TIMING CHAIN COVER EM-49 < REMOVAL AND INSTALLATION > C D E F G H I J K L M A EM N P O 10. Remove the front cover. CAUTION: Do not damage mating surfaces. 11. Remove the front oil seal using suitable tool. CAUTION: Do not damage front cover. 12. Remove chain tensioner cover using Tool (if necessary). INSTALLATION 1. Install the front oil seal using suitable tool. CAUTION: Do not scratch or make burrs on the circumference of the oil seal. 2. Install the chain tensioner cover (if removed). • Apply liquid gasket as shown. Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-15, "Recommended Chemical Products and Sealants" . 3. Install the front cover as follows: Tool number : KV10111100 (J-37228) KBIA2478E Tool number : KV10111100 (J-37228) PBIC0059E KBIA2547E KBIA2516E |
