Toyota Tundra (2015 year). Manual - part 1448
Push
Push the vent line hose into the port and push the retainer to lock it.
NOTICE:
Check for damage or foreign objects on the connected part.
After connecting the vent line hose, check that the vent line hose and valve are
securely connected by pulling on them.
1.
(4) Connect the air inlet line hose.
NOTICE:
Check for damage or foreign objects on the connected part.
After connecting the air inlet line hose, check that the air inlet line hose and valve are securely
connected by pulling on them.
(5) Connect the purge line hose.
(6) Connect the canister pump module connector.
(7) Connect the wiring harness clamp bracket with the nut.
Torque:
10 N·m {102 kgf·cm, 7ft·lbf}
3UR-FBE EMISSION CONTROL: CANISTER: INSTALLATION; 20...
