10-4

Unit

Description

Specification

USB MP3[WMA]

Frequency response

20Hz ~ 20kHz

Total harmonic distortion

0.1 % (at 1kHz)

Dynamic Range

85dB (at 1kHz)

Signal-to-noise ratio

60dB (at 1kHz)

Channel separation

54dB (at 1kHz)

Micro-pole antenna

Operating current

up to 150 mA

Operating voltage

DC 10.5 ~ 16.0 V

Operating temperature

-30˚C ~ +60˚C

Storage temperature

-40˚C ~ +80˚C

Input/output impedance

75Ω (FM)

10-5

8910-05

Audio assembly

CDP (MP3) + Bluetooth

CDP(MP3) + RDS + Bluetooth

The “CALL” button for Bluetooth system has been added.

2. MAJOR CHANGES

RDS (Radio Data System) is a broadcasting service which a growing number of FM stations are now

providing. It allows the FM stations to send additional signals along with their regular programme signals.

For example, the stations send their station names and information about what type of programme they

broadcast, such as sports or music, etc.

When tuned to an FM station which provides the RDS service, the RDS indicator lights up, the station

frequency (and then the station name if sent) is displayed.

Not all FM stations provide RDS service, nor do all RDS stations provide same services. If in doubt,

check with local radio stations for details on RDS services in your area.

This machine can use the following RDS service.

PS (Programme Service name) / PTY (Programme Type) / TP (Traffic Program) / TA (Traffic

Announcement) / AF (List of Alternative Frequencies) / RT (Radio Text)

This allows you to locate a specific type name of programme being broadcast.

3. RDS (RADIO DATA SYSTEM) AUDIO

10-6

Front door speaker

Remote control switch on steering

wheel

1. LAYOUT

Audio

CDP (MP3)

Radio

USB/AUX

Bluetooth hands-free

-

-

-

-

-

Front door tweeter speaker

10-7

8910-05

Hands-free microphone

Rear door speaker

USB/AUX

Audio assembly

CDP (MP3) + Bluetooth

CDP(MP3) + RDS + Bluetooth
