Toyota Corolla (2019 year). Instruction

337

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U

Calls can be made to an e-mail/SMS/MMS message sender's phone
number.

Display the message inbox screen. (

P. 333)

Select the desired message.
Select

Check that the “Call” screen is displayed.

■

Calling from a number within a message
Calls can be made to a number identified in a message's text area.

Display the message inbox screen. (

P. 333)

Select the desired message.
Select the text area.
Select

corresponding to the desired number.

Check that the “Call” screen is displayed.

■

Calling from the incoming message screen

P. 331

Calling the message sender

338

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U

Volume switch

• Increase/Decrease the volume
• Press and hold:

Continuously increase/decrease the volume

Off-hook switch

• Make a call
• Receive a call
• Display “Phone” screen

On-hook switch

• End a call
• Refuse a call

Using the steering wheel switches

The steering wheel switches can be used to operate a connected
cellular phone.

Operating a telephone using the steering wheel switches



Type A



Type B

339

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U

To display the screen shown below, press the “SETUP” button, and
select “Phone” on the “Setup” screen.

Set the phone connection
(

P. 312)

Setting the sound (

P. 340)

Contact/Call History Settings
(

P. 341)

Set the message settings
(

P. 349)

Set the phone display
(

P. 350)

Bluetooth

phone settings

You can adjust the hands-free system to your desired settings.

“Phone/Message Settings” screen

340

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U

Display the “Phone/Message Settings” screen. (

P. 339)

Select “Sound Settings” on the “Phone/Message Settings” screen.

Set the desired ringtone.
Adjust the ringtone volume.
Adjust  the  message  readout
volume.
Set  the  desired  incoming
SMS/MMS tone.
Adjust  the  incoming  SMS/
MMS tone volume.
Set the incoming e-mail tone.
Adjust  the  incoming  e-mail
tone volume.
Adjust the default volume of the other party's voice.

■

To return to the default volume settings
Select “Default”, and then “Yes”.

Sound setting

341

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U

The contact can be transferred from a Bluetooth

phone to the sys-

tem. The contact also can be added, edited and deleted.
The call history can be deleted and contact and favorites can be
changed.

Display the “Phone/Message Settings” screen. (

P. 339)

Select “Contact/Call History Settings”.
Select the desired item to be set.

For

PBAP

compatible

Bluetooth

phones, select to

set  “Automatic  Transfer”  on/
off.  When  set  to  on,  the
phone’s contact data and his-
tory  are  automatically  trans-
ferred.
Select  to  update  contacts
from the connected phone.
(

P. 342)

Select to sort contacts by the
first name or last name field.
Select to add contacts to the favorites list. (

P. 346)

Select to delete contacts from the favorites list. (

P. 348)

Select to display contact images.
Select to clear contacts from the call history.

Select to add new contacts to the contact list.

(

P. 344)

Select to edit contacts in the contact list.

(

P. 345)

Select to delete contacts from the contact list.

(

P. 346)

Select to reset all setup items.

: For PBAP compatible Bluetooth

phones only, this function is available

when “Automatic Transfer” is set to off.

Contact/Call History Settings

342

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U

Operation methods differ between PBAP compatible and PBAP
incompatible but OPP compatible Bluetooth

phones.

If your cellular phone is neither PBAP nor OPP compatible, the con-
tacts cannot be transferred.

■

For PBAP Compatible Bluetooth

Phones

Select “Update Contacts from Phone”.
Check that a confirmation screen is displayed when the opera-
tion is complete.

This operation may be unnecessary depending on the type of cellular
phone.
Depending on the type of cellular phone, OBEX authentication may be
required when transferring contact data. Enter “1234” into the
Bluetooth

phone.

If another Bluetooth

device is connected when transferring contact

data, depending on the phone, the connected Bluetooth

device may

need to be disconnected.
Depending on the type of Bluetooth

phone being connected, it may be

necessary to perform additional steps on the phone.

Update contacts from phone

343

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U

■

For PBAP Incompatible but OPP compatible Bluetooth

Phones

Select “Update Contacts from Phone”.
Transfer the contact data to the system using a Bluetooth

phone.

To cancel this function, select “Cancel”.

Select “Done” when it appears on the screen.
Check that a confirmation screen is displayed when the opera-
tion is complete.

■

Updating the contacts in a different way (From the “Call His-
tory” screen)
For PBAP compatible Bluetooth

phones, this function is available

when “Automatic Transfer” is set to off. (

P. 341)

Display the phone screen. (

P. 322)

Select the “Call History” tab and select a contact not yet regis-
tered in the contact list.
Select “Update Contact”.
Select the desired contact.
Select a phone type for the phone number.

344

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U

New contact data can be registered. Up to 4 numbers per person can
be registered. For PBAP compatible Bluetooth

phones, this function

is available when “Automatic Transfer” is set to off. (

P. 341)

Select “New Contact”.
Enter the name and select “OK”.
Enter the phone number and select “OK”.
Select the phone type for the phone number.
To add another number to this contact, select “Yes”.

■

Registering a new contact in a different way (From the “Call
History” screen)

Display the phone screen. (

P. 322)

Select the “Call History” tab and select a contact not yet regis-
tered in the contact list.
Select “Add to Contacts”.
Follow the steps in “Registering a new contact to the contacts
list” from step

Registering a new contact to the contact list

345

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U

For PBAP compatible Bluetooth

phones, this function is available

when “Automatic Transfer” is set to off. (

P. 341)

Select “Edit Contact”.
Select the desired contact.
Select

corresponding to the desired name or number.



For editing the name
Follow the steps in “Registering a new contact to the contacts list”
from step

. (

P. 344)



For editing the number
Follow the steps in “Registering a new contact to the contacts list”
from step

. (

P. 344)

■

Editing the contacts in a different way (From the “Contact
Details” screen)

Display the phone screen. (

P. 322)

Select the “Contacts”, “Call History” tab or the “Favorites” tab and
select the desired contact.
Select “Edit Contact”.

“E-mail Addresses”: Select to display all registered e-mail addresses for
the contact.

Follow the steps in “Editing the contact data” from step

Editing the contact data

346

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U

For PBAP compatible Bluetooth

phones, this function is available

when “Automatic Transfer” is set to off. (

P. 341)

Select “Delete Contacts”.
Select the desired contact and select “Delete”.
Select “Yes” when the confirmation screen appears.

■

Deleting the contact in a different way (From the “Contact
Details” screen)

Display the phone screen. (

P. 322)

Select the “Contacts”, “Call History” tab or the “Favorites” tab and
select the desired contact.
Select “Edit Contact”.
Select “Yes” when the confirmation screen appears.

Up to 15 contacts (maximum of 4 numbers per contact) can be regis-
tered in the favorites list.

■

Registering the contacts in the favorites list

Select “Add Favorite”.
Select the desired contact to add to the favorites list.

Dimmed contacts are already stored as a favorite.

Check that a confirmation screen is displayed when the opera-
tion is complete.

Deleting the contact data

Favorites list setting

347

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U



When 15 contacts have already been registered to the favorites
list
When 15 contacts have already been registered to the favorites
list, a registered contact needs to be replaced.
Select “Yes” when the confirmation screen appears to replace a
contact.
Select the contact to be replaced.
Check that a confirmation screen is displayed when the opera-
tion is complete.



Registering contacts in the favorites list in a different way (from
the “Contacts” screen)
Display the phone screen. (

P. 322)

Select the “Contacts” tab.
Select

at the beginning of the desired contact list name to be

registered in the favorites list.

When selected,

is changed to

, and the contact is registered in

the favorites list.



Registering contacts in the favorites list in a different way (from
the “Contact Details” screen)
Display the phone screen. (

P. 322)

Select the “Contacts” tab or the “Call History” tab and select the
desired contact.
Select “Add Favorite”.
Check that a confirmation screen is displayed when the opera-
tion is complete.

348

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U

■

Deleting the contacts in the favorites list

Select “Remove Favorite”.
Select the desired contacts and select “Remove”.
Select “Yes” when the confirmation screen appears.
Check that a confirmation screen is displayed when the opera-
tion is complete.



Deleting contacts in the favorites list in a different way (from the
“Contacts” screen)
Display the phone screen. (

P. 322)

Select the “Contacts” tab.
Select

at the beginning of the contact list name to be deleted

from the favorites. list.

When selected,

is changed to

, and the data is deleted from the

list.



Deleting contacts in the favorites list in a different way (from the
“Contact Details” screen)
Display the phone screen. (

P. 322)

Select the “Contacts”, “Call History” tab or the “Favorites” tab and
select the desired contact to delete.
Select “Remove Favorite”.
Select “Yes” when the confirmation screen appears.
Check that a confirmation screen is displayed when the opera-
tion is complete.

349

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U

Display the “Phone/Message Settings” screen. (

P. 339)

Select “Messaging Settings”.
Select the desired item to be set.

Set

automatic

message

transfer on/off.
Set

automatic

message

readout on/off.
Set  the  SMS/MMS  notifica-
tion popup on/off.
Set  the  e-mail  notification
popup on/off.
Set adding the vehicle signa-
ture  to  outgoing  messages
on/off.

Set updating message read status on phone on/off.
Change the incoming SMS/MMS display.

“Full Screen”: When an SMS/MMS message is received, the incoming
SMS/MMS display screen is displayed and can be operated on the
screen.
“Drop-Down”: When an SMS/MMS message is received, a message is
displayed on the upper side of the screen.

Change the incoming e-mail display.

“Full Screen”: When an e-mail is received, the incoming e-mail display
screen is the displayed and can be operated on the screen.
“Drop-Down”: When an e-mail is received, a message is displayed on
the upper side of the screen.

Set display of messaging account names on the inbox tab on/off.

When set to on, messaging account names used on the cellular phone
will be displayed.

■

To return to the default volume settings
Select “Default”, and then “Yes”.

Message Settings

350

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U

■

Displaying the “Messaging Settings” screen in a different way

Display the phone screen. (

P. 322)

Select

Select “Settings”.

Display the “Phone/Message Settings” screen. (

P. 339)

Select “Phone Display Settings”.
Select the desired item to be set.

Change the incoming call
display.

“Full Screen”: When a call is
received, the hands-free screen
is displayed and can be oper-
ated on the screen.
“Drop-Down”: A message is dis-
played on the upper side of the
screen.

Set display of the contact/
history transfer completion
message on/off.

Phone Display Settings

351

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U

If there is a problem with the hands-free system or a Bluetooth

device, first check the table below.



When using the hands-free system with a Bluetooth

device

What to do if... (Troubleshooting)

The hands-free system or Bluetooth

device does not work.

The connected device may not be a compatible Bluetooth

cellular phone.

 For a list of specific devices which operation has been confirmed

on this system, check with your Toyota dealer or the following web-
site: http://www.toyota.com/entune.html

The Bluetooth version of the connected cellular phone may be older than
the specified version.

 Use a cellular phone with Bluetooth version 2.0 or higher (recom-

mended: Ver. 3.0 with EDR or higher). (

P. 355)

352

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U



When registering/connecting a cellular phone



When making/receiving a call

A cellular phone cannot be registered.

An incorrect passcode was entered on the cellular phone.

 Enter the correct passcode on the cellular phone.

The registration operation has not been completed on the cellular phone
side.

 Complete the registration operation on the cellular phone (approve

registration on the phone).

Old registration information remains on either this system or the cellular
phone.

 Delete the existing registration information from both this system

and the cellular phone, then register the cellular phone you wish to
connect to this system. (

P. 314)

A Bluetooth

connection cannot be made.

Another Bluetooth

device is already connected.

 Manually connect the cellular phone you wish to use to this sys-

tem. (

P. 316)

Bluetooth

function is not enabled on the cellular phone.

 Enable the Bluetooth

function on the cellular phone.

“Please check your device settings.” message is displayed.

Bluetooth

function is not enabled on the cellular phone.

 Enable the Bluetooth

function on the cellular phone.

Old registration information remains on either this system or the cellular
phone.

 Delete the existing registration information from both this system

and the cellular phone, then register the cellular phone you wish to
connect to this system. (

P. 314)

A call cannot be made/received.

Your vehicle is in a “Out of cellular service area. Please try again later.”
area.

 Move to where “Out of cellular service area. Please try again later.”

no longer appears on the display.

Toyota Corolla (2019 year). Instruction - part 22
