06-35

8510-00

3) Cruise Control Switch

Cruise control switch

The cruise control is an automatic speed control system that maintains a desired driving speed without

using the accelerator pedal. The cruise control switch is fitted to the bottom right section of the steering

wheel. When this switch is operated, the AUTO CRUISE or ECO lamp on the instrument cluster comes

on.

The cruise control switch has a fivefold switch in it. The engine ECU can determine the current driving

condition since the resistance varies depending on the operation of the switch.

The cruise control system is operated at vehicle speed of between 38 km/h and 150 km/h. The manual

transmission is operated in the range of 3rd gear or higher.

This function can be used at the following traffic condition. (It is important to be careful for using this

function)

Cruise control (ON)

Cruise control (OFF)

Cruise control (Acceleration)

Cruise control (Deceleration)

Cruise control (Reset)

06-36

4) Horn Switch

Horn switch

Two horns are installed in the radiator grille at the bottom of both sides (one on each side). There is

another horn installed at the bottom of the battery tray side in the engine compartment for theft alarm.

Operating the horn switch on the steering wheel applies the power to the horn relay to operate both

horns (Dual horn).

The theft deterrent horn is controlled by the BCM in armed mode regardless of the horn relay operation.

06-37

8510-00

Rear seat warmer switch

Front seat warmer switch

5. SEAT WARMER SWITCH

Driver seat warmer switch

Passenger seat warmer switch

Rear LH seat warmer switch

Rear RH seat warmer switch

The front and rear seat warmer switches are designed to control (LO or HI) the seat temperature. Press
the “HI (High temperature)" or “LO (Low temperature)" on the seat warmer switch to heat the seat
and seatback. When the temperature reaches 40 ±5℃, the thermistor integrated in seat connects

and cuts the power to keep the temperature stable. There is no separate seat warmer unit to control the

heating temperature of the seat heated wire.

(STD class)

06-38

Overhead console switch

6. OVERHEAD CONSOLE SWITCH

The front room lamp is controlled by the BCM.

The front room lamp comes on when opening the driver or passenger door. (door coupled operation

switch ON)

When closing the driver or passenger door, the front room lamp comes on for 2 seconds and then

dims down for 3 seconds. (door coupled operation switch ON)

The front room lamp turns on/off depending on the operation of the front room lamp ON/OFF switch

(spot switch).

-

-

-

-

Front room lamp switch

Door coupled operation switch

Sunroof switch

Front room lamp connector

Sunroof connector
