Nissan Pathfinder (2010 year). Manual - part 528

PG-56

< COMPONENT DIAGNOSIS >

HARNESS

BODY NO. 2 HARNESS

ABMIA1378GB

A2

B105

W/6

: Rear combination lamp RH

E4

B137

W/3

: Belt tension sensor

E3

B106

W/12

: To D301

A2

B138

B/3

: Rear cargo power socket

A2

B107

W/8

: To D450

G4 B141

W/3

: Front seat heater RH (without front
  passenger power seat)

E4

B108

W/3

: Front door switch RH

G5 B149

SMJ

: To M36

E5

B110

W/3

: Seat belt buckle switch RH

F4

B154

W/16

: To B303 (with front passenger power seat)

2010 Pathfinder

PG

HARNESS

PG-57

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

F3

B113

Y/12

: Air bag diagnosis sensor unit

B2

B155

B/6

: Air mix door motor (rear)

E5

B114

Y/2

: RH side air bag (satellite) sensor

G3 B157

Y/2

: B78

C2 B116

W/3

: Rear door switch RH

B2

B175

W/2

: To B500

F5

B117

—

: Body ground

B3

B176

W/16

: Rear view camera control unit

E4

B124

W/32

: Bluetooth control unit

Front seat RH harness

F5

B125

W/8

: Bluetooth control unit

F4

B303

W/16

: To B154

F5

B126

Y/2

: Front RH side air bag module

F3

B307

W/3

: Front seat heater RH (with front passenger
  power seat)

D4 B127

Y/2

: Front RH seat belt pre-tensioner

E4

B308

W/6

: Power seat switch RH

B2

B128

Y/2

: RH side rear curtain air bag module

F3

B309

GR/2

: Sliding motor RH

B2

B129

GR/2

: Luggage area antenna

E4

B311

W/2

: Reclining motor RH

G4 B131

W/2

: To M162

F4

B351

W/8

: To B136

A1

B132

—

: Body ground

E4

B352

B/3

: Occupant classification system sensor

A2

B133

W/4

: Variable blower control (rear)

F4

B353

B/18

: Occupant classification system control unit

F4

B136

W/8

: To B351

2010 Pathfinder

PG-58

< COMPONENT DIAGNOSIS >

HARNESS

ROOM LAMP HARNESS

ABMIA0351GB

C5 R1

W/24

: To M1

C4 R8

W/4

: Microphone

C3 R2

B/10

: Rear air control (front)

C3 R9

W/3

: Front room/map lamp assembly

D3 R4

W/3

: Sunroof switch

D2 R10

W/3

: Personal lamp 2nd row

2010 Pathfinder

PG

HARNESS

PG-59

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

FRONT DOOR LH HARNESS

B4

R6

W/7

: Auto anti-dazzling inside mirror
  (without HOMELINK® universal
  transceiver

E1

R11

W/2

: Cargo lamp

C4 R7

B/10

: Auto anti-dazzling inside mirror
  (with HOMELINK® universal
  transceiver

E2

R12

W/2

: Room lamp 2nd row

ABMIA0352GB

D1

W/24

: To M9

D12

W/2

: Front door speaker LH

D2

BR/12

: To M8

D14

GR/6

: Front door lock assembly LH

D4

B/10

: Door mirror LH (with heated mirrors)

D15

GR/2

: Front outside antenna LH

D5

W/8

: Seat memory switch

D16

GR/2

: Front door request switch LH

D7

W/16

: Main power window and door lock/unlock switch

D17

B/3

: Door mirror LH (without heated mirrors)

D8

W/3

: Main power window and door lock/unlock switch

D18

B/10

: Door mirror LH (with automatic drive positioner)

D9

B/6

: Front power window motor LH

2010 Pathfinder

PG-60

< COMPONENT DIAGNOSIS >

HARNESS

FRONT DOOR RH HARNESS

ABMIA0353GB

D101

W/12

: To M75

D114

W/2

: Front door lock actuator RH

D102

W/16

: To M74

D115

GR/2

: Front outside antenna RH

D103

B/3

: Front door lock assembly RH (door unlock
  sensor)

D116

GR/2

: Front door request switch RH

D104

B/6

: Front power window motor RH

D117

B/3

: Door mirror RH (without heated mirrors)

D105

W/16

: Power window and door lock/unlock
  switch RH

D118

B/10

: Door mirror RH (with automatic drive
  positioner)

D107

B/10

: Door mirror RH (with heated mirrors)

D119

W/2

: Front door lock assembly RH (door unlock
  actuator)

D112

W/2

: Front door speaker RH

2010 Pathfinder

PG

HARNESS

PG-61

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

REAR DOOR LH HARNESS

ABMIA1379GB

D201

W/12

: To B6

D207 BR/2

: Rear door speaker LH (with BOSE audio system)

D203

W/8

: Rear power window switch LH

D208 BR/2

: Rear tweeter LH

D204

B/2

: Rear power window motor LH

D209 W/2

: Rear door speaker LH (without BOSE
  audio system)

D205

W/2

: Rear door lock actuator LH

2010 Pathfinder

PG-62

< COMPONENT DIAGNOSIS >

HARNESS

REAR DOOR RH HARNESS

ABMIA1380GB

D301

W/12

: To B106

D307

BR/2

: Rear door speaker RH (with BOSE audio system)

D303

W/8

: Rear power window switch RH

D308

BR/2

: Rear tweeter RH

D304

B/2

: Rear power window motor RH

D309

W/2

: Rear door speaker RH (without BOSE
  audio system)

D305

W/2

: Rear door lock actuator RH

2010 Pathfinder

PG

HARNESS

PG-63

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

BACK DOOR HARNESS

ABMIA1381GB

Back door No. 2 harness

E4

D507

BR/2

: License plate lamp RH

A2

D401

W/8

: To B43

D3 D508

W/4

: Glass hatch lock actuator

A2

D402

W/6

: To B48

D4 D510

BR/2

: Back door opener switch (without Intelligent
  key system)

C4 D404

W/4

: To D505

D4 D511

BR/2

: Back door opener switch (with Intelligent
  key system)

2010 Pathfinder
