06-35

8510-00

Steering wheel heating switch

▶

The steering wheel heating switch is mounted to the lower main panel. In that, signal voltage from the

steering wheel heating controller, which is installed in the steering wheel, is grounded. This is used as

an operation signal for the steering wheel heating system. The indicator in the switch comes on when it

is operated.

Steering wheel heating switch

(3) Operation process

06-36

Power seat switch

(1) Power seat switch (Driver side)

4) Power Seat Switch Assembly

Seat sliding

Seatback reclining

Seat height adjustment

A.

B.

C.

Seat sliding

Seatback reclining

Seat height adjustment

Power seat switch

06-37

8510-00

Audio remote control switch (RH)

Audio remote control switch (LH)

1) Audio Remote Control Switch

4. STEERING WHEEL SWITCH

MUTE & MODE switch

Volume UP/DOWN switch

SEEK UP/DOWN switch

Handsfree switch

Tip switch (D+)

Tip switch (D-)

06-38

Tip switch (D-)

Gear change switch

-Change up

SEEK UP/DOWN switch

Volume UP/DOWN switch

Increases/decreases volume

Tip switch (D-)

Gear change switch

-Change down

CD mode

Select next/previous track and

FF/REW

Radio mode

Change frequency UP or DOWN

Press and hold to auto search

-

 -

MUTE & MODE switch

To eliminate the sound (MUTE), briefly
press this switch. To change the audio
mode (Radio-CD-USB-AUX-Radio), press
and hold this switch.

Handsfree switch

To make/receive/end a call,
press and hold this switch.
