(a) Check the SRS warning light

37. INSPECT FOR EXHAUST GAS LEAK

(a) If gas is leaking, tighten the areas necessary to stop the leak. Replace damaged parts as necessary.

PARKING BRAKE: PARKING BRAKE CABLE: INSTALLATION; 20...

Last Modified: 9-16-2014

6.6 A

Doc ID: RM000001ED900KX

Model Year: 2015

Model: Tundra

Prod Date Range: [08/2014 - ]

Title: PARKING BRAKE: PARKING BRAKE PEDAL: REMOVAL; 2015 MY Tundra [08/2014 - ]

REMOVAL

1. PRECAUTION

NOTICE:

After turning the ignition switch off, waiting time may be required before disconnecting the cable from the

battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal
notice before proceeding with work

2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL

CAUTION:

Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the

SRS system.

3. RELEASE PARKING BRAKE PEDAL

4. REMOVE LOWER NO. 1 INSTRUMENT PANEL AIRBAG ASSEMBLY

5. DISCONNECT NO. 1 PARKING BRAKE CABLE ASSEMBLY

(a) Remove the lock nut and adjustment nut.

(b) Remove the clip.

PARKING BRAKE: PARKING BRAKE PEDAL: REMOVAL; 2015 M...

NOTICE:

Be careful not to damage the No. 1 parking brake cable or claw.

(d) Disconnect the parking brake cable from the parking brake control pedal.

6. REMOVE PARKING BRAKE CONTROL PEDAL ASSEMBLY

(a) Disconnect the connector.

(b) Detach the wire harness clamp from the control pedal.

body.

PARKING BRAKE: PARKING BRAKE PEDAL: REMOVAL; 2015 M...

Last Modified: 9-16-2014

6.6 A

Doc ID: RM000001EDA00JX

Model Year: 2015

Model: Tundra

Prod Date Range: [08/2014 - ]

Title: PARKING BRAKE: PARKING BRAKE PEDAL: DISASSEMBLY; 2015 MY Tundra [08/2014 - ]

DISASSEMBLY

1. REMOVE PARKING BRAKE SWITCH ASSEMBLY

(a) Remove the screw and switch.

PARKING BRAKE: PARKING BRAKE PEDAL: DISASSEMBLY; 20...
