636

9-1. Specifications

*

: EURO IV, V and VI are emission standards. If it is not clear that your vehi-

cle meets relevant standards, contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.

Cooling system

Capacity

2TR-FE engine

X

With automatic transmission

8.1 L (8.6 qt., 7.1 Imp.qt.)

X

With manual transmission

7.8 L (8.2 qt., 6.9 Imp.qt.)

1GD-FTV
and
2GD-FTV
engines

EURO IV
models

*

X

Without power heater

8.6 L (9.1 qt., 7.6 Imp.qt.)

X

With power heater

8.9 L (9.4 qt., 7.8 Imp.qt.)

EURO V
models

*

X

With automatic transmission

9.6 L (10.1 qt., 8.4 Imp.qt.)

X

With manual transmission

9.1 L (9.6 qt., 8.0 Imp.qt.)

EURO VI
models

*

X

With automatic transmission

9.7 L (10.3 qt., 8.5 Imp.qt.)

X

With manual transmission

9.2 L (9.7 qt., 8.1 Imp.qt.)

2KD-FTV engine

9.8 L (10.4 qt., 8.6 Imp.qt.)

Coolant type

Use either of the following:

• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene gly-

col-based non-silicate, non-amine,
non-nitrite, and non-borate coolant
with long-life hybrid organic acid
technology

Do not use plain water alone.

637

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

Ignition system (gasoline engine)

Spark plug

Make

DENSO FK20HR-A8

Gap

0.8 mm (0.031 in.)

NOTICE

■

Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

638

9-1. Specifications

X

Vehicles with maintenance type battery

X

Vehicles with maintenance-free type battery

*

: The fluid capacity is the quantity of reference.

If replacement is necessary, contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.

Electrical system

Battery

Specific gravity reading
at 20

°C (68°F):

1.250

 1.290 Fully charged

1.160

 1.200 Half charged

1.060

 1.100 Discharged

Charging rates

Quick charge
Slow charge

15 A max.
5 A max.

Battery

Open voltage at 20

°C

(68

°F):

12.6

 12.8 V Fully charged

12.2

 12.4 V Half charged

11.8

 12.0 V Discharged)

(Voltage is checked 20 minutes after the engine
and all the lights are turned off.)

Charging rates

5 A max.

Automatic transmission

Fluid
capacity

*

Gasoline engine

8.5 L (9.0 qt., 7.5 Imp.qt.)

Diesel engine

9.5 L (10.0 qt., 8.4 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Automatic transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of your transmission accompanied
by vibration, and ultimately damage the transmission of your vehicle.

639

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

*

: Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at

the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or
an equivalent oil of matching quality that satisfies the above specifications.
Please contact any authorized Toyota dealer or repairer, or another duly
qualified and equipped professional for further details.

Manual transmission

Oil
capacity

5-speed models

2.2 L (2.3 qt., 1.9 Imp.qt.)

6-speed
models

4WD models

2.5 L (2.6 qt., 2.2 Imp.qt.)

Pre Runner

2.7 L (2.9 qt., 2.4 Imp.qt.)

Oil type

TOYOTA Genuine Manual
Transmission Gear Oil API GL-3
(GL-4) or equivalent

Recommended oil viscosity

Above -10

°C (14°F):

SAE 75W-90, 80W or 80W-90
Below -10

°C (14°F):

SAE 75W-90

NOTICE

■

Manual transmission gear oil
Please be aware that depending on the particular characteristics of the gear
oil used or the operating conditions, idle sound, shift feeling and/or fuel effi-
ciency may be different or affected. Toyota recommends to use “TOYOTA
Genuine Manual Transmission Gear Oil” to achieve optimal performance.

Transfer (4WD models)

Oil capacity

1.0 L (1.1 qt., 0.9 Imp.qt.)

Oil type

*

Toyota Genuine Transfer Gear oil LF or
equivalent

Recommended oil viscosity

SAE 75W
