Toyota Corolla (2019 year). Instruction

353

5-9. Bluetooth

phone

Audi

o system

COROLLA_TMMMS_TMMC_U



When using the phonebook



When using the Bluetooth

message function

Phonebook data cannot be transferred manually/automatically.

The profile version of the connected cellular phone may not be compatible
with transferring phonebook data.

 For a list of specific devices which operation has been confirmed

on this system, check with your Toyota dealer or the following web-
site: http://www.toyota.com/entune.html

Automatic phonebook transfer function on this system is set to off.

 Set automatic phonebook transfer function on this system to on.

(

P. 341)

Passcode has not been entered on the cellular phone.

 Enter the passcode on the cellular phone if requested (default pass-

code: 1234).

Transfer operation on the cellular phone has not completed.

 Complete transfer operation on the cellular phone (approve trans-

fer operation on the phone).

Phonebook data cannot be edited.

Automatic phonebook transfer function on this system is set to on.

 Set automatic phonebook transfer function on this system to off.

(

P. 341)

Messages cannot be viewed.

Message transfer is not enabled on the cellular phone.

 Enable message transfer on the cellular phone (approve message

transfer on the phone).

Automatic transfer function on this system is set to off.

 Set automatic transfer function on this system to on. (P. 349)

New message notifications are not displayed.

Notification of SMS/MMS/E-mail reception on this system is set to off.

 Set notification of SMS/MMS/E-mail reception on this system to on.

(

P. 349)

Automatic message transfer function is not enabled on the cellular phone.

 Enable automatic transfer function on the cellular phone.

354

5-9. Bluetooth

phone

COROLLA_TMMMS_TMMC_U



In other situations

Even though all conceivable measures have been taken, the symptom sta-
tus does not change.

The cellular phone is not close enough to this system.

 Bring the cellular phone closer to this system.

The cellular phone is the most likely cause of the symptom.

 Turn the cellular phone off, remove and reinstall the battery pack,

and then restart the cellular phone.

 Enable the cellular phone’s Bluetooth

connection.

 Stop the cellular phone’s security software and close all applica-

tions.

 Before using an application installed on the cellular phone, care-

fully check its source and how its operation might affect this sys-
tem.

355

Audi

o system

COROLLA_TMMMS_TMMC_U

5-10. Bluetooth

■

When using the Bluetooth

audio system

●

In the following conditions, the system may not function.
• If the portable audio player is turned off
• If the portable audio player is not connected
• If the portable audio player’s battery is low

●

There may be a delay if a cellular phone connection is made during
Bluetooth

audio play.

●

Depending on the type of portable audio player that is connected to the sys-
tem, operation may differ slightly and certain functions may not be available.

■

When using the hands-free system

●

Entune Audio is muted when making a call.

●

If both parties speak at the same time, it may be difficult to hear.

●

If the received call volume is overly loud, an echo may be heard.
If the Bluetooth

phone is too close to the system, quality of the sound may

deteriorate and connection status may deteriorate.

●

In the following circumstances, it may be difficult to hear the other party:
• When driving on unpaved roads
• When driving at high speeds
• If a roof or window is open
• If the air conditioning is blowing directly on the microphone
• If there is interference from the network of the cellular phone

■

Conditions under which the system will not operate

●

If using a cellular phone that does not support Bluetooth

●

If the cellular phone is turned off

●

If you are outside of cellular phone service coverage

●

If the cellular phone is not connected

●

If the cellular phone’s battery is low

●

When outgoing calls are controlled, due to heavy traffic on telephone lines,
etc.

●

When the cellular phone itself cannot be used

●

When transferring contact data from the cellular phone

Bluetooth

356

5-10. Bluetooth

COROLLA_TMMMS_TMMC_U

■

Bluetooth

antenna

The antenna is built into the display.
If the portable audio player is behind the seat or in the glove box or console
box, or is touching or covered by metal objects, the connection status may
deteriorate.
If the cellular phone is behind the seat or in the console box, or touching or
covered by metal objects, the connection status may deteriorate.

■

Battery charge/signal status

●

This display may not correspond exactly with the portable audio player or
cellular phone itself.

●

This system does not have a charging function.

●

The portable audio player or cellular phone battery will be depleted quickly
when the device is connected to Bluetooth

■

When using the Bluetooth

audio and hands-free system at the same

time
The following problems may occur.

●

The Bluetooth

audio connection may be interrupted.

●

Noise may be heard during Bluetooth

audio playback.

■

About the contact in this system
The following data is stored for every registered cellular phone. When
another phone is connecting, you cannot read the registered data.

●

Contact data

●

Call history

●

Favorite

●

Message

When removing a Bluetooth

phone from the system, the above-mentioned

data is also deleted.

357

5-10. Bluetooth

Audi

o system

COROLLA_TMMMS_TMMC_U

■

Compatible models
The Bluetooth

audio system supports portable audio players with the follow-

ing specifications

●

Bluetooth

specifications:

Ver. 2.0, or higher (Recommended: Ver. 3.0+EDR or higher)

●

Profiles:
• A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher

(Recommended: Ver. 1.2 or higher)
This is a profile to transmit stereo audio or high quality sound to Entune
Audio.

• AVRCP (Audio/Video Remote Control Profile) Ver. 1.0 or higher

(Recommended: Ver. 1.4 or higher)
This is a profile to allow remote control the A/V equipment.

However, please note that some functions may be limited depending on the
type of portable audio player connected.
The hands-free system supports cellular phones with the following specifica-
tions.

●

Bluetooth

specification:

Ver. 2.0 or higher (Recommended: Ver. 3.0+EDR or higher)

●

Profiles:
• HFP (Hands Free Profile) Ver. 1.0 or higher (Recommended: Ver. 1.6 or

higher)
This is a profile to allow hands-free phone calls using a cellular phone or
head set. It has outgoing and incoming call functions.

• OPP (Object Push Profile) Ver. 1.1 or higher (Recommended: Ver. 1.2)

This is a profile to transfer contact data. When a Bluetooth

compatible

cellular phone has both PBAP and OPP, OPP cannot be used.

• PBAP (Phone Book Access Profile) Ver. 1.0 or higher (Recommended:

Ver. 1.1)
This is a profile to transfer contact data.

• MAP (Message Access Profile) Ver.1.0 or higher

This is a profile to using phone message.

If the cellular phone does not support HFP, you cannot register it with the
hands-free system. OPP, PBAP or MAP services must be selected individu-
ally.

358

5-10. Bluetooth

COROLLA_TMMMS_TMMC_U

■

Reconnecting the portable audio player
If the portable audio player is disconnected due to poor reception when the
engine switch is in the “ACC” or “ON” position (vehicles without a smart key
system) or ACCESSORY or IGNITION ON mode (vehicles with a smart key
system), the system automatically reconnects the portable audio player.
If you have switched off the portable audio player yourself, follow the instruc-
tions below to reconnect:

●

Select the portable audio player again

●

Enter the portable audio player

■

When you sell your car
Be sure to delete your personal data. (

P. 280)

WARNING

■

While driving
Do not use the portable audio player, cellular phone or connect a device to
the Bluetooth

system.

■

Caution regarding interference with electronic devices

●

Your audio unit is fitted with Bluetooth

antennas. People with implantable

cardiac pacemakers, cardiac resynchronization therapy-pacemakers or
implantable cardioverter defibrillators should maintain a reasonable dis-
tance between themselves and the Bluetooth

antennas. The radio waves

may affect the operation of such devices.

●

Before using Bluetooth

devices, users of any electrical medical device

other than implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should con-
sult the manufacturer of the device for information about its operation
under the influence of radio waves. Radio waves could have unexpected
effects on the operation of such medical devices.

NOTICE

■

When leaving the vehicle
Do not leave your portable audio player or cellular phone in the vehicle. The
inside of the vehicle may become hot, causing damage to the portable
audio player or cellular phone.

359

Audi

o system

COROLLA_TMMMS_TMMC_U

5-11. Using the voice command system

Press the talk switch.

Select to train voice recogni-
tion.
Select to start the voice rec-
ognition tutorial.

Select “OK” and say the desired command.

On the list screen, you can select the desired command.
To cancel the voice command system, press and hold the talk switch.

Voice command system

The voice command system enables the hands-free system to
be operated using voice commands.
Operations of the voice command system can be performed by
selecting the menu corresponding to each function on the
screen. Even if any menu is selected, commands displayed on
all menus can be operated.

Using the voice command system



Type A



Type B

360

5-11. Using the voice command system

COROLLA_TMMMS_TMMC_U

■

Microphone
P. 323

■

When using the microphone

●

It is unnecessary to speak directly into the microphone when giving a com-
mand.

●

When “Voice Prompt Interrupt” set to on, it is not necessary to wait for the
confirmation beep before speaking a command. (

P. 283)

●

Voice commands may not be recognized if:
• Spoken too quickly.
• Spoken at a low or high volume.
• The roof or windows are open.
• Passengers are talking while voice commands are spoken.
• The air conditioning speed is set high.
• The air conditioning vents are turned towards the microphone.

●

In the following conditions, the system may not recognize the command
properly and using voice commands may not be possible:
• The command is incorrect or unclear. Note that certain words, accents or

speech patterns may be difficult for the system to recognize.

• There is excessive background noise, such as wind noise.

Due to natural language speech recognition technology, this system
enables recognition of a command when spoken naturally. However,
the system cannot recognize every variation of each command.
In some situations, it is possible to omit the command for the proce-
dure and directly state the desired operation.
Not all voice commands are displayed in the short cut menu.
This function is available in English, Spanish and French.

■

Expression examples for each function

Casual speech recognization

Command

Expression examples

“Call

(name)

(type)”

Get me (Robert Brown).
I need to call (Robert Brown) at (Work) right away.

“Dial (number)”

Please dial the number (3334445555).
Ring (3334445555).

361

5-11. Using the voice command system

Audi

o system

COROLLA_TMMMS_TMMC_U

Some recognizable voice commands and their actions are shown
below as examples.



Basic



Phone

Command list

Command

Action

“Help”

Prompts voice guidance to offer examples of com-
mands or operation methods

“Go Back”

Returns to the previous screen

Command

Action

“Redial”

Places a call to the phone number of the latest outgo-
ing call

“Call Back”

Places a call to the phone number of latest incoming
call

“Show

Recent

Calls”

Displays the call history screen

“Dial (phone num-
ber)”

Places a call to the said phone number

“Call

(contacts)

(phonetypes)”

Place a call to the said phone type of the contact from
the phone book

362

5-11. Using the voice command system

COROLLA_TMMMS_TMMC_U

The Mobile Assistant feature will activate Apple’s Siri

Eyes Free

mode via the steering wheel switches. To operate the Mobile Assis-
tant, a compatible cellular phone must be registered and connected to
this system via Bluetooth

. (

P. 312)

Press and hold the off-hook on the steering wheel until you hear the
beeps.

The Mobile Assistant can be
used only when the following
screen is displayed.

To  cancel  the  Mobile  Assistant,
select  “Cancel”,  or  press  and  hold
the off-hook on the steering wheel.
To  restart  the  Mobile Assistant  for
additional  commands,  press  the
off-hook on the steering wheel.

• Mobile Assistant can only be restarted after the system responds to a

voice command.

• After some phone and music commands, the Mobile Assistant feature will

automatically end to complete the requested action.

■

Adjusting the Mobile Assistant volume
The volume of the Mobile Assistant can be adjusted using the
“PWR·VOL” knob or steering wheel volume switches. The Mobile
Assistant and phone call volumes are synchronized.

Mobile Assistant



Type A



Type B

363

5-11. Using the voice command system

Audi

o system

COROLLA_TMMMS_TMMC_U

■

Notes about Mobile Assistant

●

The available features and functions may vary based on the iOS version
installed on the connected device.

●

Some Siri features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri will inform you that the function is not available.

●

If Siri is not enabled on the cellular phone connected via Bluetooth

, an

error message will be displayed on the screen.

●

While a phone call is active, the Mobile Assistant cannot be used.

●

If using the navigation feature of the cellular phone, ensure the active audio
source is Bluetooth

audio or iPod in order to hear turn by turn direction

prompts.

366

COROLLA_TMMMS_TMMC_U

6-1. Using the air conditioning system and defogger

■

Adjusting the temperature setting



Heater

To adjust the temperature setting, turn the

dial clockwise to

increase the temperature.



Air conditioning system

To adjust the temperature setting, turn the

dial clockwise

(warm) or counterclockwise (cool).

is not pressed, the system will blow ambient temperature air or

heated air.

■

Fan speed setting

To adjust the fan speed, turn the

dial clockwise (increase) or

counterclockwise (decrease).

Turning the dial to “0” turns off the fan.

Manual air conditioning system



: If equipped

Air conditioning controls



Heater



Air conditioning system

367

6-1. Using the air conditioning system and defogger

rior

ures

COROLLA_TMMMS_TMMC_U

■

Changing airflow modes
To change the airflow mode, set

the

dial to the desired

position.

Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the windshield defogger operates.
Air flows to the windshield.

368

6-1. Using the air conditioning system and defogger

COROLLA_TMMMS_TMMC_U

■

Switching between outside air and recirculated air modes

Press

The mode switches between outside air mode (indicator off) and recir-

culated air mode (indicator on) each time

is pressed.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.

Set the air outlet selector dial to the

position.

Set the outside/recirculated air mode button to outside air mode if the
recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.

Vehicles with the air conditioning system: If the dehumidification

function is not operating, press

to operate the dehumidifica-

tion function.

■

Defogging the rear window and outside rear view mirrors



Vehicles without outside rear view mirror defoggers

Defoggers are used to defog the rear window.

Press

The defoggers will automatically turn off after a period of time.



Vehicles with outside rear view mirror defoggers

Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press

The defoggers will automatically turn off after a period of time.

Other functions

Toyota Corolla (2019 year). Instruction - part 23
