CAUTION:
●
Always replace exhaust gaskets with new ones when
reassembling.
Scrape off all residue of old gasket from flange surface.
●
With engine running, check all tube connections for
exhaust gas leaks, and entire system for unusual noises.
●
After installation, check to ensure that mounting brack-
ets and mounting insulators are free from undue stress.
If any of the above parts are not installed properly,
excessive noise or vibration may be transmitted to the
vehicle body.
SFE180A
NFE079
QG engine models
SEC. 200
⋅
208
12.7 - 15.7 (1.30 - 1.60, 9.4 11.6)
51.0 - 64.7 (5.20 - 6.60,
37.6 - 47.7)
30 - 35
(3.1 - 3.5,
23 - 25)
5.1 - 6.4
(0.52 - 0.65,
45.1 - 56.6)
Gasket
Gasket
Gasket
51.0 - 64.7 (5.20 - 6.60, 37.6 - 47.7)
36.3 - 45.1 (3.7 - 4.6, 26.8 - 33.3)
Gasket
12.7 - 15.7 (1.30 - 1.60, 9.4 - 11.6)
: N·m (kg-m, ft-lb)
: N·m (kg-m, in-lb)
: Do not re-use
5.1 - 6.4 (0.52 - 0.65, 45.1 - 56.6)
5.1 - 6.4
(0.52 - 0.65,
45.1 - 56.6)
40 - 60
(4.1 - 6.1,
30 - 44)
Catalyst
Without catalyst
EXHAUST SYSTEM
FE-9
