03-15

7410-00

The front part of the active head restraint is separated and moved forward to protect the occupant's neck

in the event of a rear-end collision.

The active head restraints may be installed to both driver and passenger seats depending on the vehicle

specifications.

(1) System configuration

Active head restraint sensor

Active head restraint

(passenger seat)

Active head restraint

(driver seat)

2) Active Head Restraint

03-16

(2) Active head restraint deployment

No in operation

In operation

03-17

7410-00

(3) Operating process

Driver seat

Passenger seat

For a vehicle with an active head restraint system, an active head restraint sensor is installed and its G

sensor is operated in the event of a rear-end collision. As the G sensor in the active head restraint

sensor is operated, the power is supplied to the driver's or passenger's active head restraint. Then, the

lock in the head restraint is disengaged and the front part of the head restraint is separated and moved

toward the neck of an occupant.

03-18

Head restraint adjustment (Height)

3) Rear Seat

(1) Rear seat operation

The rear seat is a 6:4 split seat and a manual seat that the angle of the head restraint and seatback of the

seat can be adjusted. And the heated wires in the rear seat cushion and seatback can be operated with

rear seat heated wire switches located on the LH/RH rear door trim.

The head restraint can be raised

without pressing the head

restraint sleeve (A) or lowered

with the sleeve (A) pressed.

Seatback reclining adjustment

To adjust the seatback angle,

pull the lock release lever on the

upper part of the seat to release

the lock.
