DOORS 9P-9
SSANGYONG MY2002
KAA9P120
KAA9P130
DOOR HOLD OPEN LINK
Removal and Installation Procedure
1. Remove the door trim panel. Refer to Section 9G.
Interior Trim.
2. Remove the bolts on the door and on the body.
3. Remove the door hold open link.
4. Installation should follow the removal procedure
in the reverse order.
DOOR HINGE
Removal and Installation Procedure
1. With the aid of another technician, remove the bolts
and the hinge from the door and the body.
2. Installation should follow the removal procedure
in the reverse order.
OUTSIDE CHANNEL MOLDING
Removal and Installation Procedure
1. Lower the window completely.
2. Remove the outside rearview mirror. Refer to
Section 9L, Glass and Mirror.
3. Remove the screws and the outside channel
molding.
4. Installation should follow the removal procedure
in the reverse order.
KAA9P140
KAA9P150
DOOR WEATHERSTRIP
Removal and Installation Procedure
1. Remove the door weatherstrip.
2. Installation should follow the removal procedure
in the reverse order.
