Nissan Altima HL32 Hybrid. Manual - part 202
TRUNK OPEN FUNCTION
DLK-29
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
L
M
A
B
DLK
N
O
P
The outside key antenna detection area of trunk open function is in
the range of approximately 80 cm (31.50 in) surrounding Trunk
opener request switch (1). However, this operating range depends
on the ambient conditions.
KEY REMINDER FUNCTION
*:If the door closing impact shocks the door lock knob, or contacts against baggage with the door lock knob might activate the door locks
accidentally but unlock operation will be perform at these cases.
CAUTION:
• The above function operates when the Intelligent Key is inside the vehicle. However, there may be
times when the Intelligent Key cannot be detected, and this function will not operate when the Intelli-
gent Key is on the instrument panel, rear parcel shelf, or in the glove box. Also, this system some-
times does not operate if the Intelligent Key is in the door pocket for the open door.
• When the key reminder function is operated when the trunk is opened/closed and the buzzers
sound, if the following operations are performed, the key reminder function is cleared and buzzer
sounds are stopped.
- Remote controller door lock button operation of Intelligent Key
- Remote controller door unlock button operation of Intelligent Key
- When the trunk is closed, the Intelligent Key is not inside the vehicle
- When any door is open
HAZARD AND BUZZER REMINDER FUNCTION
During trunk opening operation by request switch, the hazard warning lamps and Intelligent Key warning
buzzer will flash or honk as a reminder.
When trunk open by each request switch, IPDM E/R honks Intelligent Key warning buzzer as a reminder and
transmits hazard request signal to BCM via CAN communication line.
BCM flashes hazard warning lamps as a reminder.
Operating function of hazard and buzzer reminder
How to change hazard and buzzer reminder mode
With CONSULT-III
DLK-52, "INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)"
.
LIST OF OPERATION RELATED PARTS
Parts marked with
× are the parts related to operation.
JMKIA0102GB
Key reminder function
Operation condition
Operation
Trunk is closed
Right after trunk is closed under the following conditions
• Intelligent Key is inside trunk room
• All doors are closed
• All doors are locked
• Trunk open
• Honk Intelligent Key warning
buzzer
Operation
Hazard warning lamp flash
Intelligent Key warning buzzer honks
Trunk open
—
Four times
