Peugeot Boxer Benne (2012 year). Instruction - part 7

Audio equipment

ECHNOLOGY

BOAR

SELECTING A STATION

STORING A STATION - MANUALLY

After selecting a frequency, press
one of these buttons (for more than
2 seconds) to store the frequency.
Storing is confirmed by an audible
beep.

Press the AM or FM button and then
select a waveband from: MW1 and
MW2 or FM1, FM2 and FMA.

To select the radio function, make a
short press on the AM or FM button.

Briefly press one of these buttons to
carry out an automatic search of the
radio stations.

Press one of these buttons to carry
out a manual search of the radio
stations.

RADIO

Press the FM AS * button (for more
than 2 seconds) until the audible
signal is heard.
The radio searches for and stores the
6 stations with the strong signal
(in decreasing signal strength order)
in the waveband.
A long press on the button updates
the selection.

STORING A STATION - AUTOMATICALLY

* AutoStore: automatic storing (pre-setting) of stations.

Audio equipment

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio
Layer 3, is an audio compression standard which permits the
recording of several tens of music files on a single disc.

MP3

In order to be able to play a recorded CDR or CDRW, when
recording it is preferable to select standards ISO 9660
level 1.2 or Joliet.
If the disc is recorded in another format, it may not be played
correctly.

It is recommended that the same recording standard is
always used for an individual disc, with as low a speed as
possible (4x maximum) for optimum sound quality.
In the particular case of a multi-session CD, the Joliet
standard is recommended.

The audio equipment will only play files with the extension
".mp3" with a sampling rate of 22.05 KHz or 44.1 KHz.No
other type of file (.wma, .mp4, m3u...) can be played.

It is advisable to restrict file names to 20 characters without
using special characters (e.g.: () " " ? ; , space ) to avoid any
playing or displaying problems.

PLAY A CD

Insert circular compact discs only.
Some anti-pirating systems, on original
discs or CDs copied using a personal
recorder, may cause faults which are no
reflection on the quality of the original
player.
Insert a CD or an MP3 CD in the player,
play begins automatically.

If the player already contains a disc,
switch on the audio equipment and
press the MEDIA source button briefl y.
The last track played begins.

Press one of the buttons to select a
track on the CD.
Press and hold one of the buttons for
fast forwards or backwards.

Press this button to pause play.
Press again to resume play.

Bluetooth hands-free system

ECHNOLOGY

BOARD

When you switch on the audio system, you may have to enter a
code for access to its functions.
In this cases, the message " Radio Code " is displayed in the
screen, followed by 4 dashes.
The 4-number code should be entered using the buttons 1 to 6.
You have 20 seconds to enter the code.
If the wrong code is entered, the audio system gives an audible
signal and the message message " Radio blocked/wait " is
displayed. You should then start the procedure again.

Keep your code in a safe place, never inside the
vehicle .

TELEPHONE PRE-EQUIPMENT

If the hands-free kit is fitted to your vehicle, you can use the
audio system and the steering mounted controls to manage your
telephone calls.
During an incoming call, the audio system is deactivated, and
the message " PHONE " is displayed.
The volume can be adjusted and stored via the " EXTERNAL
AUDIO " menu.

Each time an incorrect code is entered, the waiting time before
the code can be entered again increases progressively (1 minute,
2 minutes, 4 minutes, 8 minutes, 16 minutes, 30 minutes, 1 hour,
2 hours, 4 hours, 8 hours, 16 hours, 24 hours).

The language of the Bluetooth system adapts automatically
by detecting the language set on your telephone.

SYSTEM

INTRODUCTION

This system allows you to:
- send and receive calls via the Bluetooth

connection with your

mobile telephone,

- display the names of your contacts and numbers from the

directory of your mobile phone in the instrument panel screen,

- use voice commands to make a call and manage your

contacts while keeping both hands on the steering wheel,

- hear your text messages via the voice synthesiser built into

the system,

- listen to MP3, WMA, AAC, M4A, MP4 and WAV audio files

from a USB storage device,

- display information on the track being played in the radio

screen (title, artist, etc...),

- control vocally a portable music player (iPod

type),

- recharge your portable music player (iPod

type) via the USB

port.

Audio equipment

Bluetooth hands-free system

PRESENTATION

Adjustment of the volume of the functions:
hands-free, audio and text message player, voice
announcements.

Pause/resume the file being played (portable
player).

USB connection port. Remove the plastic cover to
connect your portable player.

Display of the menus and directories of the files
being played (USB storage device).

    -   Scroll the menu options.
  -   Select the files to be played (portable player).
  -   Scroll the list of text messages.

- Activate voice recognition.
- Interrupt the voice message in order to issue a new

voice command.

- Deactivate voice recognition.
- Interrupt the voice message.

- Exit from the main menu.
- Exit from a sub-menu and return to the previous

menu option.

- Exit without storing.
- Deactivate/reactivate the microphone during a

telephone conversation.

- Set the volume of the incoming call ring to zero.

- Confirm the current menu option.

- Transfer he telephone conversation from the hands-

free system to the mobile telephone and vice versa.

- Select the audio source.
- Select the text displayed.

    -   Activate the main menu.
  -   Confirm the current menu option.
  -   Accept the incoming call.
  -   Switch one telephone conversation to another.

  -   Select a visual message.
  -   Reject an incoming telephone call.
  -   End the current telephone call.

Description of the steering mounted controls

- Repeat the last voice message.

Bluetooth hands-free system

ECHNOLOGY

BOARD

PRESENTATION

Description of voice commands

By pressing this button and saying "HELP", you have access to the list of voice commands available at any time or by saying
"HELP" after a system message.

The main voice commands for navigating in the menu are the following:

You can access the main menu of the system via the voice command by pressing this button.

* If the system is activated.

** Not available on iPod

LAST CALLS

HENRY BRIDGES

CHRISTOPHER ANDREW
123456789

PHONEBOOK

HENRY BRIDGES

CHRISTOPHER ANDREW
123456789

MESS. READER

READ LAST
IN BOX

VIS+ACOUST

DELETE ALL

VIS. SIGNAL

SIGNAL TYPE

READER OFF

MEDIA PLAYER

USB OPTION *

PLAY ANYTHING

SET USB

FOLDERS **
ARTISTS
GENRES
ALBUMS
PLAYLISTS

TRACK PLAY
SHUFFLE
TRACK LOOP

SETTINGS

USER DATA

COPY PHONEBOOK

PAIRING

DELETE USERS

ADVANCED OPTIONS

DELETE PHONEBOOK

EXIT

DELETE ALL
ADD CONTACTS

100

Bluetooth hands-free system

When prompted by the telephone, enter the
PIN displayed in the instrument panel.
If the pairing has been successful, the
system announces "Connecting".
The name of the telephone identified
appears in the instrument panel screen,
pairing is confirmed.

"Settings"\wait for a response\
"Pairing".

PIN

Pairing a mobile telephone
Pairing consists of setting your vehicle's
Bluetooth

system to recognise your mobile

telephone.
For this you must activate the Bluetooth

function of your telephone and set its
visibility.

MOBILE TELEPHONE WITH HANDS-FREE FUNCTION

With the ignition on, activate the
main menu.

Select SETTINGS.

Confirm.

Select PAIRING.

Confirm.

This number, which permits
recognition of your mobile
telephone, is generated
randomly by the system.

It is communicated by the instrument panel
screen and is repeated verbally by the
system.
This PIN is independent of your SIM card
and your mobile's access code.
Once your handset has been paired, there is
no need to keep a record of this number.
If you change your mobile telephone, you
must repeat the pairing procedure as you
will be given a new PIN.

Look for the option which displays
the Bluetooth

system detected

by your telephone.

When the system has been
identified, a message appears in
your telephone (My car, ...).

Pressing MAIN or ESC during
the pairing phase may cancel the
procedure.

If the pairing fails, an error message will
appear; in this case, repeat the procedure.

101

Bluetooth hands-free system

ECHNOLOGY

BOARD

  Downloading your phonebook
  There are 2 options:
  1  - Following the pairing procedure, the

system suggests downloading your
telephone's phonebook.

Calling a contact recorded in the

phonebook
Your telephone's phonebook must first be
downloaded into the system.

"CALL [Name of the person]"\
wait until the information relating
to the person (name, tel. n°, ...)
appears\
"Yes" to make the call or "No" to
cancel.

Pressing confi rms your agreement.

"Yes" starts the download.

Pressing declines this download.

"No" declines.

2 - You can download the phonebook later

via the menu:

Activate the main menu.

Select SETTINGS then USER
DATA then PHONEBOOK.

"Settings"\"User data"\
"Download phonebook".

Activate the main menu.

Select PHONEBOOK.

Confirm.

Select the group with which
the person to be contacted is
associated.

Confirm.

Select the name.

Confirm to make the call, if the
person has only one number.

If the person has more than one number:

Select the number.

Confirm to make the call.

Specify "Home" or "Work", or
"NEXT" or "PREVIOUS".
Press OK to make the call.

102

Bluetooth hands-free system

Making a call by dialling a number

Ending a call

Incoming call

"Dial / Dial a number"\
Say the number character by
character (+, #, *), digit by
digit (0 to 9).

The system displays and
verbally repeats the number
recognised.

"CALL" if the number is correct.
or
"Cancel" to cancel dialling of the
number.
"Start over" to delete and start
dialling another number.
"Repeat" to hear the number again.

If the person is recorded in
the phonebook, his name is
displayed.

Press to accept the call.

Press and hold to decline the
call.

Press to ignore the call, however,
the call is stored in the log of
incoming calls.

During a call, if a second incoming call
is received.

By means of the voice commands only

Press and hold.

Press to switch the conversation
and place the other person on
hold.

103

Bluetooth hands-free system

ECHNOLOGY

BOARD

  Transferring an active call
  There are 2 options:
  1  - From the mobile telephone to the hands-

free system

With the ignition on, the recognition
connection between the mobile telephone
and the vehicle's audio equipment is done
automatically.
Confirm this recognition using the keypad on
the mobile telephone.
The call can then be transferred.

Placing a call on hold

Call list
This enables you to call the number of one
of the last 10 calls received, of one of the
last 10 people called or of one of the last
5 missed calls.

2 - From the hands-free system to the

mobile telephone

Press to deactivate the
microphone and place your
contact on hold.

Press again to resume the
conversation.

Activate the main menu.

Select CALL LIST.

Confirm.

Select the number to be called.

Confirm.

"Callback" for the last person who
called you, or
"Redial" for the last person you
called.
"Yes" or "No" to confirm/cancel.
The "Redial" button can also be
used.
The system will again ask "Redial or

callback?".
"Callback" to call back the last
person who called you.
"Redial" to redial the last person
you called.

Press, the system's controls are
still active.

Bluetooth hands-free system

VOICE COMMANDS

The key words which can be recognised by the system are organised into three levels (levels 1, 2 and 3).
When you say a level 1 command, the system makes the level 2 commands available; when you say a level 2 command, the
system makes the level 3 commands available.

Settings/pairing

Level 1

Level 2

Level 3

Actions

Settings
Adjust
Configure

User data

Activation of the hands-free system SETTINGS menu.

Activation of the USER DATA menu.

Delete users

Deletion of the data recorded for all of the users.

Delete contacts /
Delete directory /
Delete numbers

Deletion of the phone book data.

Copy phone book /
Copy phonebook /
Copy numbers

Transfer of the phone books from your mobile telephone to the hands-
free system (available according to the type of mobile telephone).

Add Contacts

Transfer of the names from your mobile telephone to the hands-free
system (available according to the type of mobile).

Delete all

Deletion of the pairing data and of the phone books / contacts of all
of the telephones paired, with restoration of the default settings of
the hands-free system.

Pairing / Pair / Pair the user

Activation of the pairing procedure for a new mobile telephone.

Advanced options

Activation of the ADVANCED OPTIONS menu.

105

Bluetooth hands-free system

ECHNOLOGY

BOARD

VOICE COMMANDS

Mobile telephone with hands-free function

Level 1

Level 2

Level 3

Actions

Dial / Dial a number

One, Two, ..., Plus,
Star, Hash

CALL / Dial

Entering the digits or symbols to dial the telephone number.

Delete / Correct

Deletion of the last group of digits entered.

Start over

Deletion of all of the groups of digits entered with the option of

entering a new number.

Repeat

Repeating the telephone number entered and recognised by the

hands-free system.

Cancel

Cancellation of dialling of the number.

Sending the call to the number entered verbally.

CALL

[ Name ]

Yes / No

Call to the name of the person, stored in the system's phone book.

Mobile

Call to the name of the person with personalisation if there are

several numbers stored in the system.

Home

Work / Office

Redial

Call to the last person called.

Callback

Call to the last person who called.

106

Bluetooth hands-free system

If your mobile telephone includes this
function, every time a text message is
received, the system produces an audible
signal and offers to read the text message
vocally.

To read the text received.

"Yes" starts the playback of the text
received.

Only on mobile telephones with this

function

To save a message and read it
later.

"No" to save the message and read
it later.

TEXT READER

Read an incoming text message

Read the last text received

Activate the main menu.

Select MESS. READER.

Confirm.

Select READ LAST.

Confirm.

"Read last" starts playback of
the last text message received.

List of text messages

The system can hold around 20 text
messages. If the list is full, reception of a
new text message causes the deletion of the
oldest text message.

To go to a specific text message:

Activate the main menu.

Select MESS. READER.

Confirm.

Select IN BOX.

Confirm.

107

Bluetooth hands-free system

ECHNOLOGY

BOARD

Select the desired text message.

"Message reader" then after the
audible signal "message received".
"PREVIOUS" or "NEXT" moves

through the list of text messages.
"Read" starts reading of the text
message selected.

Confi rm to read the text message.

Managing text messages

"Read" starts reading of the message.
"Erase" deletes the message.
"CALL" allows you to contact the
sender of the message.

Deleting all text messages

Activate the main menu.

Select DELETE ALL.

Confirm.

The system asks you to confirm your choice:

Confirm to delete.

To cancel.

"Message reader" then after the
audible signal "Delete all".

The system requests confirmation,
reply with: "Yes" to confirm or "No"
to cancel.

"Message reader" then after the
audible signal "Signal type".
The system lists the options, select

between: "Reader deactivated",
"Audio and visual info" or "Visual
info only".

Information settings

Activate the main menu.

Choose the desired option.

During reading of the message:

Activate the main menu.

Select MESS. READER.

Confirm.

Select SIGNAL TYPE.

Confirm to select from the
3 choices available:

- Audio + visual: the system signals the

receipt of a message audibly and visibly
and offers to read it.

- Visual only: reception of a message is

signalled visibly in the instrument panel.

- Off: the text message reader is

deactivated.

108

Bluetooth hands-free system

VOICE COMMANDS

Message reader

Level 1

Level 2

Level 3

Actions

Message reader
Messages

Messages received /
Received

Activation of the MESS. READER menu.

Activation of the list of text messages received.

Read/ read again

Reads the text message selected in the list.

CALL

Deletion of the phone book data.

Delete

Transfer of the phone books from your mobile telephone to the

hands-free system (available according to the type of mobile).

Back / Next / NEXT

Go to the next text message in the list

Back / PREVIOUS

Go to the previous test message in the list.

Read last / read last message / read message Read the last text message received.

Delete all / Delete messages / Delete

Delete all text messages in the list after confirmation.

109

Bluetooth hands-free system

ECHNOLOGY

BOARD

Level 1

Level 2

Level 3

Actions

Read messages /
Messages

Type of info / Info

Activation of the MESS. READER menu.

Deactivation of the info settings function.

Deactivate reader /
Reader not active /
Reader off

Deactivates the reading of text messages.

Visual and audible
info / Visual and
audible / Visual plus
audible / Audible

Reception of a text message is signalled in the instrument panel
screen and by an audible signal.

Visual info only /
Only visual / Visual

Reception of a text message is signalled only in the instrument
panel screen.

Bluetooth hands-free system

Audio tracks in .mp3, .wma, .wav format
and playlists with the extension .wpl are
recognised by the system.

Selecting tracks

PORTABLE AUDIO DEVICE PLAYER

Autoplay

USB port

Connect the device to the
USB port directly or using an
appropriate cable (not provided).

Ignition on:
- activates the recognition connection and

automatically starts the playlist,

- or activates automatic play if the system

is programmed to autoplay.

Otherwise, select the track to be
played via the menu.

Activate the main menu.

Select SETTINGS then MEDIA
PLAYER then TRACK PLAY.

Confirm.

Select READER or READER
OFF.

Confirm.

Activate the main menu.

Select MEDIA PLAYER.

Confirm.

Choose one of the selection
modes:
FOLDERS, ARTISTS, GENRES,

ALBUMS, PLAYLISTS, SHUFFLE
(random play of tracks in the
playlist).

"Media player", then "USB
options" and finally choose
"Folders", "Artists", ...

The PLAY ALL function enables you
to listen to the entire content of a

selection mode (folders, artists, ...).

Content .. 5 6 7 8 ..
