Toyota Hilux (2017 year). Manual - part 155

628

9-1. Specifications

X

2TR-FE engine (for EURO IV and V models

*

1

)

*

1

: EURO IV and V are emission standards. If it is not clear that your vehicle

meets relevant standards, contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.

*

2

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade:
0W-20, 5W-20, 5W-30 and 10W-30:
API grade SL “Energy-Conserving”, SM “Energy-Conserving” or SN
“Resource-Conserving”; or ILSAC multigrade engine oil
15W-40:
API grade SL, SM or SN multigrade engine oil

Recommended viscosity (SAE):
If you use SAE 10W-30 or a
higher viscosity engine oil in
extremely low temperatures,
the engine may become difficult
to start, so SAE 0W-20, 5W-20
or 5W-30 engine oil is recom-
mended.

Lubrication system

Oil capacity
(Drain and refill

 Reference

*

2

)

With filter
Without filter

5.6 L (5.9 qt., 4.9 Imp.qt.)
5.3 L (5.6 qt., 4.7 Imp.qt.)

Temperature range anticipated
before next oil change

629

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which

allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil

when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.

How to read oil container labels:
Either or both API registered marks are added to some oil contain-
ers to help you select the oil you should use.

API Service Symbol

Top portion: “API SERVICE SN”
means the oil quality designa-
tion by American Petroleum
Institute (API).
Center portion: “SAE 0W-20”
means the SAE viscosity grade.
Lower portion: “Resource-Con-
serving” means that the oil has
fuel-saving and environmental
protection capabilities.

ILSAC Certification Mark

The International Lubricant Specification Advisory Committee (ILSAC)
Certification Mark is displayed on the front of the container.

1

2

630

9-1. Specifications

X

2TR-FE engine (except for EURO IV and V models

*

1

)

*

1

: EURO IV and V are emission standards. If it is not clear that your vehicle

meets relevant standards, contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.

*

2

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade:
0W-20, 5W-20, 5W-30 and 10W-30:
API grade SL “Energy-Conserving”, SM “Energy-Conserving” or SN
“Resource-Conserving”; or ILSAC multigrade engine oil
15W-40 and 20W-50:
API grade SL, SM or SN multigrade engine oil

Recommended viscosity (SAE):

If you use SAE 10W-30 or a
higher viscosity engine oil in
extremely low temperatures,
the engine may become difficult
to start, so SAE 0W-20, 5W-20
or 5W-30 engine oil is recom-
mended.

Oil capacity
(Drain and refill

 Reference

*

2

)

With filter
Without filter

5.6 L (5.9 qt., 4.9 Imp.qt.)
5.3 L (5.6 qt., 4.7 Imp.qt.)

Temperature range anticipated
before next oil change

631

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which

allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil

when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.

How to read oil container labels:
Either or both API registered marks are added to some oil contain-
ers to help you select the oil you should use.

API Service Symbol

Top portion: “API SERVICE SN”
means the oil quality designa-
tion by American Petroleum
Institute (API).
Center portion: “SAE 0W-20”
means the SAE viscosity grade.
Lower portion: “Resource-Con-
serving” means that the oil has
fuel-saving and environmental
protection capabilities.

ILSAC Certification Mark

The International Lubricant Specification Advisory Committee (ILSAC)
Certification Mark is displayed on the front of the container.

1

2
