03-7

7410-00

Head restraint

warning label

Rear seat head restraint

▶

Rear seat head restraint

- Head restraint warning label has been attached to the side of rear seat head restraint.

03-8

Front seat heated wire and ventilation switch

Heated wire

Heated wire and

ventilation

Front seat belt (3-point type)

Front seat and seat switch

1. SEAT/SEAT BELT OVERVIEW

The seat is divided into front seat (driver & passenger) and rear seat.

The front seat has the heated wire in the seat cushion and seatback and the rear seat has it in the seat

cushion. The ventilation function is only applied to the driver seat. The seat belts of all seats are 3-point

type.

2. SEAT/SEAT BELT LAYOUT

Driver seat heated

wire switch

Passenger seat

heated wire switch

Driver seat heated

wire switch

Driver seat

ventilation

switch

Passenger

seat heated

wire switch

03-9

7410-00

Rear seat belt (3-point type)

Rear LH, center

Rear RH

Rear seat

Rear seat heated wire switch

LH

RH

Rear seat belt - LH

Rear center

seat belt

Rear seat

belt - RH

Rear double buckle

- 1st row

Rear buckle -

1st row

03-10

Head restraint adjustment (Height)

To raise the head restraint, pull upward on
the head restraint. To lower the head
restraint, push downward on the head
restraint with the head restraint sleeve (A)
pressed.

Head restraint adjustment (Tilting)

The head restraint can be moved
forward/backward.

3. SEAT ADJUSTMENT AND OPERATION

1) Front Seat

There are 2 types of front seats: a) power seat that uses electric motor to move the seat and adjust the

seatback and seat cushion; b) manual seat that a user has to operate the lever manually to adjust the

seat.

However the head restraint and driver seat lumber support should be adjusted manually for both types of

seats. Heated wire is installed in the seatback and seat cushion, and ventilation function may be added

to driver seat depending on vehicle specifications. The switch for the front seat heated wire and

ventilation is located on the TGS lever side.

The front part of the active head restraint is separated and moved forward to protect the occupant's neck

in the event of a rear-end collision. The active head restraints may be installed to both driver and

passenger seats depending on the vehicle specifications.

Head restraint adjustment

▶
