Renault Trafic (2018 year). Instruction

1.50

Rear centre seat
Check that the belt is suitable for secu-

ring your child seat. Consult an appro-

ved dealer.

Fit the child seat in a rear

seat wherever possible.

In the rear side seat
A carrycot can be installed across the

vehicle and will take up at least two

seats.

Position the child with their feet nearest

the door.

Move the front seat as far forward as

possible to install a rear-facing child

seat, then move back the seat in front

as far as it will go, although without al-

lowing it to come into contact with the

child seat.
For the safety of the child in the for-

ward-facing position:
– do not push the seat in front of the

child back further than halfway along

its runners;

– do not recline the seatback too far

(maximum of 25°) and raise the seat

as much as possible.

In all situations, remove the rear head-

rests (refer to the information on the

“Rear headrests” in Section 3). This

must be done before fitting the child

seat.
Check that the forward-facing child seat

is resting against the back of the vehi-

cle seat.

CHILD SAFETY: fitting a child seat, general information

(2/2)

A child seat with a floor sup-

port must never be installed

on the rear centre seat.
RISK OF DEATH OR

SERIOUS INJURY.

1.51

CHILD SEATS: attachment by seat belt

(1/14)

Check the status of the air bag

before fitting a child seat or al-

lowing a passenger to use the seat.

Seat not suitable for fitting

child seats.

Child seat attached using the belt

Seat which allows a child seat

with “Universal” approval to be

attached by a seat belt.

RISK OF DEATH OR

SERIOUS INJURY: before

fitting a rear-facing child

seat on the front passen-

ger seat, check that the air bag has

been deactivated (refer to the infor-

mation on “Deactivating the front

passenger air bag” in Section 1).

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

3-seater van

2-seater van

1.52

CHILD SEATS: attachment by seat belt

(2/14)

Two or three-seater van versions

Type of child seat

Weight of the child

Front passenger seat(s) (2)

With single

passenger seat (1)

With two-seater bench seat

Centre seat

Side seat

Shell seat/rear-facing seat

Groups 0, 0+ and 1

< 13 kg and 9 to 18 kg

Forward-facing seat

Group 1

9 to 18 kg

Booster seat

Groups 2 and 3

15 to 25 kg and 22 to

36 kg

X Seat which does not allow a child seat to be fitted.

U Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
(1) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. Raise the

headrest. Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately

25°).

(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, check

that the airbag has been deactivated (please refer to the information on “Child safety: front passenger airbag deactiva-

tion/activation” in Section 1).

The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-

ble regulations are respected.

1.53

CHILD SEATS: attachment by seat belt

(3/14)

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

RISK OF DEATH OR

SERIOUS INJURY: before

fitting a rear-facing child

seat on the front passenger

seat, check that the airbag has been

deactivated (please refer to the in-

formation on “Child safety: front

passenger airbag deactivation, acti-

vation” in Section 1).

Check the status of the air bag

before fitting a child seat or al-

lowing a passenger to use the seat.
Child seat attached using the belt

Seat which allows a seat with

“Universal” approval to be

fitted using a seat belt;

Seat not suitable for fitting

child seats.

5-seater Combi

1.54

CHILD SEATS: attachment by seat belt

(4/14)

5-seater Combi version

Type of child seat

Weight of the child

Front passenger

seat (1) (2)

Rear side

seat

Rear centre

seat

Carrycot fitted across

the vehicle

Group 0

< 10 kg

U (3)

Rear-facing shell seat

Groups 0 and 0+

< 13 kg

U (4)

Rear-facing seat

Groups 0+ and 1

< 13 kg and 9 to 18 kg

U (4)

Forward-facing seat

Group 1

9 to 18 kg

U (5)

Booster seat

Groups 2 and 3

15 to 25 kg and 22 to

36 kg

U (5)

(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, check

that the airbag has been deactivated (please refer to the information on “Child safety: front passenger airbag deactiva-

tion/activation” in Section 1).

The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-

ble regulations are respected.

1.55

CHILD SEATS: attachment by seat belt

(5/14)

X = Seat not suitable for fitting child seats of this type.

U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
(2) Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).
(3) A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest

the door.

(4) Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will

go, although without allowing it to come into contact with the child seat.

(5) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. In all situa-

tions, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the child seat

(please refer to the section entitled “Rear headrests” in Section 3). Do not push the seat in front of the child more than halfway

back on its runners and do not recline the seatback more than 25°.

1.56

6-seater Combi version

Type of child seat

Weight of the child

Front seat

Rear seat

centre

passenger

side

passenger

(1)

side

centre

Carrycot fitted across the

vehicle

Group 0

< 10 kg

U (2)

Rear-facing shell seat

Groups 0 and 0+

< 13 kg

U (3)

Rear-facing seat

Groups 0+ and 1

< 13 kg and 9 to 18 kg

U (3)

Forward-facing seat

Group 1

9 to 18 kg

U (4)

Booster seat

Groups 2 and 3

15 to 25 kg and 22 to

36 kg

U (4)

CHILD SEATS: attachment by seat belt

(6/14)

(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, check

that the airbag has been deactivated (please refer to the information on “Child safety: front passenger airbag deactiva-

tion/activation” in Section 1).

The table below summarises the information already shown in the diagram on the following pages, to ensure the appli-

cable regulations are respected.

1.57

CHILD SEATS: attachment by seat belt

(7/14)

X = Seat not suitable for fitting child seats of this type.

U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
(2) A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest

the door.

(3) Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will

go, although without allowing it to come into contact with the child seat.

(4) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. In all situa-

tions, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the child seat

(please refer to the section entitled “Rear headrests” in Section 3). Do not push the seat in front of the child more than halfway

back on its runners and do not recline the seatback more than 25°.

1.58

CHILD SEATS: attachment by seat belt

(8/14)

Check the status of the air bag

before fitting a child seat or al-

lowing a passenger to use the seat.
Child seat attached using the belt

Seat which allows a seat with

“Universal” approval to be

fitted using a seat belt;

Seat not suitable for fitting

child seats.

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

RISK OF DEATH OR

SERIOUS INJURY: before

fitting a rear-facing child

seat on the front passenger

seat, check that the airbag has been

deactivated (please refer to the in-

formation on “Child safety: front

passenger airbag deactivation, acti-

vation” in Section 1).

6-seater Combi

1.59

RISK OF DEATH OR

SERIOUS INJURY: before

fitting a rear-facing child

seat on the front passenger

seat, check that the airbag has been

deactivated (please refer to the in-

formation on “Child safety: front

passenger airbag deactivation, acti-

vation” in Section 1).

Check the status of the air bag

before fitting a child seat or al-

lowing a passenger to use the seat.
Child seat attached using the belt

Seat which allows a seat with

“Universal” approval to be

fitted using a seat belt;

Seat not suitable for fitting

child seats.

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

CHILD SEATS: attachment by seat belt

(9/14)

8-seater combi/bus

1.60

CHILD SEATS: attachment by seat belt

(10/14)

8-seater Bus/Combi version

Type of child seat

Weight of

the child

Front

passenger

seat (1) (2)

Rear seat

2nd row

side seats

2nd row

centre seat

3rd row

side seats

3rd row

centre seat

Carrycot fitted across

the vehicle

Group 0

< 10 kg

U (3)

Rear-facing shell

seat

Groups 0 and 0+

< 13 kg

U (4)

Rear-facing seat

Groups 0+ and 1

< 13 kg and 9 to

18 kg

U (4)

Forward-facing seat

Group 1

9 to 18 kg

U (5)

Booster seat

Groups 2 and 3

15 to 25 kg and 22

to 36 kg

U (5)

(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, check

that the airbag has been deactivated (please refer to the information on “Child safety: front passenger airbag deactiva-

tion/activation” in Section 1).

The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-

ble regulations are respected.

1.61

CHILD SEATS: attachment by seat belt

(11/14)

X = Seat not suitable for fitting child seats of this type.

the door.

(4) Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will

go, although without allowing it to come into contact with the child seat.

(5) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. In all situa-

tions, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the child seat

(please refer to the section entitled “Rear headrests” in Section 3). Do not push the seat in front of the child more than halfway

back on its runners and do not recline the seatback more than 25°.

1.62

CHILD SEATS: attachment by seat belt

(12/14)

9-seater Bus/Combi version

Type of child seat

Weight of

the child

Front seat

Rear seat

centre

passenger

side

passenger

(1)

2nd row

side seats

2nd row

centre

3rd row

side seats

3rd row

centre

seat

Carrycot fitted across

the vehicle

Group 0

< 10 kg

U (2)

U (3)

Rear-facing shell seat

Groups 0 and 0+

< 13 kg

U (3)

Rear-facing seat

Groups 0+ and 1

< 13 kg and 9 to

18 kg

U (4)

U (3)

Forward-facing seat

Group 1

9 to 18 kg

U (4)

Booster seat

Groups 2 and 3

15 to 25 kg and

22 to 36 kg

U (4)

(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, check

that the airbag has been deactivated (please refer to the information on “Child safety: front passenger airbag deactiva-

tion/activation” in Section 1).

The table below summarises the information already shown in the diagram on the following pages, to ensure the appli-

cable regulations are respected.

1.63

CHILD SEATS: attachment by seat belt

(13/14)

X = Seat not suitable for fitting child seats of this type.

the door.

(3) Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will

go, although without allowing it to come into contact with the child seat.

(4) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. In all situa-

tions, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the child seat

(please refer to the section entitled “Rear headrests” in Section 3). Do not push the seat in front of the child more than halfway

back on its runners and do not recline the seatback more than 25°.

1.64

RISK OF DEATH OR

SERIOUS INJURY: before

fitting a rear-facing child

seat on the front passen-

ger seat, check that the air bag has

been deactivated (refer to the infor-

mation on “Deactivating the front

passenger air bag” in Section 1).

Check the status of the air bag

before fitting a child seat or al-

lowing a passenger to use the seat.
Child seat attached using the belt

Seat which allows a seat with

“Universal” approval to be

fitted using a seat belt;

Seat not suitable for fitting

child seats.

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

CHILD SEATS: attachment by seat belt

(14/14)

9-seater combi/bus

1.65

Child seat attached using the ISOFIX

mounting

Seat which allows an ISOFIX

child seat to be fitted.

The rear seats are fitted with

an anchorage point which allows a

forward-facing ISOFIX child seat with

universal approval to be fitted. The an-

chorage points are located in the lug-

gage compartment and are visible.
The size of the ISOFIX child seat is in-

dicated by a letter:

– A, B and B1: for forward-facing seats

in group 1 (9 to 18 kg);

– C: rear-facing seats in group 1 (9 to

18 kg);

– D and E: shell seat or rear-facing

seats in group 0 or 0+ (less than

13 kg);

– F and G: carrycots in group 0 (less

than 10 kg).

CHILD SEATS: attachment using the ISOFIX system

(1/12)

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

Seat which does not allow a

child seat to be fitted.

5-seater Combi

Renault Trafic (2018 year). Instruction - part 4
