6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

■

Location of air outlets
The  air  outlets  and  air  volume
changes  according  to  the
selected airflow mode.

■

Adjusting the position of and opening and closing the air out-
lets



Front center outlets

Direct air flow to the left or right,
up or down.

Air outlets

370

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U



Front side outlets

Direct air flow to the left or right,
up or down.

Open the vent
Close the vent

1

2

371

6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

■

For quick cooling (vehicles with an air conditioning system)

Turn the

 dial to the “MAX A/C” position and select the recirculated air

mode.

■

Fogging up of the windows

●

Vehicles  with  the

  button:  The  windows  will  easily  fog  up  when  the

humidity in the vehicle is high. Turning

 on will dehumidify the air from

the outlets and defog the windshield effectively.

●

Vehicles with the

 button: If you turn

 off, the windows may fog

up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode
When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effective
in  preventing  outside  air  from  entering  the  vehicle  interior.  During  cooling
operation, setting the recirculated air mode will also cool the vehicle interior
effectively.

■

When the outside temperature is low (vehicles with the

 button)

The air conditioning system may not operate even when





is pressed.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
It  is  recommended  that  the  air  conditioning  system  be  set  to  outside  air
mode prior to turning the vehicle off.

■

Air conditioning filter
P. 453

372

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U

WARNING

■

To prevent the windshield from fogging up

●

Do not set the air outlet selector dial to

 during cool air operation in

extremely humid weather. The difference between the temperature of the
outside air and that of the windshield can cause the outer surface of the
windshield to fog up, blocking your vision.

■

To prevent burns (vehicles with outside rear view mirror defoggers)
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

373

6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

■

Adjusting the temperature setting

Increases the temperature
Decreases the temperature

If

 is not pressed, the sys-

tem  will  blow  ambient  tempera-
ture air or heated air.

Automatic air conditioning system





: If equipped

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

Air conditioning controls

1

2

374

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U

■

Fan speed setting

Increases the fan speed
Decreases the fan speed

■

Change the airflow mode
To  change  the  airflow  mode,
move  the  airflow  change  knob
upward or downward.

The  air  outlets  used  are
changed  each  time  the  knob  is
operated.

Air flows to the upper body.
Air  flows  to  the  upper  body
and feet.
Air flows to the feet.
Air  flows  to  the  feet  and  the
windshield  defogger  oper-
ates.

■

Other functions
● Switching between outside air and recirculated air modes

(

P. 375)

● Defogging the windshield (P. 376)
● Defogging the rear window and outside rear view mirrors

(

P. 376)

1

2

Airflow change knob

1

2

3

4

375

6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

Press

.

The dehumidification function begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set-
ting.
Adjust the temperature setting.

To stop the operation, press

.

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

■

Switching between outside air and recirculated air modes

Press

 to change to recirculated air mode.

Press

 to change to outside air mode.

When recirculated air mode is selected, the indicator on

 illu-

minates.

When outside air mode is selected, the indicator on

 illumi-

nates.

Using automatic mode

Other functions

1

2

3

376

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U

■

Defogging the windshield
Defoggers  are  used  to  defog  the  windshield  and  front  side  win-
dows.

Press

.

The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if the
recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the front side windows early, turn the air flow
and temperature up.
To return to the previous mode, press

 again when the windshield is

defogged.

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press

.

The defoggers will automatically turn off after a period of time.

■

Windshield wiper de-icer (if equipped)
This  feature  is  used  to  prevent  ice  from  building  up  on  the  wind-
shield and wiper blades.
Press the switch to turn the sys-
tem on/off.

The  indicator  comes  on  when
the  windshield  wiper  de-icer  is
on.
The windshield de-icer will auto-
matically  turn  off  after  a  period
of time.

377

6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

■

Location of air outlets
The  air  outlets  and  air  volume
changes  according  to  the
selected airflow mode.

■

Adjusting the position of and opening and closing the air out-
lets



Front center outlets

Direct air flow to the left or right,
up or down.

Air outlets

378

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U



Front side outlets

Direct air flow to the left or right,
up or down.

Open the vent
Close the vent

■

Operation of the air conditioning system in Eco drive mode (if equipped)
In Eco drive mode, the air conditioning system is controlled as follows to pri-
oritize fuel efficiency:

●

Engine speed controlled to restrict heating/cooling capacity.

●

Outside/recirculated  air  mode  may  automatically  switch  depending  on  the
temperature setting or the inside temperature.

●

Fan speed restricted when automatic mode is selected

To improve air conditioning performance, perform the following operations:

●

Adjust the fan speed.

●

Turn off Eco drive mode. (

P. 182)

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

 is pressed.

1

2

379

6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

■

Fogging up of the windows

●

The  windows  will  easily  fog  up  when  the  humidity  in  the  vehicle  is  high.

Turning

 on will dehumidify the air from the outlets and defog the wind-

shield effectively.

●

If you turn

 off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to recirculated air mode. This is effective in
preventing outside air from entering the vehicle interior. During cooling oper-
ation,  setting  the  recirculated  air  mode  will  also  cool  the  vehicle  interior
effectively.

●

Outside/recirculated  air  mode  may  automatically  switch  depending  on  the
temperature setting or the inside temperature.

380

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U

■

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.



Vehicles without a smart key system

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position.



Vehicles with a smart key system

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to IGNITION ON mode.

●

It is possible to switch to outside air mode at any time by pressing

 .

■

When the outside temperature is low
The dehumidification function may not operate even when

 is pressed.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately  after  the  air  conditioning  system  is  started  in  automatic
mode.

■

Air conditioning filter
P. 453

■

Customization that can be configured at Toyota dealer
Settings (e.g. air conditioning setting) can be changed.
(Customizable features

P. 564)

381

6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

WARNING

■

To prevent the windshield from fogging up

●

Do  not  use

  during  cool  air operation in extremely humid  weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (if equipped)

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

382

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U

Heated steering wheel



/seat heaters





: If equipped

The heated steering wheel and seat heaters heat the side grips
of the steering wheel and seats, respectively.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel or seats when the heater is on:
• Babies,  small  children,  the  elderly,  the  sick  and  the  physically  chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheat-
ing
• Do  not  cover  the  seat  with  a  blanket  or  cushion  when  using  the  seat

heater.

• Do not use the seat heaters more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
stopped.

383

6-1. Using the air conditioning system and defogger

6

In

te

rior

fe

at

ures

COROLLA_TMMMS_TMMC_U

Turn the heated steering wheel on/off

The indicator light comes on when
the heated steering wheel is oper-
ating.

■

The heated steering wheel can be used when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

Press the switch.

High temperature
Low temperature

The indicator light comes on when
the switch is on.

■

The seat heaters can be used when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■

When not in use
Put the switch in the neutral position. The indicator will turn off.

Heated steering wheel

Seat heaters

1

2

384

COROLLA_TMMMS_TMMC_U

6-2. Using the interior lights

Front interior light/personal lights (

P. 385)

Rear interior light (

P. 386)

Engine switch light (vehicles with a smart key system)

Interior lights list

1

2

3
