EM-8

< PREPARATION >

[HR16DE]

PREPARATION

Spark plug wrench

Removing and installing spark plug
a: 14 mm (0.55 in)

Pulley holder

Crankshaft pulley removing and installing

Valve seat cutter set

Finishing valve seat dimensions

Piston ring expander

Removing and installing piston ring

Valve guide drift

Removing and installing valve guide

Valve guide reamer

(1): Reaming valve guide inner hole
(2): Reaming hole for oversize valve guide

(J-43897-18)
(J-43897-12)
Oxygen sensor thread cleaner

Reconditioning the exhaust system threads
before installing a new air fuel ratio sensor
(Use with anti-seize lubricant shown below.)
A: [18 mm (0.71 in) dia.] for zirconia heated
oxygen sensor
B: [12 mm (0.47 in) dia.] for titania heated
oxygen sensor
C: Mating surface shave cylinder
D: Flutes

Tool name

Description

JPBIA0399ZZ

NT035

S-NT048

S-NT030

PBIC4012E

PBIC4013E

JPBIA0238ZZ

PREPARATION

EM-9

< PREPARATION >

[HR16DE]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

Acoustic tension gauge

Checking drive belt tension

Anti-seize lubricant (Permatex 133AR
or equivalent meeting MIL specifica-
tion MIL-A-907)

Lubricating oxygen sensor thread cleaning
tool when reconditioning exhaust system
threads

Manual lift table caddy

Removing and installing engine

1. Compression gauge
2. Adapter

Checking compression pressure

Tube presser

Pressing the tube of liquid gasket

Tool name

Description

PBIC3881E

AEM489

ZZA1210D

ZZA0008D

S-NT052

EM-10

< BASIC INSPECTION >

[HR16DE]

CAMSHAFT VALVE CLEARANCE

BASIC INSPECTION

CAMSHAFT VALVE CLEARANCE

Inspection and Adjustment

INFOID:0000000009444709

INSPECTION

Perform inspection as follows after removal, replacement or installation of camshaft or valve-related parts, or if

there are unusual engine conditions regarding valve clearance.
1. Remove rocker cover. Refer to

EM-48, "Removal and Installation"

.

2. Measure the valve clearance with the following procedure:
a. Set No. 1 cylinder at TDC of its compression stroke.

• Rotate crankshaft pulley (2) clockwise and align TDC mark (no

paint) (A) to timing indicator (1) on front cover.

• At the same time, check that both intake and exhaust cam

lobes of No. 1 cylinder face inside (

) as shown.

• If the lobes do not face inside, rotate the crankshaft pulley 360

degrees to align as shown.

b. Using suitable tool (A) measure the clearance between the valve

lifter and camshaft.

(B)

: White paint mark (Not used for service)

PBIC3673E

(1)

: Camshaft (INT)

(2)

: Camshaft (EXH)

: Engine front

JPBIA4738ZZ

Valve clearance

: Refer to

EM-116, "Camshaft"

.

JPBIA4116ZZ

CAMSHAFT VALVE CLEARANCE

EM-11

< BASIC INSPECTION >

[HR16DE]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

• Measure the valve clearances at locations marked “

×” [loca-

tions indicated with (

)] as shown using suitable tool.

c. Set No. 4 cylinder at TDC of its compression stroke.

• Rotate crankshaft pulley (2) one revolution (360 degrees) and

align TDC mark (no paint) (A) to timing indicator (1) on front

cover.

• Measure the valve clearances at locations marked “

×” [loca-

tions indicated with (

)] as shown using suitable tool.

3. If out of the specifications, adjust as necessary. Refer to “ADJUSTMENT”.

ADJUSTMENT

NOTE:

Proper valve clearance is obtained by selecting the correct valve lifter head thickness.
1. Remove camshaft. Refer to

EM-60, "Exploded View"

.

2. Remove valve lifters from the locations that are out of the standard.

(A)

: No. 1 cylinder

(B)

: No. 2 cylinder

(C)

: No. 3 cylinder

(D)

: No. 4 cylinder

JPBIA4117ZZ

Measuring position

No. 1 CYL.

No. 2 CYL.

No. 3 CYL.

No. 4 CYL.

No. 1 cylinder at compression TDC

EXH

×

×

INT

×

×

(B)

: White paint mark (Not use for service)

PBIC3673E

(A)

: No. 1 cylinder

(B)

: No. 2 cylinder

(C)

: No. 3 cylinder

(D)

: No. 4 cylinder

JPBIA4118ZZ

Measuring position

No. 1 CYL.

No. 2 CYL.

No. 3 CYL.

No. 4 CYL.

No. 4 cylinder at compression TDC

EXH

×

×

INT

×

×
