Nissan Frontier. Manual - part 41

AV-156

< REMOVAL AND INSTALLATION >

[DISPLAY AUDIO WITHOUT AMPLIFIER]

SATELLITE RADIO ANTENNA

SATELLITE RADIO ANTENNA

Removal and Installation

INFOID:0000000009482136

REMOVAL

1. Remove the roof console. Refer to

INT-25, "Removal and Installation"

.

2. Disconnect the harness connector from the satellite radio antenna.
3. Remove the satellite radio antenna nut.
4. Remove the satellite radio antenna.

INSTALLATION

Installation is in the reverse order of removal.

LKIA0679E

AV

USB CONNECTOR

AV-157

< REMOVAL AND INSTALLATION >

[DISPLAY AUDIO WITHOUT AMPLIFIER]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

USB CONNECTOR

Removal and Installation

INFOID:0000000009482137

REMOVAL

1. Remove the center console assembly. Refer to

IP-26, "Removal and Installation"

.

2. Push the pawl from the back of the center console to remove the USB interface.

INSTALLATION

Installation is in the reverse order of removal.

AV-158

< REMOVAL AND INSTALLATION >

[DISPLAY AUDIO WITHOUT AMPLIFIER]

REAR VIEW CAMERA

REAR VIEW CAMERA

Removal and Installation

INFOID:0000000009482138

REMOVAL

1. Remove the tail gate protector. Refer to

EXT-38, "Removal and Installation"

.

2. Remove the rear view camera screws and the rear view camera.

INSTALLATION

Installation is in the reverse order of removal.

AV

COMPONENT PARTS

AV-159

< SYSTEM DESCRIPTION >

[DISPLAY AUDIO WITH AMPLIFIER]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

SYSTEM DESCRIPTION

COMPONENT PARTS

Component Parts Location

INFOID:0000000009482139

AWNIA2918ZZ
