Toyota Tundra (2015 year). Manual - part 1494

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0500

Vehicle Speed Sensor "A"

Comes on

DTC

stored

P0504

Brake Switch "A" / "B" Correlation

-

DTC

stored

P0505

Idle Control System Malfunction

Comes on

DTC

stored

P050A

Cold Start Idle Air Control System Performance

Comes on

DTC

stored

P050B

Cold Start Ignition Timing Performance

Comes on

DTC

stored

P0550

Power Steering Pressure Sensor Circuit Malfunction

Comes on

DTC

stored

P0552

Power Steering Pressure Sensor Circuit Low Input

Comes on

DTC

stored

P0553

Power Steering Pressure Sensor Circuit High Input

Comes on

DTC

stored

P0560

System Voltage

Comes on

DTC

stored

P0604

Random Access Memory (RAM)

Comes on

DTC

stored

P0606

ECM / PCM Processor

Comes on

DTC

stored

P0607

Control Module Performance

Comes on

DTC

stored

P060A

Internal Control Module Monitoring Processor Performance

Comes on

DTC

stored

P060B

Internal Control Module A/D Processing Performance

Comes on

DTC

stored

P060D

Internal Control Module Accelerator Pedal Position

Performance

Comes on

DTC

stored

P060E

Internal Control Module Throttle Position Performance

Comes on

DTC

stored

P0617

Starter Relay Circuit High

Comes on

DTC

stored

P062F

Internal Control Module EEPROM Error

Comes on

DTC

stored

P0630

VIN not Programmed or Mismatch - ECM / PCM

Comes on

DTC

stored

P0657

Actuator Supply Voltage Circuit / Open

Comes on

DTC

stored

P0724

Brake Switch "B" Circuit High

Comes on

DTC

stored

P101D

A/F Sensor Heater Circuit Performance Bank 1 Sensor 1

Stuck ON

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P102D

O2 Sensor Heater Circuit Performance Bank 1 Sensor 2 Stuck

ON

Comes on

DTC

stored

P103D

A/F Sensor Heater Circuit Performance Bank 2 Sensor 1

Stuck ON

Comes on

DTC

stored

P105D

O2 Sensor Heater Circuit Performance Bank 2 Sensor 2 Stuck

ON

Comes on

DTC

stored

P106B

Evaporative Emission System Pressure Sensor - Secondary

Air Injection Pressure Sensor Correlation

Comes on

DTC

stored

P109C

Open in Fuel Pressure Switching Valve Circuit

-

DTC

stored

P109D

Short in Fuel Pressure Switching Valve Circuit

-

DTC

stored

P1340

Camshaft Position Sensor "A" (Bank 1 Sensor 2)

Comes on

DTC

stored

P1342

Camshaft Position Sensor "A" Low Input (MRE)

Comes on

DTC

stored

P1343

Camshaft Position Sensor "A" High Input (MRE)

Comes on

DTC

stored

P144C

Open in Secondary Air Injection System Heater Control

Circuit

Comes on

DTC

stored

P144D

Short in Secondary Air Injection System Heater Control

Circuit

Comes on

DTC

stored

P1603

Engine Stall History

-

DTC

stored

P1604

Startability Malfunction

-

DTC

stored

P1605

Rough Idling

-

DTC

stored

P1607

Cruise Control Input Processor

Comes on

DTC

stored

P1613

Secondary Air Injection Driver Malfunction

Comes on

DTC

stored

P1614

Secondary Air Injection System Driver Bank 2

Comes on

DTC

stored

P2102

Throttle Actuator Control Motor Circuit Low

Comes on

DTC

stored

P2103

Throttle Actuator Control Motor Circuit High

Comes on

DTC

stored

P2109

Throttle / Pedal Position Sensor "A" Minimum Stop

Performance

-

DTC

stored

P2111

Throttle Actuator Control System - Stuck Open

Comes on

DTC

stored

P2112

Throttle Actuator Control System - Stuck Closed

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P2118

Throttle Actuator Control Motor Current Range / Performance Comes on

DTC

stored

P2119

Throttle Actuator Control Throttle Body Range / Performance

Comes on

DTC

stored

P2120

Throttle / Pedal Position Sensor / Switch "D" Circuit

Comes on

DTC

stored

P2121

Throttle / Pedal Position Sensor / Switch "D" Circuit Range /

Performance

Comes on

DTC

stored

P2122

Throttle / Pedal Position Sensor / Switch "D" Circuit Low

Input

Comes on

DTC

stored

P2123

Throttle / Pedal Position Sensor / Switch "D" Circuit High

Input

Comes on

DTC

stored

P2125

Throttle / Pedal Position Sensor / Switch "E" Circuit

Comes on

DTC

stored

P2127

Throttle / Pedal Position Sensor / Switch "E" Circuit Low Input Comes on

DTC

stored

P2128

Throttle / Pedal Position Sensor / Switch "E" Circuit High

Input

Comes on

DTC

stored

P2135

Throttle / Pedal Position Sensor / Switch "A" / "B" Voltage

Correlation

Comes on

DTC

stored

P2138

Throttle / Pedal Position Sensor / Switch "D" / "E" Voltage

Correlation

Comes on

DTC

stored

P2195

Oxygen (A/F) Sensor Signal Stuck Lean (Bank 1 Sensor 1)

Comes on

DTC

stored

P2196

Oxygen (A/F) Sensor Signal Stuck Rich (Bank 1 Sensor 1)

Comes on

DTC

stored

P2197

Oxygen (A/F) Sensor Signal Stuck Lean (Bank 2 Sensor 1)

Comes on

DTC

stored

P2198

Oxygen (A/F) Sensor Signal Stuck Rich (Bank 2 Sensor 1)

Comes on

DTC

stored

P2237

Oxygen (A/F) Sensor Pumping Current Circuit / Open (Bank 1

Sensor 1)

Comes on

DTC

stored

P2238

Oxygen (A/F) Sensor Pumping Current Circuit Low (Bank 1

Sensor 1)

Comes on

DTC

stored

P2239

Oxygen (A/F) Sensor Pumping Current Circuit High (Bank 1

Sensor 1)

Comes on

DTC

stored

P2240

Oxygen (A/F) Sensor Pumping Current Circuit / Open (Bank 2

Sensor 1)

Comes on

DTC

stored

P2241

Oxygen (A/F) Sensor Pumping Current Circuit Low (Bank 2

Sensor 1)

Comes on

DTC

stored

P2242

Oxygen (A/F) Sensor Pumping Current Circuit High (Bank 2

Sensor 1)

Comes on

DTC

stored

P2252

Oxygen (A/F) Sensor Reference Ground Circuit Low (Bank 1

Sensor 1)

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P2253

Oxygen (A/F) Sensor Reference Ground Circuit High (Bank 1

Sensor 1)

Comes on

DTC

stored

P2255

Oxygen (A/F) Sensor Reference Ground Circuit Low (Bank 2

Sensor 1)

Comes on

DTC

stored

P2256

Oxygen (A/F) Sensor Reference Ground Circuit High (Bank 2

Sensor 1)

Comes on

DTC

stored

P2401

Evaporative Emission Leak Detection Pump Stuck OFF

Comes on

DTC

stored

P2402

Evaporative Emission Leak Detection Pump Stuck ON

Comes on

DTC

stored

P2419

Evaporative Emission System Switching Valve Control Circuit

Low

Comes on

DTC

stored

P2420

Evaporative Emission System Switching Valve Control Circuit

High

Comes on

DTC

stored

P2431

Secondary Air Injection System Air Flow / Pressure Sensor

Circuit Range / Performance Bank1

Comes on

DTC

stored

P2432

Secondary Air Injection System Air Flow / Pressure Sensor

Circuit Low Bank1

Comes on

DTC

stored

P2433

Secondary Air Injection System Air Flow / Pressure Sensor

Circuit High Bank1

Comes on

DTC

stored

P2436

Secondary Air Injection System Air Flow / Pressure Sensor

Circuit Range / Performance Bank 2

Comes on

DTC

stored

P2437

Secondary Air Injection System Air Flow / Pressure Sensor

Circuit Low Bank 2

Comes on

DTC

stored

P2438

Secondary Air Injection System Air Flow / Pressure Sensor

Circuit High Bank 2

Comes on

DTC

stored

P2440

Secondary Air Injection System Switching Valve Stuck Open

Bank1

Comes on

DTC

stored

P2441

Secondary Air Injection System Switching Valve Stuck Close

Bank1

Comes on

DTC

stored

P2442

Secondary Air Injection System Switching Valve Stuck Open

Bank 2

Comes on

DTC

stored

P2443

Secondary Air Injection System Switching Valve Stuck Closed

Bank 2

Comes on

DTC

stored

P2444

Secondary Air Injection System Pump Stuck On Bank1

Comes on

DTC

stored

P2445

Secondary Air Injection System Pump Stuck Off Bank1

Comes on

DTC

stored

P2446

Secondary Air Injection System Pump Stuck On Bank 2

Comes on

DTC

stored

P2447

Secondary Air Injection System Pump Stuck Off Bank 2

Comes on

DTC

stored

P2610

ECM / PCM Internal Engine Off Timer Performance

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...
