BR-6

< SYMPTOM DIAGNOSIS >

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000011279858

Use the chart below to find the cause of the symptom. If necessary, repair or replace these parts.

×: Applicable

Reference page

BR-1

1

,

BR

-1

3

BR-1

1

,

BR

-1

3

BR-1

1

,

BR

-1

3

BR-1

1

,

BR

-1

3

BR-1

1

,

BR

-1

3

BR-1

1

,

BR

-1

3

BR-1

1

,

BR

-1

3

BR-1

1

,

BR

-1

3

DL

N

-98

 (A

WD)

DLN-1

11

 (A

WD)

FS

U-

5

RSU-4

WT

-62

FAX-6

 (FW

D

),

F

AX-44

 (A

WD)

RAX-5

 (FW

D

),

RAX-13

 (A

W

D

)

ST

-5

Possible cause and
SUSPECTED PARTS

Bra

ke

 p

ad

- da

m

age

d

Bra

ke

 p

ad

- un

ev

en

 we

ar

Shi

ms

 da

ma

ge

d

Di

sc

 b

rak

e ro

to

r im

ba

la

nc

e

Di

sc

 b

rak

e ro

to

r da

ma

ge

Disc

brake rot

or runout

Di

sc

 b

rak

e ro

to

r de

fo

rma

tio

n

Di

sc

 b

rak

e ro

to

r de

fle

ct

io

n

Disc

brake rot

or rust

Di

sc

 b

rak

e ro

to

r th

ickn

es

s va

riati

o

n

PROPELLER SHAFT

DIFF

ERENTIAL

FRONT S

U

SPENSION

REAR S

U

SPENSION

WHEE

LAND TIRE

DRIVE SHAFT

STE

E

RING

Symptom BRAKE

Noise

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

Shimmy,
Shudder

×

×

×

×

×

×

×

×

×

×

×

BRAKE PEDAL

BR-7

< BASIC INSPECTION >

C

D

E

G

H

I

J

K

L

M

A

B

BR

N

O

P

BASIC INSPECTION

BRAKE PEDAL

Inspection

INFOID:0000000011279859

BRAKE PEDAL HEIGHT

Check the brake pedal height (H) between the dash lower panel (3) and the brake pedal upper surface.

CAUTION:

Check the brake pedal height with the floor trim removed.

Brake pedal height (H) from dash lower panel (3)

Refer to

BR-58, "Brake Pedal"

.

Clearance (A) between brake pedal stopper bracket (2), stop lamp switch (4) and brake
pedal position switch (1) contact ends

Refer to

BR-58, "Brake Pedal"

.

Brake pedal full stroke (S)

Refer to

BR-58, "Brake Pedal"

.

Brake pedal play (P)

Refer to

BR-58, "Brake Pedal"

.

ALFIA0437ZZ

BR-8

< BASIC INSPECTION >

BRAKE FLUID

BRAKE FLUID

Inspection

INFOID:0000000011279860

BRAKE FLUID LEVEL

• Make sure that the brake fluid level in the reservoir tank is between

the MAX and MIN lines.

• Visually check around the reservoir tank for brake fluid leakage.

• If the brake fluid level is excessively low, check the brake system

for leakage.

• If brake warning lamp remains illuminated after parking brake

pedal is released, check the brake system for brake fluid leakage.

BRAKE LINE

1. Check brake line (tubes and hoses) for cracks, deterioration or other damage. Replace any damaged

parts.

2. Check for brake fluid leakage by fully depressing brake pedal

while engine is running.

CAUTION:

If brake fluid leakage occurs around joints, retighten or

replace damaged parts as necessary.

JPFIA0007ZZ

SBR389C

BRAKE MASTER CYLINDER

BR-9

< BASIC INSPECTION >

C

D

E

G

H

I

J

K

L

M

A

B

BR

N

O

P

BRAKE MASTER CYLINDER

Inspection

INFOID:0000000011279861

Check for brake fluid leakage at the following areas:

• Master cylinder mounting face

• Reservoir tank mounting face

• Brake tube and brake tube connections

• Brake hose and brake hose connections

If any brake fluid leakage is found, repair as necessary.
