BRM-34

< REMOVAL AND INSTALLATION >

REPLACEMENT OPERATIONS

Roof

INFOID:0000000009758081

REMOVAL

1. Remove the headlining. Refer to

INT-40, "Removal and Installation"

.

Replacement parts

z

Roof panel

Front

ALKIA2779ZZ

REPLACEMENT OPERATIONS

BRM-35

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

2. Remove the roof side moldings (RH/LH). Refer to

EXT-32, "Removal and Installation"

.

3. Remove the windshield glass. Refer to

GW-12, "Removal and Installation"

.

4. Remove the rear window glass. Refer to

GW-26, "Removal and Installation"

.

5. Drill out spot welds using a 8.0 mm (0.31 in) spot weld removing bit (A) on the windshield and rear window

glass flanges.

NOTE:

Only drill through the first layer of metal (the roof outer panel)

6. Use an angle head grinder and a 3.18 mm (0.125 in) cutting wheel (A) to grind through the first layer only.

NOTE:

Only grind through the first layer of metal (the roof outer panel)

ALKIA2824ZZ

BRM-36

< REMOVAL AND INSTALLATION >

REPLACEMENT OPERATIONS

7. Remove roof panel (1).

PREPARATION

ALKIA2825ZZ

ALKIA2543ZZ

REPLACEMENT OPERATIONS

BRM-37

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

1. Grind all mating surfaces around the roof flanges.
2. Test panel for proper alignment and fit.
3. Remove panel.
4. Compare to the removed panel, then drill 8.0 mm (0.31 in) holes in the same location on the new roof

panel.

5. Use 3M weld through primer to prime body side upper and the front and rear window flanges

INSTALLATION

1.

Weld through primer

Front

ALKIA2542ZZ
