03-36

Remote door lock

▶

When briefly pressing (below 0.5 sec) the LOCK button on the transmitter, the doors are locked.

The BCM sends the door lock signal immediately after receiving the door lock message from the

transmitter. When door close, hood close and door lock status is detected, it outputs the turn signal

lamp signal.

Only when door close, hood close and door lock conditions are satisfied after door lock is performed,

the turn signal lamp signal is outputted.

The REKES operation is not available when the ignition key is in the key switch. Also, it is not

possible to use the switches on the remote control key for 1 second after removing the ignition key

from the ignition switch to avoid unintended operation.

If any of doors could not be locked when pressing the LOCK switch, the system performs the unlock

operation.

1.

2.

3.

4.

5.

Door lock

▶

Locking door and tailgate (briefly press)

If you press this button, all doors and the tailgate are locked and the theft deterrent mode is

activated.

When the theft deterrent mode is activated, the hazard warning flasher blinks twice. However, when

pressing this button once again within 4 seconds, the hazard warning flasher blinks twice and buzzer

sounds once.

1.

-

-

03-37

8710-01

Remote door unlock

▶

When briefly pressing (below 2.0 sec) the UNLOCK button on the transmitter, the doors are

unlocked.

The door unlock relay is turned ON for 0.5 seconds when receiving the door unlock message from

the transmitter.

The turn signal lamps blink only when all doors are successfully unlocked.

The REKES operation is not available when the ignition key is in the key switch. Also, it is not

possible to use the switches on the remote control key for 1 second after removing the ignition key

from the ignition switch to avoid unintended operation.

1.

2.

3.

4.

Remote panic

▶

When pressing (over 2.0 sec) the PANIC switch on the transmitter, the panic alarm is activated.

When receiving the panic message from the transmitter, the horn sounds and the turn signal lamps

blink for 30 seconds (Panic alarm).

1.

2.

03-38

After 30 seconds delay auto door lock

▶

If a door or tailgate is not opened within 30 seconds after unlocking the doors with remote control key

in theft deterrent mode, all doors will be automatically locked again (change to theft deterrent mode).

If any door is not opened or the key is not detected within 30 seconds after receiving the unlock

signal, the lock signal is outputted and theft deterrent mode is activated.

When entering into the theft deterrent mode, the turn signal lamps blink twice and the exterior buzzer

sounds once for SKM the lamps blink twice and burglar alarm horn sounds once for REKES.

1.

2.

03-39

8710-01

11) Door Lock/Unlock Control

The BCM with SKM receives wake-up source for driver door lock/unlock switch, passenger door

lock/unlock switch, rear door (left/right) lock switch, central door lock/unlock switch status through the

electric wire (hardwire).

Door lock/unlock control by door LOCK switch

▶

When moving the driver or passenger door lock (knob) switch to LOCK from UNLOCK position, BCM

sends the LOCK signal for 0.5 seconds.

When moving the driver or passenger door lock (knob) switch to UNLOCK from LOCK position, BCM

(UNLOCK) operation by the door lock (knob) switch is not available when sending the LOCK

(UNLOCK) signal by any other method such as remote control key.

When reconnecting the battery, the door lock (knob) switch is not operational regardless of the door

lock switch positions.

All doors stay unlocked when receiving the door lock signal in 0.5 seconds after closing the doors.

1.

2.

3.

4.

5.

The status for key cylinder switch and latch position switch is received through the door lock/unlock

switch.

When door lock signal is outputted due to failure of the door knob switch and door open switch and

automatic unlock signal is transmitted 5 times for 1 minute, BCM forcibly lock the doors without

unlocking.

However, door unlock command works normally and deactivates forcible unlock.

-
