Toyota Verso (2017 year). Instruction - part 23
3-2. Using the audio system
Operating an iPod
Connecting an iPod enables you to enjoy music from the vehicle
speakers.
■ Connecting an iPod
Open the cover and connect
an iPod using an iPod cable.
Turn on the power of the iPod if
it is not turned on.
Press
■ Control panel
Power
Volume
Displays song list
iPod menu mode
Back button
Selecting an
iPod menu/
song or
displays text
message
Selecting a song,
Playback
fast-forwarding or
reversing
Repeat play
Shuffle playback
: If equipped
374
VERSO_EE_OM64517E
3-2. Using the audio system
Selecting a play mode
Press
(Menu) to select iPod menu mode.
Turning
clockwise changes the play mode in the follow-
ing order:
“Playlists”“Artists”“Albums”“Songs”“Podcasts”
“Genres” “Composers”“Audiobooks”
Press
to select the desired play mode.
■ Play mode list
3
First
Second
Third
Fourth
Play mode
selection
selection
selection
selection
Playlists
Songs
“Playlists”
-
-
select
select
Albums
Songs
“Artists”
Artists select
-
select
select
Albums
Songs
“Albums”
-
-
select
select
“Songs”
Songs select
-
-
-
Podcasts
Episodes
“Podcasts”
-
-
select
select
Albums
Songs
“Genres”
Genre select
Artists select
select
select
Composers
Albums
Songs
“Composers”
-
select
select
select
Audiobooks
“Audiobooks”
Chapter select
-
-
select
375
VERSO_EE_OM64517E
3-2. Using the audio system
■ Selecting a list
Turn
to display the first selection list.
Press
to select the desired item.
Pressing the knob changes to the second selection list.
Repeat the same procedure to select the desired item.
To return to the previous selection list, press
Selecting songs
Turn
or press “” or “” on
to select the desired song.
Selecting a song from the song list
Press
The song list will be displayed.
Turn
to select a song.
Press
to play the song.
To return to the previous display, press
Fast-forwarding and reversing songs
To fast-forward or reverse, press and hold “” or “” on
Shuffle playback
Pressing
(Random) changes modes in the following order:
Track shuffle Album shuffle Off
376
VERSO_EE_OM64517E
3-2. Using the audio system
Repeat play
Press
(Repeat).
To cancel, press
(Repeat) again.
Switching the display
Press
Track title, Artist name and Album title are shown on the display.
To return to the previous display, press
or
3
Adjusting sound quality and volume balance
Press
to enter iPod menu mode.
Pressing
changes sound modes. (P. 388)
377
VERSO_EE_OM64517E
3-2. Using the audio system
■ About iPod
●Apple is not responsible for the operation of this device or its compliance
with safety and regulatory standards.
● iPod is a trademark of Apple Inc., registered in the U.S. and other coun-
tries.
■ iPod functions
●When an iPod is connected and the audio source is changed to iPod
mode, the iPod will resume play from the same point in which it was last
used.
●Depending on the iPod that is connected to the system, certain functions
may not be available. If a function is unavailable due to a malfunction (as
opposed to a system specification), disconnecting the device and recon-
necting it once again may resolve the problem.
●While connected to the system, the iPod cannot be operated with its own
controls. It is necessary to use the controls of the vehicle’s audio system
instead.
■ iPod problems
To resolve most problems encountered when using your iPod, disconnect
your iPod from the vehicle iPod connection and reset it.
For instructions on how to reset your iPod, refer to your iPod Owner’s Man-
ual.
■ Display
P. 365
■ Error messages
“ERROR”:
This indicates a problem in the iPod or its connection.
“NO SONGS”: This indicates that there is no music data in the iPod.
“NO PLAYLIST”: This indicates that some available songs are not found in
a selected playlist.
“UPDATE YOUR iPOD”: This indicates that the version of the iPod is not
compatible. Upgrade your iPod software to the lat-
est version.
378
VERSO_EE_OM64517E
3-2. Using the audio system
■ Compatible models
Model
Generation
Software version
iPod
5th generation
Ver. 1.3.0
1st generation
Ver. 1.3.1
2nd generation
Ver. 1.1.3
3rd generation
Ver. 1.1.3
iPod nano
4th generation
Ver. 1.0.4
5th generation
Ver. 1.0.2
6th generation
Ver. 1.0.0
1st generation
Ver. 3.1.3
3
Ver. 3.1.3
2nd generation
Ver. 4.2.1
Ver. 3.1.3
iPod touch
Late 2009 (8 GB)
Ver. 4.2.1
Ver. 3.1.3
3rd generation
(32 GB/64 GB)
Ver. 4.2.1
4th generation
Ver. 4.2.1
1st generation
Ver. 1.1.2
iPod classic
2nd generation (120 GB)
Ver. 2.0.1
Late 2009 (160 GB)
Ver. 2.0.4
1st generation (iPhone)
Ver. 3.1.3
Ver. 3.1.3
2nd generation
(iPhone 3G)
Ver. 4.2.1
iPhone
Ver. 3.1.3
3rd generation
(iPhone 3GS)
Ver. 4.2.1
4th generation (iPhone 4)
Ver. 4.2.1
379
VERSO_EE_OM64517E
3-2. Using the audio system
Depending on differences between models or software version etc., some
models listed above might be incompatible with this system.
iPod 4th generation and earlier models are not compatible with this system.
iPod mini, iPod shuffle and iPod photo are not compatible with this system.
Items related to standards and limitations are as follows:
●Maximum number of lists in device: 9999
●Maximum number of songs in device: 65535
● Maximum number of songs per list: 65535
WARNING
■ Caution while driving
Do not connect iPod or operate the controls. Doing so may cause an acci-
dent, resulting in death or serious injury.
NOTICE
■ To prevent damage to iPod or its terminal
●Do not leave iPod in the vehicle. The temperature inside the vehicle may
become high, resulting in damage to the iPod.
●Do not push down on or apply unnecessary pressure to the iPod while it is
connected as this may damage the iPod or its terminal.
●Do not insert foreign objects into the port as this may damage the iPod or
its terminal.
380
VERSO_EE_OM64517E
3-2. Using the audio system
Operating a USB memory
Connecting a USB memory enables you to enjoy music from the
vehicle speakers.
■ Connecting a USB memory
Open the cover and connect a
USB memory.
Turn on the power of the USB
memory if it is not turned on.
3
Press
■ Control panel
Power Volume
Displays folder list
Back button
Selecting
a file or
displays text
message
Playback
Selecting
Repeat play Random playback
a folder
Selecting a file, fast-forwarding or reversing
: If equipped
381
VERSO_EE_OM64517E
3-2. Using the audio system
Selecting a folder
■ Selecting folders one at a time
Press “” or “” on
to select the desired folder.
■ Selecting a folder and file from folder list
Press
The folder list will be displayed.
Turn and press
to select a folder and a file.
To return to the previous display, press
To exit, press
■ Returning to the first folder
Press and hold “” on
until you hear a beep.
Selecting files
Turn
or press “” or “” on
to select the desired file.
Fast-forwarding and reversing files
To fast-forward or reverse, press and hold “” or “” on
Random playback
Pressing
(Random) changes modes in the following order:
Folder random USB random Off
382
VERSO_EE_OM64517E
3-2. Using the audio system
Repeat play
Pressing
(Repeat) changes modes in the following order:
File repeat Folder repeat* Off
*: Available except when Random (random playback) is selected
Switching the display
Press
Track title, Artist name and Album title (MP3 only) are shown on the dis-
play.
3
To return to the previous display, press
or
■ USB memory functions
●Depending on the USB memory that is connected to the system, the
device itself may not be operable and certain functions may not be avail-
able. If the device is inoperable or a function is unavailable due to a mal-
function (as opposed to a system specification), disconnecting the device
and reconnecting it once again may resolve the problem.
● If the USB memory still does not begin operation after being discon-
nected and reconnected, format the memory.
■ Display
P. 365
■ Error messages
“ERROR”: This indicates a problem in the USB memory or its connection.
“NO MUSIC”: This indicates that no MP3/WMA files are included in the USB
memory.
383
VERSO_EE_OM64517E
3-2. Using the audio system
■ USB memory
●Compatible devices
USB memory that can be used for MP3 and WMA playback
●Compatible device formats
The following device formats can be used:
• USB communication formats: USB2.0 FS (12 mbps)
• File formats: FAT16/32 (Windows)
• Correspondence class: Mass storage class
MP3 and WMA files written in any format other than those listed above
may not play correctly, and their file names and folder names may not be
displayed correctly.
Items related to standards and limitations are as follows:
• Maximum directory hierarchy: 8 levels
• Maximum number of folders in a device: 999 (including the root)
• Maximum number of files in a device: 9999
• Maximum number of files per folder: 255
●MP3 and WMA files
MP3 (MPEG Audio LAYER 3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size using
MP3 compression.
WMA (Windows Media Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3
format.
There is a limit to the MP3 and WMA file standards that can be used and
to the media/formats on which the files are recorded.
384
VERSO_EE_OM64517E
3-2. Using the audio system
●MP3 file compatibility
• Compatible standards
MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III,
MPEG2.5)
• Compatible sampling frequencies
MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz)
MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz)
MPEG2.5: 8, 11.025, 12 (kHz)
• Compatible bit rates (compatible with VBR)
MPEG1 AUDIO LAYERII, III: 32-320 (kbps)
MPEG2 AUDIO LAYERII, III: 32-160 (kbps)
MPEG2.5: 32-160 (kbps)
• Compatible channel modes: stereo, joint stereo, dual channel and
monaural
●WMA file compatibility
3
• Compatible standards
WMA Ver. 9
• Compatible sampling frequencies
HIGH PROFILE 32, 44.1, 48 (kHz)
• Compatible bit rates
HIGH PROFILE 32-320 (kbps, VBR)
●File names
The only files that can be recognized as MP3/WMA and played are those
with the extension .mp3 or .wma.
●ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title, artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3
tags. (The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.
385
VERSO_EE_OM64517E
3-2. Using the audio system
●MP3 and WMA playback
• When a device containing MP3 or WMA files is connected, all files in
the USB memory are checked. Once the file check is finished, the first
MP3 or WMA file is played. To make the file check finish more quickly,
we recommend that you do not include any files other than MP3 or
WMA files or create any unnecessary folders.
• When the USB memory is connected and the audio source is changed
to USB memory mode, the USB memory will start playing the first file in
the first folder. If the same device is removed and reinserted (and the
contents have not been changed), the USB memory will resume play
from the same point in which it was last used.
●Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be skipped (not played).
●Playback
• To play MP3 files with steady sound quality, we recommend a fixed bit
rate of at least 128 kbps and a sampling frequency of 44.1 kHz.
• There is a wide variety of freeware and other encoding software for
MP3 and WMA files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at
all.
• Microsoft, Windows, and Windows Media are registered trademarks of
Microsoft Corporation in the U.S.A. and other countries.
WARNING
■ Caution while driving
Do not connect USB memory or operate the controls. Doing so may cause
an accident, resulting in death or serious injury.
386
VERSO_EE_OM64517E
3-2. Using the audio system
NOTICE
■ To prevent damage to USB memory or its terminal
●Do not leave USB memory in the vehicle. The temperature inside the vehi-
cle may become high, resulting in damage to the USB memory.
●Do not push down on or apply unnecessary pressure to the USB memory
while it is connected as this may damage the USB memory or its terminal.
●Do not insert foreign objects into the port as this may damage the USB
memory or its terminal.
●Depending on the size and shape of the USB memory that is connected to
the system, the passenger’s seat may hit the USB memory when moving
the seat forward. In this case, do not forcibly move the seat forward as this
may damage the USB memory or the terminal, etc.
3
387
VERSO_EE_OM64517E
3-2. Using the audio system
Optimal use of the audio system
Displays the current mode
Changes the following set-
tings
• Sound quality and vol-
ume balance (P. 389)
The sound quality and bal-
ance setting can be
changed to produce the
best sound.
• Automatic Sound Level-
izer on/off (P. 389)
Selecting the mode
Using the audio control function
■ Changing sound quality modes
Press
Turn
to select “Sound Setting”.
Press
Turn
as corresponds to the desired mode.
“BASS”,“TREBLE”,“FADER”,“BALANCE”, or“ASL”
Press
: If equipped
388
VERSO_EE_OM64517E
3-2. Using the audio system
■ Adjusting sound quality
Turning
adjusts the level.
Sound
Mode
Turn to the
Turn to the
Level
quality mode
displayed
left
right
Bass*
“BASS”
-5 to 5
Low
High
Treble*
“TREBLE”
-5 to 5
Front/rear
Shifts to
volume
“FADER”
R7 to F7
Shifts to rear
front
balance
Left/right
Shifts to
3
volume
“BALANCE”
L7 to R7
Shifts to left
right
balance
*: The sound quality level is adjusted individually in each audio mode.
■ Adjusting the Automatic Sound Levelizer (ASL)
When ASL is selected, turning
to the right changes the
amount of ASL in the order of LOW, MID and HIGH.
Turning
to the left turns ASL off.
ASL automatically adjusts the volume and tone quality according to vehi-
cle speed.
389
VERSO_EE_OM64517E
3-2. Using the audio system
Using the AUX port
This port can be used to connect a portable audio device and listen
to it through the vehicle’s speakers.
Open the cover and connect
the portable audio device.
Press
until “AUX” is displayed.
■ Operating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle’s audio controls. All other
adjustments must be made on the portable audio device itself.
■ When using a portable audio device connected to the power outlet
Noise may occur during playback. Use the power source of the portable
audio device.
: If equipped
390
VERSO_EE_OM64517E
