Toyota Hilux (2017 year). Manual - part 154

624

9-1. Specifications

Double-cab models (models
made in South Africa

*

):

This number is also on the
manufacturer’s label.

Models made in Thailand

*

:

This number is also on the
manufacturer’s plate.

Models for model code destina-
tion V

*

:

This number is also on the top
left of the instrument panel.

*

: See “Checking your vehicle’s model” if you are not sure of which model

your vehicle is. (

→P. 11)

625

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

■

Engine number
The engine number is stamped on the engine block as shown.

X

2TR-FE engine

X

2TR-FE engine

X

1GD-FTV and 2GD-FTV
engines

X

2KD-FTV engine

Engine

Model

2TR-FE

Type

4 cylinder in line, 4 cycle, gasoline

Bore and stroke

95.0

×

 95.0 mm (3.74

×

 3.74 in.)

Displacement

2694 cm

3

 (164.4 cu.in.)

Valve clearance

Automatic adjustment

Drive belt tension

Automatic adjustment

626

9-1. Specifications

X

1GD-FTV engine

X

2GD-FTV engine

X

2KD-FTV engine

Model

1GD-FTV

Type

4 cylinder in line, 4 cycle, diesel
(with turbocharger)

Bore and stroke

92.0

×

 103.6 mm (3.62

×

 4.08 in.)

Displacement

2755 cm

3

 (168.1 cu.in.)

Valve clearance

Automatic adjustment

Drive belt tension

Automatic adjustment

Model

2GD-FTV

Type

4 cylinder in line, 4 cycle, diesel
(with turbocharger)

Bore and stroke

92.0

×

 90.0 mm (3.62

×

 3.54 in.)

Displacement

2393 cm

3

 (146.0 cu.in.)

Valve clearance

Automatic adjustment

Drive belt tension

Automatic adjustment

Model

2KD-FTV

Type

4 cylinder in line, 4 cycle, diesel
(with turbocharger)

Bore and stroke

92.0

×

 93.8 mm (3.62

×

 3.69 in.)

Displacement

2494 cm

3

 (152.2 cu.in.)

Valve clearance
(engine cold)

Intake: 0.20

 0.30 mm (0.008  0.012 in.)

Exhaust: 0.35

 0.45 mm (0.014  0.018 in.)

Drive belt tension

Automatic adjustment

627

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

X

Gasoline engine

X

Diesel engine

Fuel

Fuel type

Unleaded gasoline only

Research Octane
Number

91 or higher

Fuel tank capacity
(Reference)

80 L (21.1 gal., 17.6 Imp.gal.)

Fuel type

X

EU area

Diesel fuel conforming to European standard
EN590

X

Except EU area (except Russia)

Diesel fuel only

X

Except EU area (Russia)

Diesel fuel confirming to GOST R52368-2005

Cetane number

48 or higher

Fuel tank capacity
(Reference)

80 L (21.1 gal., 17.6 Imp.gal.)
