Toyota Tundra (2015 year). Manual - part 1493

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0122

Throttle / Pedal Position Sensor / Switch "A" Circuit Low

Input

Comes on

DTC

stored

P0123

Throttle / Pedal Position Sensor / Switch "A" Circuit High

Input

Comes on

DTC

stored

P0125

Insufficient Coolant Temperature for Closed Loop Fuel

Control

Comes on

DTC

stored

P0128

Coolant Thermostat (Coolant Temperature Below Thermostat

Regulating Temperature)

Comes on

DTC

stored

P0136

Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2)

Comes on

DTC

stored

P0137

Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2)

Comes on

DTC

stored

P0138

Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2)

Comes on

DTC

stored

P0139

Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)

Comes on

DTC

stored

P0141

Oxygen Sensor Heater Circuit Malfunction (Bank 1 Sensor 2)

Comes on

DTC

stored

P014C

A/F Sensor Slow Response - Rich to Lean Bank 1 Sensor 1

Comes on

DTC

stored

P014D

A/F Sensor Slow Response - Lean to Rich Bank 1 Sensor 1

Comes on

DTC

stored

P014E

A/F Sensor Slow Response - Rich to Lean Bank 2 Sensor 1

Comes on

DTC

stored

P014F

A/F Sensor Slow Response - Lean to Rich Bank 2 Sensor 1

Comes on

DTC

stored

P0156

Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2)

Comes on

DTC

stored

P0157

Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2)

Comes on

DTC

stored

P0158

Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2)

Comes on

DTC

stored

P0159

Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)

Comes on

DTC

stored

P015A

A/F Sensor Delayed Response - Rich to Lean Bank 1 Sensor 1 Comes on

DTC

stored

P015B

A/F Sensor Delayed Response - Lean to Rich Bank 1 Sensor 1 Comes on

DTC

stored

P015C

A/F Sensor Delayed Response - Rich to Lean Bank 2 Sensor 1 Comes on

DTC

stored

P015D

A/F Sensor Delayed Response - Lean to Rich Bank 2 Sensor 1 Comes on

DTC

stored

P0161

Oxygen Sensor Heater Circuit Malfunction (Bank 2 Sensor 2)

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0171

System Too Lean (Bank 1)

Comes on

DTC

stored

P0172

System Too Rich (Bank 1)

Comes on

DTC

stored

P0174

System Too Lean (Bank 2)

Comes on

DTC

stored

P0175

System Too Rich (Bank 2)

Comes on

DTC

stored

P0220

Throttle / Pedal Position Sensor / Switch "B" Circuit

Comes on

DTC

stored

P0222

Throttle / Pedal Position Sensor / Switch "B" Circuit Low

Input

Comes on

DTC

stored

P0223

Throttle / Pedal Position Sensor / Switch "B" Circuit High

Input

Comes on

DTC

stored

P0230

Fuel Pump Primary Circuit

-

DTC

stored

P0300

Random / Multiple Cylinder Misfire Detected

Comes

on/blinks*1

DTC

stored

P0301

Cylinder 1 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0302

Cylinder 2 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0303

Cylinder 3 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0304

Cylinder 4 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0305

Cylinder 5 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0306

Cylinder 6 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0307

Cylinder 7 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0308

Cylinder 8 Misfire Detected

Comes

on/blinks*1

DTC

stored

P0327

Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor)

Comes on

DTC

stored

P0328

Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)

Comes on

DTC

stored

P032C

Knock Sensor 3 Circuit Low

Comes on

DTC

stored

P032D

Knock Sensor 3 Circuit High

Comes on

DTC

stored

P0332

Knock Sensor 2 Circuit Low Input (Bank 2)

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0333

Knock Sensor 2 Circuit High Input (Bank 2)

Comes on

DTC

stored

P0335

Crankshaft Position Sensor "A" Circuit

Comes on

DTC

stored

P0337

Crankshaft Position Sensor "A" Circuit Low Input

Comes on

DTC

stored

P0338

Crankshaft Position Sensor "A" Circuit High Input

Comes on

DTC

stored

P0339

Crankshaft Position Sensor "A" Circuit Intermittent

-

DTC

stored

P033C

Knock Sensor 4 Circuit Low Input

Comes on

DTC

stored

P033D

Knock Sensor 4 Circuit High Input

Comes on

DTC

stored

P0340

Camshaft Position Sensor Circuit Malfunction

Comes on

DTC

stored

P0342

Camshaft Position Sensor "A" Circuit Low Input (Bank 1 or

Single Sensor)

Comes on

DTC

stored

P0343

Camshaft Position Sensor "A" Circuit High Input (Bank 1 or

Single Sensor)

Comes on

DTC

stored

P0345

Camshaft Position Sensor "A" Circuit (Bank 2)

Comes on

DTC

stored

P0347

Camshaft Position Sensor "A" Circuit Low Input (Bank 2)

Comes on

DTC

stored

P0348

Camshaft Position Sensor "A" Circuit High Input (Bank 2)

Comes on

DTC

stored

P0351

Ignition Coil "A" Primary / Secondary Circuit

Comes on

DTC

stored

P0352

Ignition Coil "B" Primary / Secondary Circuit

Comes on

DTC

stored

P0353

Ignition Coil "C" Primary / Secondary Circuit

Comes on

DTC

stored

P0354

Ignition Coil "D" Primary / Secondary Circuit

Comes on

DTC

stored

P0355

Ignition Coil "E" Primary / Secondary Circuit

Comes on

DTC

stored

P0356

Ignition Coil "F" Primary / Secondary Circuit

Comes on

DTC

stored

P0357

Ignition Coil "G" Primary / Secondary Circuit

Comes on

DTC

stored

P0358

Ignition Coil "H" Primary / Secondary Circuit

Comes on

DTC

stored

P0365

Camshaft Position Sensor "B" Circuit (Bank 1)

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0367

Camshaft Position Sensor "B" Circuit Low Input (Bank 1)

Comes on

DTC

stored

P0368

Camshaft Position Sensor "B" Circuit High Input (Bank 1)

Comes on

DTC

stored

P0390

Camshaft Position Sensor "B" Circuit (Bank 2)

Comes on

DTC

stored

P0392

Camshaft Position Sensor "B" Circuit Low Input (Bank 2)

Comes on

DTC

stored

P0393

Camshaft Position Sensor "B" Circuit High Input (Bank 2)

Comes on

DTC

stored

P0412

Secondary Air Injection System Switching Valve "A" Circuit

Comes on

DTC

stored

P0415

Secondary Air Injection System Switching Valve "B" Circuit

Comes on

DTC

stored

P0418

Secondary Air Injection System Control "A" Circuit

Comes on

DTC

stored

P0419

Secondary Air Injection System Control "B" Circuit

Comes on

DTC

stored

P0420

Catalyst System Efficiency Below Threshold (Bank 1)

Comes on

DTC

stored

P0430

Catalyst System Efficiency Below Threshold (Bank 2)

Comes on

DTC

stored

P043E

Evaporative Emission System Leak Detection Reference

Orifice Low Flow

Comes on

DTC

stored

P043F

Evaporative Emission System Reference Orifice High Flow

Comes on

DTC

stored

P0441

Evaporative Emission Control System Incorrect Purge Flow

Comes on

DTC

stored

P0451

Evaporative Emission Control System Pressure Sensor Range

/ Performance

Comes on

DTC

stored

P0452

Evaporative Emission Control System Pressure Sensor /

Switch Low Input

Comes on

DTC

stored

P0453

Evaporative Emission Control System Pressure Sensor /

Switch High Input

Comes on

DTC

stored

P0455

Evaporative Emission Control System Leak Detected (Gross

Leak)

Comes on

DTC

stored

P0456

Evaporative Emission Control System Leak Detected (Very

Small Leak)

Comes on

DTC

stored

P0461

Fuel Level Sensor "A" Circuit Range / Performance

Comes on

DTC

stored

P0462

Fuel Level Sensor "A" Circuit Low

Comes on

DTC

stored

P0463

Fuel Level Sensor "A" Circuit High

Comes on

DTC

stored

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOST...
