632

9-1. Specifications

X

1GD-FTV and 2GD-FTV engines (for EURO V and VI models

*

1

)

*

1

: EURO V and VI are emission standards. If it is not clear that your vehicle

meets relevant standards, contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.

*

2

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota
recommends the use of approved “Toyota Genuine Motor Oil”.
Another motor oil of matching quality can also be used.
Oil grade: ACEA C2

Oil capacity
(Drain and refill

 

reference

*

2

)

With filter
Without filter

7.5 L (7.9 qt., 6.6 Imp.qt.)
7.0 L (7.4 qt., 6.2 Imp.qt.)

NOTICE

Using engine oil other than ACEA C2 may damage the catalytic converter.

633

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

Recommended viscosity (SAE):
SAE 0W-30 is filled into your
Toyota vehicle at manufactur-
ing, and the best choice for
good fuel economy and good
starting in cold weather.

Oil viscosity (0W-30 is explained here as an example):

• The 0W in 0W-30 indicates the characteristic of the oil which

allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.

• The 30 in 0W-30 indicates the viscosity characteristic of the oil

when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.

Temperature range anticipated
before next oil change

Preferred

634

9-1. Specifications

X

1GD-FTV and 2GD-FTV engines (for EURO IV models

*

1

)

*

1

: EURO IV is an emission standard. If it is not clear that your vehicle meets

relevant standards, contact any authorized Toyota dealer or repairer, or
another duly qualified and equipped professional.

*

2

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat-
isfy the following grade and viscosity.
Oil grade: API CF-4, CF or ACEA B1
Recommended viscosity (SAE):

SAE 5W-30 is the best choice
for good fuel economy and
good starting in cold weather.
If you use SAE 10W-30 or a
higher viscosity engine oil in
extremely low temperatures,
the engine may become difficult
to start, so SAE 5W-30 engine
oil is recommended.
Oil viscosity (5W-30 is explained here as an example):

• The 5W in 5W-30 indicates the characteristic of the oil which

allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.

• The 30 in 5W-30 indicates the viscosity characteristic of the oil

when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.

Oil capacity
(Drain and refill —
reference

*

2

)

With filter
Without filter

7.5 L (7.9 qt., 6.6 Imp.qt.)
7.0 L (7.4 qt., 6.2 Imp.qt.)

Temperature range anticipated
before next oil change

Preferred

635

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

X

2KD-FTV engine

*

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: API CF-4, CF or ACEA B1

(You may also use API CE or CD.)

Recommended viscosity (SAE):

If you use SAE 10W-30 or a
higher viscosity engine oil in
extremely low temperatures,
the engine may become difficult
to start, so SAE 5W-30 engine
oil is recommended.

Oil viscosity (10W-30 is explained here as an example):

• The 10W in 10W-30 indicates the characteristic of the oil which

allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.

• The 30 in 10W-30 indicates the viscosity characteristic of the oil

when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.

Oil capacity
(Drain and refill



reference

*

)

With filter
Without filter

6.9 L (7.3 qt., 6.1 Imp.qt.)
6.6 L (7.0 qt., 5.8 Imp.qt.)

Temperature range anticipated
before next oil change
