Toyota Verso (2017 year). Instruction - part 24
3-2. Using the audio system
Using the steering wheel audio switches
Some audio features can be controlled using the switches on the
steering wheel.
Volume
Radio mode: Select radio
stations
CD mode: Select tracks and
files (MP3 and WMA)
iPod mode: Selects a song
USB memory mode:
Selects a file and folder
3
Power on, select audio
source
Turning on the power
Press
when the audio system is turned off.
Changing the audio source
Press
when the audio system is turned on. The audio source
changes as follows each time
is pressed. If a mode cannot be
used, it will be skipped.
AMFMCD modeiPod or USB memory*AUX*
*: If equipped
391
VERSO_EE_OM64517E
3-2. Using the audio system
Adjusting the volume
Press “+” on
to increase the volume and “-” to decrease the vol-
ume.
Hold down “+” or “-” on
to continue increasing or decreasing the vol-
ume.
Silencing a sound
Press and hold
To cancel, press and hold
again.
Selecting a radio station
Press
to select the radio mode.
Press “” or “” on
to select a preset station.
To scan for receivable stations, press and hold “” or “” on
until
you hear a beep.
Selecting a track/file or song
Press
to select the CD, iPod or USB memory mode.
Press “” or “” on
to select the desired track/file or song.
Selecting a folder (MP3 and WMA or USB memory)
Press
to select the CD or USB memory mode.
Press and hold “” or “” on
until you hear a beep.
392
VERSO_EE_OM64517E
3-2. Using the audio system
WARNING
■ To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
3
393
VERSO_EE_OM64517E
3-3. Using the interior lights
Interior lights list
Personal/interior lights (P. 395, 396)
Foot lights
Front door courtesy lights (if equipped)
394
VERSO_EE_OM64517E
3-3. Using the interior lights
Personal/interior lights main switch
Personal/interior lights main switch
Off
The personal/interior lights can
be individually turned on or off.
Door position
When neither of the main
switches ( or
) is pressed:
The personal/interior lights come
on when a door is opened. They
turn off when the doors are
closed. The personal/interior
3
lights can be individually turned
on when the doors are closed.
On
The personal/interior lights can-
not be individually turned off.
395
VERSO_EE_OM64517E
3-3. Using the interior lights
Personal/interior lights
Personal/interior lights
Front
On/off
Rear
On/off
396
VERSO_EE_OM64517E
3-3. Using the interior lights
Personal/interior lights
■ Illuminated entry system
Vehicles without smart entry & start system
The lights automatically turn on/off according to the engine switch posi-
tion, whether the doors are locked/unlocked, and whether the doors are
open/closed.
Vehicles with smart entry & start system
The lights automatically turn on/off according to “ENGINE START STOP”
switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are open/closed.
■ To prevent battery discharge
Vehicles without smart entry & start system
If the interior lights remain on when the engine switch is turned off, the
3
lights will go off automatically after 20 minutes.
Vehicles with smart entry & start system
If the interior lights remain on when the “ENGINE START STOP” switch
is turned off, the lights will go off automatically after 20 minutes.
■ Customization that can be configured at any authorized Toyota dealer
or repairer, or another duly qualified and equipped professional
Settings (e.g. The time elapsed before lights turn off) can be changed.
(Customizable features P. 646)
397
VERSO_EE_OM64517E
3-4. Using the storage features
List of storage features
Overhead console
Auxiliary boxes*
Glove box
Bottle holders
Cup holders
Console box
*: The emergency tire puncture repair kit is stowed in auxiliary box behind
the front passenger seat. (P. 584) (if equipped)
398
VERSO_EE_OM64517E
3-4. Using the storage features
WARNING
■ Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may result in the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
3
399
VERSO_EE_OM64517E
3-4. Using the storage features
Glove box
Glove box
Glove box without lock function
Pull up the lever to open the
glove box.
Glove box with lock function
Pull up the lever to open the glove box.
The glove box can be locked and unlocked by using the key (vehi-
cles without smart entry & start system) or the mechanical key
(vehicles with smart entry & start system).
Unlock
Lock
Open
■ Glove box light
The glove box light turns on when the tail lights are on.
400
VERSO_EE_OM64517E
3-4. Using the storage features
Glove box and console box
WARNING
■ Caution while driving
Keep the glove box closed. In the event of sudden braking or sudden swerv-
ing, an accident may occur due to an occupant being struck by the open
glove box or the items stored inside.
Console box
Type A
3
Type B
Lift the lid to open.
401
VERSO_EE_OM64517E
3-4. Using the storage features
Console box
■ Tray in the console box
The tray can be removed and used as a
separator.
WARNING
■ Caution while driving (type B)
Keep the console box closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by the
open console box or the items stored inside.
402
VERSO_EE_OM64517E
3-4. Using the storage features
Overhead console and cup holders
Overhead console
Press the lid to open.
The overhead console is useful
for temporarily storing small
items.
WARNING
3
■ Caution while driving
Do not leave the overhead console open. Items stored in it may fall out and
cause injury.
Cup holders
Type A
403
VERSO_EE_OM64517E
3-4. Using the storage features
Cup holders
Type B (if equipped)
Type C
WARNING
■ Items unsuitable for the cup holder
Do not place anything other than cups or beverage cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent burns.
404
VERSO_EE_OM64517E
3-4. Using the storage features
Bottle holders
Bottle holders
Front
Rear
3
WARNING
■ Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury.
NOTICE
■ Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.
405
VERSO_EE_OM64517E
3-4. Using the storage features
Auxiliary boxes
Auxiliary boxes
Type A
Press the button to open the lid.
Type B for passenger side (if equipped)
Lift the tray and pull it forward.
Type C
Pull the strap to open the lid.
406
VERSO_EE_OM64517E
3-4. Using the storage features
Auxiliary boxes
■ Using the auxiliary box vent (if equipped)
Air from the air conditioner can be distrib-
uted into the auxiliary box by opening and
closing the vent.
Open
Close
The air is conditioned the same as the air
for the passenger side vent.
Perishable items should not be put in the
box.
■ Space expansion for auxiliary box (type C) (vehicles loaded with the
emergency tire puncture repair kit)
3
The emergency tire puncture repair kit
can be attached to the luggage compart-
ment carpet using the hook and loop fas-
tener.
Hook and loop fastener
WARNING
■ Caution while driving
Keep the auxiliary boxes closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by an
open auxiliary box or the items stored inside.
407
VERSO_EE_OM64517E
