Toyota Tundra (2015 year). Manual - part 2826
(b) Temporarily install the spring with the bolt, washer and nut to
the front side.
4. INSTALL REAR SPRING BUMPER SUB-ASSEMBLY
(a) Install the spring bumper.
NOTICE:
Align the leaf spring center bolt and nut with the installation hole
(a) Temporarily install the spring seat and 2 U bolts with the 4
washers and 4 nuts.
NOTICE:
(a) Connect the parking brake cable to the vehicle with the 3 bolts.
Torque:
for Bolt A -
19 N·m {194 kgf·cm, 14ft·lbf}
for Bolt B -
14 N·m {138 kgf·cm, 10ft·lbf}
7. STABILIZE SUSPENSION
8. TIGHTEN REAR SPRING ASSEMBLY LH
(a) Tighten the 3 nuts.
Torque:
105 N·m {1071 kgf·cm, 77ft·lbf}
9. TIGHTEN REAR SPRING U BOLT
(a) Tighten the 4 nuts.
Torque:
SUSPENSION: REAR LEAF SPRING: INSTALLATION; 2015 MY Tu...
