PG-64 < COMPONENT DIAGNOSIS > HARNESS B3 D405 W/8 : To D501 D3 D550 W/8 : To D451 A3 D406 — : Body ground D3 D551 W/4 : Rear view camera C1 D408 W/4 : To D601 D4 D552 GR/2 : Back door request switch C1 D409 W/1 : To D650 E4 D554 — : Body ground F3 D450 W/8 : To B107 Rear window sub-harness E3 D451 W/8 : To D550 C1 D601 W/4 : To D408 E3 D455 — : Body ground D2 D602 W/4 : Rear wiper motor Back door harness E1 D603 — : Body ground C3 D501 W/8 : To D405 F2 D604 B/1 : Rear window defogger C4 D502 W/4 : Back door latch D1 D605 W/2 : High-mounted stop lamp D2 D503 B/1 : Glass hatch ajar switch Back door LH harness D3 D504 — : Body ground B1 D650 W/1 : To D409 C4 D505 W/4 : To D404 B2 D651 B/1 : Rear window defogger D4 D506 BR/2 : License plate lamp LH 2010 Pathfinder |
