01-4

2) Steering Wheel Angle Sensor

SWAS: Steering Wheel Angle Sensor

Old

New

The sensor has been changed due to newly adopted steering wheel heating system.

The location of sensor connector and the pin arrangement of connector have been changed.

1.

2.

Sensor connector

Sensor connector

01-5

0000-00

3) Steering Wheel Heating System

Steering wheel heating unit

Old

New

The steering wheel heated wire and the heating unit are
installed in the steering wheel assembly.

Lower main switch cluster

Old

New

The steering wheel heating switch has
been added on the lower main switch
cluster.

Specifications

▶

Description

Specification

Power consumption

Below 95W

Rated voltage

12V

Operating voltage

9V~16V

Rated current

6±2.0A

Steering wheel

heating unit

Steering wheel

heating switch

01-6

4) Parking Brake Lever Assembly

Parking brake lever assembly (Automatic transaxle equipped vehicle)

Old

New

The parking brake lever bracket has been changed to adopt the premium console.

Parking brake lever assembly (Manual transaxle equipped vehicle)

Old

New

The parking brake lever bracket has been changed to adopt the premium console.
