06-27

8510-00

4WD LOCK switch

This switch is of push lock type, which
enables to increase/decrease the
torque to the rear wheels in AWD
mode.

Steering wheel heating switch

This switch is of push return type,
which is used to activate or deactivate
the steering wheel heating function.

ESP OFF switch

The ESP OFF switch is of push return
type, which is used to stop or resume
the ESP function.

4WD LOCK switch

This switch is of push lock type, which
enables to increase/decrease the
torque to the rear wheels in AWD
mode.

HLLD

(Headlamp Leveling Device)

The headlamp aiming can be adjusted
by using this dial-type switch.

Rear fog lamp switch

(EU ONLY)

This switch is of push return type,
which sends ON/OFF signal to the
BCM so that the BCM can switch on
the lamps by activating the rear fog
lamp relay.

06-28

Power seat switch

(1) Power seat switch (Driver side)

4) Power Seat Switch Assembly

Seat sliding

Seatback

reclining

Seat height

adjustment

Seat sliding

Seatback reclining

Seat height adjustment

06-29

8510-00

Audio remote control switch (RH)

Audio remote control switch (LH)

1) Audio Remote Control Switch

4. STEERING WHEEL SWITCH

MUTE & MODE switch

Volume UP/DOWN switch

SEEK UP/DOWN switch

Handsfree switch

Tip switch (D+)

Tip switch (D-)

06-30

Tip switch (D-)

Gear change switch

-Change up

SEEK UP/DOWN switch

Volume UP/DOWN

switch

Increases/decreases

volume

Tip switch (D-)

Gear change switch

-Change down

CD mode

Select next/previous track and

FF/REW

Radio mode

Change frequency UP or DOWN

Press and hold to auto search

-

-

MUTE & MODE switch

To eliminate the sound (MUTE), briefly
press this switch. To change the audio
mode (Radio-CD-USB-AUX-Radio),
press and hold this switch.

Handsfree switch

To make/receive/end a call,
press and hold this switch.
