

P. 226).

■

Cleaning the inside of the rear window

●

Do  not  use  glass  cleaner  to  clean  the  rear  window,  as  this  may  cause
damage to the rear window defogger heater wires or antenna. Use a cloth
dampened with lukewarm water to gently wipe the window clean. Wipe the
window in strokes running parallel to the heater wires or antenna.

●

Be careful not to scratch or damage the heater wires or antenna.

414

7-2. Maintenance

General maintenance should be performed on a daily basis. This can
be done by yourself or by a Toyota dealer.

Scheduled  maintenance  should  be  performed  at  specified  intervals
according to the maintenance schedule.

For details about maintenance items and schedules, refer to the “Sched-
uled Maintenance Guide” or “Owner’s Manual Supplement”.

You can perform some maintenance procedures by yourself.
Please be aware that do-it-yourself maintenance may affect warranty
coverage.

The use of Toyota Repair Manuals is recommended.
For details about warranty coverage, refer to the separate “Owner’s War-
ranty Information Booklet” or “Owner’s Manual Supplement”.

Maintenance requirements

To ensure safe and economical driving, day-to-day care and reg-
ular maintenance are essential. It is the owner’s responsibility to
perform regular checks. Toyota recommends the following main-
tenance:

General maintenance

Scheduled maintenance

Do-it-yourself maintenance

415

7-2. Maintenance

7

Mainten

ance an

d ca

re

COROLLA_TMMMS_TMMC_U

■

Repair and replacement
It is recommended that genuine Toyota parts be used for repairs to ensure
performance of each system. If non-Toyota parts are used in replacement or if
a repair shop other than a Toyota dealer performs repairs, confirm the war-
ranty coverage.

■

Resetting the message indicating maintenance is required (U.S.A. only)
After  the  required  maintenance  is  performed  according  to  the  maintenance
schedule, please reset the message.
To reset the message, follow the procedure described below:

Vehicles with a monochrome display
Vehicles without a smart key system: Turn the engine switch to the “LOCK”
position with the trip meter A reading shown. (

P. 77)

Vehicles with a smart key system: Turn the engine switch off with the trip
meter A reading shown. (

P. 77)

Vehicles without a smart key system:
While pressing the display change button (

P. 77), turn the engine switch

to  the  “ON”  position  (do  not  start  the  engine  because  reset  mode  will  be
canceled).
Vehicles with a smart key system:
While pressing the display change button (

P. 77), turn the engine switch

to the IGNITION ON mode (do not start the engine because otherwise the
reset mode will be canceled).
Continue to press and hold the button until the trip meter displays “000000”.

Vehicles with a color display
While the engine is running, switch the multi-information display to the “Set-
tings” screen. (

P. 93)

Select “Reset Scheduled Maint. Data” on the “Settings” screen.
Select “Yes” when “Reset Data?” is displayed on the multi-information dis-
play.
“The Data Has Been Reset” will be displayed when the reset procedure has
been completed.

■

Allow inspection and repairs to be performed by a Toyota dealer

●

Toyota technicians are well-trained specialists and are kept up to date with
the latest service information. They are well informed about the operations
of all systems on your vehicle.

●

Keep  a  copy  of  the  repair  order.  It  proves  that  the  maintenance  that  has
been  performed  is  under  warranty  coverage.  If  any  problem  should  arise
while your vehicle is under warranty, your Toyota dealer will promptly take
care of it.

1

2

3

1

2

3

416

7-2. Maintenance

COROLLA_TMMMS_TMMC_U

WARNING

■

If your vehicle is not properly maintained
Improper  maintenance  could  result  in  serious  damage  to  the  vehicle  and
possible death or serious injury.

■

Handling of the battery

●

Engine exhaust, some of its constituents, and a wide variety of automobile
components contain or emit chemicals known to the State of California to
cause  cancer  and  birth  defects  and  other  reproductive  harm.  Work  in  a
well ventilated area.

●

Oils, fuels and fluids contained in vehicles as well as waste produced by
component wear contain or emit chemicals known to the State of Califor-
nia  to  cause  cancer  and  birth  defects  or  other  reproductive  harm. Avoid
exposure and wash any affected area immediately.

●

Battery  posts,  terminals  and  related  accessories  contain  lead  and  lead
compounds which  are known  to cause brain damage. Wash your hands
after handling. (

P. 437)















Content   ..  24  25  26  27   ..
