Nissan Rogue. Manual - part 107
BCS-34
< ECU DIAGNOSIS INFORMATION >
[WITH INTELLIGENT KEY SYSTEM]
BCM
12
(W)
Ground Auto light power supply 5V
Output
Push-button
ignition switch
OFF
0V
ON
5V
16
(P)
Ground Audio dongle
Input/
Output
Push-button
ignition switch
OFF
5V
17
(L)
Ground
CVT shift selector park po-
sition switch power
Output
Selector lever
P position
0V
Except P position
Battery voltage
19
(LG)
Ground Auto light signal
Input
Push-button
ignition switch
ON
Outside of vehicle is
bright
Close to 5V
Outside of vehicle is
dark
Close to 0V
23
(G)
Ground Power window relay control
Output
Push-button
ignition switch
OFF
Battery voltage
ON
0V
24
(LA/R)
Ground
Rear window defogger re-
lay control
Output
Rear window
defogger
Not activated
Battery voltage
Activated
0V
25
(BR)
Ground Accessory relay-1 control
Output
Push-button
ignition switch
OFF
Battery voltage
ON
0V
27
(Y)
Ground Ignition relay-1 control
Output
Push-button
ignition switch
OFF
Battery voltage
ON
0V
28
(LA/W)
Ground
Front blower motor relay
control
Output
Push-button
ignition switch
OFF
Battery voltage
ON
0V
30
(V)
Ground Auto light reference ground
Output
Push-button
ignition switch
ON
0V
33
(LG)
Ground
Combination switch output
5
Output
Combination
switch
(Wiper inter-
mittent dial 1)
OFF
7.0 – 8.0V
INT VOLUME 2
1.2V
INT VOLUME 3
RR WIPER INT
RR WIPER ON
34
(Y)
Ground Combination switch input 5
Input
Combination
switch
(Wiper inter-
mittent dial 1)
OFF
0V
FR FOG
1.0V
TAIL LAMP
TURN RH
NO LIGHT
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
Signal name
Input/
Output
(+)
(-)
PKIB4960J
PKIB4958J
PKIB4958J
