SsangYong Korando III (2010 year). Manual - part 203

10-8

1) Audio Control Switch

No.

Name

1 Power/Mute/Pause/Enter/Volume

button

2

Station memory button (1~6) and Audio function button

3

Bluetooth hands-free CALL button

4

Bluetooth hands-free END button

5

Previous (≪) and Next (≫) button

6

SCAN/INFO button

7 BAND/AS

button

8 SETTING

button

9

Display window (LCD)

10 USB/AUX

button

11

Disc Play button

12

Disc Eject button

13 Disc

slot

CDP (MP3) + Bluetooth

▶

10-9

8910-05

No.

Name

1 Display

window

2 RDS

button

3 AF/TA

button

4 SEEK

button

5 CALL

button

6

Disc slot

7 CD/AUX/USB

button

8

POWER button with VOLUME dial

9

Station memory button (1~6)

10 BAND/AST

button

11

SCAN / INFO button with dial

12 EQ/SOUND

button

13 END

button

14

Disc Eject button

CDP (MP3) + RDS + Bluetooth

▶

10-10

If your vehicle has this feature, some audio controls can be adjusted at the steering wheel.

They include the following:

Steering wheel audio switch

MUTE [         ]

Press: to turn the system on, to mute on/off

Press and hold: to turn the system off

MODE
Press: to select the functions (CD → USB → AUX → RADIO)
Press and hold: to select the bands (FM1→ FM2 → MW → LW)
▲VOLUME▼

Press to increase/decrease the volume.
▲SEEK▼

When listening to a station:

Press: to go to the next/previous preset station

Press and hold: to search the next/previous radio station (The radio seeks stations only with a strong

signal that are in the selected band).

When playing a CD or USB:

Press: to go to the next/previous track:

Press and hold to fast forward/backward through the tracks.

▶

▶

▶

▶

PHONE [        ]

During the standby:

Press: to make a call via voice-activated dialing function

Press and hold:  to make a call via last call dialing function

When a call comes in:

Press: to receive the incoming a call

Press and hold: to reject the incoming a call

During a call

Press/Press and hold: to end a call

▶

2) Steering Wheel Audio Switch

01-3

0000-00

1. MAJOR CHANGES

1) Gear Shift Lever and Cable (Manual Transaxle)

Gear shift lever

bracket

Gear shift lever assembly

Old

New

The gear shift lever bracket has been changed to adopt the premium console.

Gear shift cable assembly

Old

New

The connection and socket to lever has been changed.
