EXT-26

< REMOVAL AND INSTALLATION >

RUNNING BOARDS

REMOVAL

1. Remove the bolts and remove the running board from running board brackets.
2. Remove the screw and remove the end cap.

• Remove the reinforcement from end cap.

3. Release the clips and remove the step pad from the running board.
4. Remove the nuts and bolts and remove the running board brackets.

INSTALLATION

Installation is in the reverse order of removal.

MUDGUARD

EXT-27

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

EXT

N

O

P

MUDGUARD

Removal and Installation

INFOID:0000000009879101

NOTE:

Crew Cab shown King Cab similar.

WIIA0995E

EXT-28

< REMOVAL AND INSTALLATION >

DOOR OUTSIDE MOLDING

DOOR OUTSIDE MOLDING

Removal and Installation

INFOID:0000000009879102

1.

Front door outside molding LH

2.

Screw

3.

Hole cover

4.

Front door LH

5.

Rear door outside molding LH

6.

Rear door-Crew cab

WIIA0996E

DOOR OUTSIDE MOLDING

EXT-29

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

EXT

N

O

P

FRONT DOOR OUTSIDE MOLDING

Removal

1. Open the window fully.
2. Remove the door mirror. Refer to

MIR-15, "Door Mirror Assembly"

.

3. Remove the molding

1. Remove the hole cover and screw.

2. Lift the molding from the rear side.

3. Disconnect the clips from flange.

Installation

Installation is in the reverse order of removal.

REAR DOOR OUTSIDE MOLDING

Removal

1. Open the window fully.
2. Remove the molding.

1. Remove the hole cover and screw.

2. Lift the molding from the rear side.

3. Disconnect the clips from flange.

Installation

Installation is in the reverse order of removal.
