Opel Crossland X (2018 year). Manual - part 8





118

Lighting

Illustration shows rear courtesy lights.

Sunvisor lights

Illuminates when the cover is opened.

Lighting features

Centre console lighting

A spotlight integrated in the overhead

console illuminates the centre

console when headlights are

switched off.

Entry lighting

Welcome lighting

Some or all of the following lights are

switched on for a short time by

unlocking the vehicle with the radio

remote control:

● headlights
● tail lights
● number plate lights
● instrument panel light
● interior lights

The number of activated lights

depends on the surrounding light

conditions.
The lighting switches off immediately

when the ignition is switched on.

Starting off 3 18.

This function can be activated or

deactivated in the vehicle

personalisation.
Vehicle personalisation 3 103.
The following lights will additionally

switch on when the driver's door is

opened:

● illumination of some switches
● Driver Information Centre
● door pocket lights

Exit lighting

The following lights are switched on if

the key is removed from the ignition

switch:

● interior lights
● instrument panel light

They will switch off automatically after

a delay. This function works only in

the dark. Theatre lighting is activated

if the driver's door is opened during

this time.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Lighting

119

Battery discharge protection

Vehicle battery state of charge

function

The function guarantees longest

vehicle battery life via a generator

with controllable power output and

optimised power distribution.
To prevent discharge of the vehicle

battery when driving, the following

systems are reduced automatically in

two stages and finally switched off:

● auxiliary heater
● heated rear window and mirrors
● heated seats
● fan

In the second stage, a message

which confirms the activation of the

vehicle battery discharge protection

will be displayed in the Driver

Information Centre.

Switching off electric lights

To prevent discharge of the vehicle

battery when the ignition is switched

off, some interior lights are switched

off automatically after some time.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

120

Climate control

Climate control

Climate control systems ............. 120

Heating and ventilation system 120

Air conditioning system ........... 121

Electronic climate control

system .................................... 124

Auxiliary heater ........................ 128

Air vents ..................................... 129

Adjustable air vents ................. 129

Fixed air vents ......................... 130

Maintenance .............................. 130

Air intake ................................. 130

Air conditioning regular

operation ................................ 131

Service .................................... 131

Climate control systems

Heating and ventilation

system

Controls for:

● temperature £
● air distribution l, M and K
● fan speed Z
● demisting and defrosting à
● heated rear window and exterior

mirrors b

● heated seats ß

Temperature £

Adjust the temperature by turning

£

 to the desired temperature.

red area : warmer

blue area : colder
Heating will not be fully effective until

the engine has reached normal

operating temperature.

Air distribution l M K

Press:
l

: to windscreen and front door

windows

M

: to head area and rear seats via

adjustable front air vents

K

: to front and rear foot well and

windscreen

Combinations are possible.

Fan speed Z

Adjust the air flow by turning Z to the

desired speed.
to the right

: increase

to the left

: decrease

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate control

121

Demisting and defrosting the

windows á

● Press á: the air distribution is

directed towards the windscreen.

● Set temperature controller £ to

warmest level.

● Set fan speed Z to highest level.
● Switch on heated rear window b.
● Open side air vents as required

and direct them towards the door

windows.

Heated rear window and exterior

mirrors b

3

 39

Heated seats ß

3

 47.

Air conditioning system

Illustration shows functions which

may not be available for your

particular vehicle.
Controls for:

● temperature £
● air distribution l, M and K
● fan speed Z
● demisting and defrosting à
● air conditioning A/C
● air recirculation 4

● heated rear window and exterior

mirrors b

● heated windscreen ,
● heated seats ß

Some changes of settings are

indicated briefly in the Info-Display.

Activated functions are indicated by

the LED in the respective button.

Temperature £

Adjust the temperature by turning

£

 to the desired temperature.

red area : warmer

blue area : colder

-------------------------------------------------------------------------------------------------------------------------------------------------------------

122

Climate control

Heating will not be fully effective until

the engine has reached normal

operating temperature.

Air distribution l M K

Press:
l

: to windscreen and front door

windows

M

: to head area and rear seats via

adjustable front air vents

K

: to front and rear foot well and

windscreen

Combinations are possible.

Fan speed Z

Adjust the air flow by turning Z to the

desired speed.
to the right

: increase

to the left

: decrease

Air conditioning A/C

Press A/C to switch on cooling.

Activation is indicated by the LED in

the button. Cooling is only functional

when the engine is running and

climate control fan is switched on.
Press A/C again to switch off cooling.
The air conditioning system cools and

dehumidifies (dries) as soon as the

outside temperature is slightly above

the freezing point. Therefore

condensation may form and drip from

under the vehicle.
If no cooling or drying is required,

switch off the cooling system for fuel

saving reasons.

Activated cooling may inhibit

Autostops. Stop-start system 3 138.

Demisting and defrosting the

windows à

● Press à: the air distribution is

directed towards the windscreen.

● Set temperature controller £ to

warmest level.

● Switch on air conditioning A/C if

required.

● Set fan speed Z to highest level.
● Switch on heated rear window b.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate control

123

● Switch on heated

windscreen ,.

● Open side air vents as required

and direct them towards the door

windows.

Note

If à is pressed while the engine is

running, an Autostop will be inhibited

until à is pressed again.
If à is pressed while the engine is in

an Autostop, the engine will restart

automatically.

Stop-start system 3 138.

Air recirculation system 4

Press 4 to activate air recirculation

mode, LED is indicated.
Select air recirculation to assist in

cooling the interior or in blocking

outside odours or exhaust.
Press 4 again to deactivate air

recirculation mode.

9 Warning

The exchange of fresh air is

reduced in air recirculation mode.

In operation without cooling, the

air humidity increases, so the

windows may mist up from inside.

The quality of the passenger

compartment air deteriorates,

which may cause the occupants to

feel drowsy.

In warm and very humid ambient air

conditions, the windscreen may mist

up from outside when cold air is

directed towards it. If windscreen

mists up from outside, activate

windscreen wiper and deactivate l.

Maximum cooling

Briefly open the windows so that hot

air can disperse quickly.

● Switch on air conditioning A/C.
● Press 4 for air recirculation

system on.

● Press M for air distribution.
● Set temperature control £ to

coldest level.

● Set fan speed Z to highest level.
● Open all vents.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

124

Climate control

Heated rear window, windscreen

and exterior mirrors b

3

 39

Heated seats ß

3

 47.

Electronic climate control

system

The dual zone climate control allows

different temperatures for driver side

and front passenger side.
In automatic mode, temperature, fan

speed and air distribution are

regulated automatically.

Illustration shows functions which

may not be available for your

particular vehicle.
Controls for:

● temperature on driver side £
● MENU enters the Climate setting

menu in the Info-Display

● fan speed Z
● automatic mode AUTO
● temperature on front passenger

side £

● cooling A/C
● manual air recirculation 4
● demisting and defrosting à
● heated rear window and exterior

mirrors b

● heated windscreen ,
● heated seats ß

Activated functions are indicated by

the LED in the respective control.
The electronic climate control system

is only fully operational when the

engine is running.

Climate settings menu (MENU

button)

Settings for

● air distribution l, M, K
● fan speed Z
● temperature for driver and

passenger side 19°/21°

● dual zone temperature

synchronisation MONO

● air conditioning ON/OFF
● automatic mode AUTO

can be triggered manually in the

Climate setting menu. Press MENU to

enter the menu and follow the touch

buttons.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate control

125

Climate setting menu can also be

displayed

● by selecting Climate on the 7''

Colour-Info-Display or

● by pressing Í and then selecting

Climate from the menu on the 8''

Colour-Info-Display.

Automatic mode AUTO

Basic settings for automatic control

with maximum comfort:

● Press AUTO to start the air

conditioning automatically.

● Open all air vents to allow

optimised air distribution in

automatic mode.

● Set the preselected

temperatures for driver and front

passenger using the left and right

control dial. Recommended

temperature is 22 °C.

Temperature is indicated in

displays beside the control dials

and in the climate settings menu.

● Air recirculation mode 4 should

be deactivated. When

deactivated the LED in the button

is not illuminated.

Manual settings

Climate control system settings can

be changed by activating the

following functions:

Fan speed Z

Adjust the air flow by turning rotary

knob Z to the desired speed. Turn left

to decrease or turn right to increase.

Fan speed can also be changed by

touch buttons in the climate settings

display. Press MENU to enter the

menu.
Turning rotary knob Z anticlockwise:

fan and cooling are switched off.
To return to automatic mode, press

AUTO.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

126

Climate control

Air distribution l, M, K

Press MENU to enter the menu.
Touch (in the Colour-Info-Display):
l

: to windscreen and front door

windows

M

: to head area and rear seats via

adjustable air vents

K

: to front and rear foot well and

windscreen

To return to automatic air distribution,

press AUTO.

Temperature preselection £

Set the preselected temperatures

separately for driver and front

passenger to the desired value using

the left and right control dials. The dial

on the passenger side changes the

temperature for the passenger side.

The dial on the driver's side changes

the temperature for the driver's side or

for both sides depending on

activation of synchronisation MONO

in the climate settings menu. Press

MENU to enter the menu.
Recommended temperature is 22 °C.

Temperature is indicated in displays

beside the control dials and in the

climate settings menu.

If the minimum temperature Lo is set,

the climate control system runs at

maximum cooling, if cooling A/C is

switched on.
If the maximum temperature Hi is set,

the climate control system runs at

maximum heating.

Note

If A/C is switched on, reducing the

set cabin temperature can cause the

engine to restart from an Autostop or

inhibit an Autostop.

Stop-start system 3 138.

Dual zone temperature

synchronisation MONO or SYNC

Press MENU to enter the menu.

Touch MONO or SYNC to link

passenger side temperature setting

to the driver side.
When passenger side control dial will

be adjusted, synchronisation is

deactivated.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate control

127

Air conditioning A/C

Press A/C to switch on cooling. The

LED in the button illuminates to

indicate activation. Cooling is only

functional when the engine is running

and climate control fan is switched on.
Press A/C again to switch off cooling.
The air conditioning system cools and

dehumidifies (dries) when outside

temperature is above a specific level.

Therefore condensation may form

and drip from under the vehicle.
If no cooling or drying is required,

switch off the cooling system for fuel

saving reasons.

Manual air recirculation 4

Press 4 to activate the air

recirculation mode. The LED in the

button illuminates to indicate

activation.
Press 4 again to deactivate

recirculation mode.

9 Warning

The exchange of fresh air is

reduced in air recirculation mode.

In operation without cooling, the

air humidity increases, so the

windows may mist up from inside.

The quality of the passenger

compartment air deteriorates,

which may cause the occupants to

feel drowsy.

In warm and very humid ambient air

conditions, the windscreen may mist

up from outside, when cold air is

directed towards it. If windscreen

mists up from outside, activate

windscreen wiper and deactivate l.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

128

Climate control

Demisting and defrosting the

windows à

● Press à. The LED in the button

illuminates to indicate activation.

● Temperature and air distribution

are set automatically and the fan

runs at high speed.

● Switch on air conditioning by

pressing A/C, if required.

● Switch on heated rear window b.
● Switch on heated

windscreen ,.

● To return to previous mode press

à

 again, to return to automatic

mode press AUTO.

Note

If à is pressed while the engine is

running, an Autostop will be inhibited

until à is pressed again.
If à is pressed while the engine is in

an Autostop, the engine will restart

automatically.

Stop-start system 3 138.

Deactivation of Electronic climate

control system

Cooling, fan and automatic mode can

be switched off by turning control dial
Z

 anticlockwise.

Activation by switching on the fan or

pressing AUTO.

Heated rear window, windscreen

and exterior mirrors b

3

 39

Heated seats ß

3

 47.

Auxiliary heater

Air heater

Quickheat is an electric auxiliary air

heater which automatically warms up

the passenger compartment more

quickly.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate control

129

Air vents

Adjustable air vents

Centre air vents in the instrument

panel

Direct the flow of air by tilting and

swivelling the slats.
To close the vent, swivel the slats

inwards.

Outer air vents in the instrument

panel

Direct the flow of air by tilting and

swivelling the slats.
To close the vent, swivel the slats

outwards.

Centre air vent on top of the

instrument panel

Close air flow by turning the thumb

wheel to the front.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

130

Climate control

Air vent in the glovebox

The air vent can be opened or closed

by turning.
At least two air vents must be open

while cooling is on.

9 Warning

Do not attach any objects to the

slats of the air vents. Risk of

damage and injury in case of an

accident.

Fixed air vents

Additional air vents are located

beneath the windscreen and door

windows and in the foot wells.

Maintenance

Air intake

The air intake in front of the

windscreen in the engine

compartment must be kept clear to

allow air intake. Remove any leaves,

dirt or snow.

Cabin air filter

Change filter regulary for maximum

effect.
More frequent passenger

compartment air filter replacement

may be needed, if you drive in areas

with heavy traffic, poor air quality,

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate control

131

areas with high dust levels or which

are sensitive to environmental

allergens.
Passenger compartment air filter

replacement may also be needed if

there is reduced air flow, windows

fogging up, or odors.
Your dealer can help to determine

when it is the right time to replace the

filter.

Air conditioning regular

operation

In order to ensure continuously

efficient performance, cooling must

be operated for a few minutes once a

month, irrespective of the weather

and time of year. Operation with

cooling is not possible when the

outside temperature is too low.

Service

For optimal cooling performance, it is

recommended to annually check the

climate control system, starting

three years after initial vehicle

registration, including:

● functionality and pressure test
● heating functionality
● leakage check
● check of drive belts
● cleaning of condenser and

evaporator drainage

● performance check
● cabin air filter check

-------------------------------------------------------------------------------------------------------------------------------------------------------------

132

Driving and operating

Driving and

operating

Driving hints ............................... 133

Control of the vehicle ............... 133

Steering ................................... 133

Starting and operating ............... 133

New vehicle running-in ............ 133

Ignition switch positions ........... 133

Power button ........................... 134

Power saving mode ................. 135

Starting the engine .................. 136

Overrun cut-off ........................ 137

Stop-start system .................... 138

Parking .................................... 140

Engine exhaust .......................... 141

Diesel particle filter .................. 141

Catalytic converter ................... 141

AdBlue ..................................... 142

Automatic transmission .............. 145

Transmission display ............... 145

Selector lever .......................... 145

Manual mode ........................... 146

Electronic driving programmes 146

Fault ........................................ 147

Interruption of power supply .... 147

Manual transmission .................. 148
Brakes ........................................ 149

Antilock brake system ............. 149

Parking brake .......................... 149

Brake assist ............................. 150

Hill start assist ......................... 150

Ride control systems ................. 150

Electronic Stability Control and

Traction Control system ......... 150

Driver assistance systems ......... 152

Cruise control .......................... 152

Speed limiter ........................... 154

Forward collision alert ............. 156

Active emergency braking ....... 157

Front pedestrian protection ..... 159

Parking assist .......................... 161

Advanced parking assist ......... 164

Side blind spot alert ................. 169

Panoramic view system ........... 170

Rear view camera ................... 173

Lane departure warning .......... 174

Driver alert ............................... 176

Fuel ............................................ 177

Fuel for petrol engines ............. 177

Fuel for diesel engines ............ 178

Fuel for liquid gas operation .... 178

Refuelling ................................ 179

Trailer hitch ................................ 181

General information ................. 181

Driving characteristics and

towing tips .............................. 181

Trailer towing ........................... 181

Towing equipment ................... 182

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving and operating

133

Driving hints

Control of the vehicle

Never coast with engine not

running

Many systems will not function in this

situation (e.g. brake servo unit, power

steering). Driving in this manner is a

danger to yourself and others.
All systems function during an

Autostop.
Stop-start system 3 138.

Idle boost

If charging of the vehicle battery is

required due to battery condition, the

power output of the generator must

be increased. This will be achieved by

an idle boost which may be audible.
A message appears in the Driver

Information Centre.

Pedals

To ensure the pedal travel is

uninhibited, there must be no mats in

the area of the pedals.

Use only floor mats, which fit properly

and are fixed by the retainers on the

driver side.

Steering

If power steering assist is lost

because the engine stops or due to a

system malfunction, the vehicle can

be steered but may require increased

effort.

Starting and operating

New vehicle running-in

Do not brake unnecessarily hard for

the first few journeys.
During the first drive, smoke may

occur because of wax and oil

evaporating off the exhaust system.

Park the vehicle in the open for a

while after the first drive and avoid

inhaling the fumes.
During the running-in period, fuel and

engine oil consumption may be

higher.
Additionally, the cleaning process of

the diesel particle filter may take

place more often.
Diesel particle filter 3 141.
Autostop may be inhibited to allow

charging of the vehicle battery.

Ignition switch positions

Turn key:

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     6      7      8      9     ..
