PG-48

< COMPONENT DIAGNOSIS >

HARNESS

E2

E9

—

: Body ground

F5

E101

B/2

: Front fog lamp LH

E3

E11

B/3

: Front headlamp LH (without daytime
  light system)

C1

E125

B/47

: ABS actuator and electric unit (control
  unit) (with VQ40DE)

D1 E14

—

: Body ground

E2

E126

—

: Body ground

F2

E17

GR/2 : Front side marker lamp LH

C1

E127

B/47

: ABS actuator and electric unit (control
  unit) (with VK56DE)

B4

E18

GR/2 : Front wheel sensor LH

A2

E141

B/2

: Heater pump

C1 E21

GR/2 : Brake fluid level switch

C1

E153

W/2

: Transfer motor relay

A1

E23

GR/5 : Front wiper motor

C1

E154

W/2

: Transfer motor relay

2010 Pathfinder

PG

HARNESS

PG-49

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

ENGINE CONTROL HARNESS (VQ40DE)

ABMIA1375GB

C5 F3

B/1

: A/C Compressor

G2

F55

B/2

: ATP switch (all-mode 4WD system)

D2 F5

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 1)

G1

F56

B/8

: Transfer terminal cord assembly

D4 F6

GR/3

: Ignition coil No. 2 (with power transistor)

G1

F57

B/2

: Transfer motor

D4 F7

GR/3

: Ignition coil No. 4 (with power transistor)

G1

F58

GR/6

: Transfer control device (all-mode
  4WD system)

2010 Pathfinder

PG-50

< COMPONENT DIAGNOSIS >

HARNESS

E4

F8

GR/3

: Ignition coil No. 6 (with power transistor)

F1

F59

B/2

: Wait detection switch (all-mode 4WD
  system)

E2

F9

G/10

: A/T assembly

F1

F60

GR/2

: Neutral 4LO switch (all-mode 4WD system)

D4 F10

—

: Engine ground

E4

F65

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 2)

C2 F11

B/3

: Crankshaft position sensor (POS)

D1

F66

G/3

: Camshaft position sensor (PHASE) (bank 1)

F3

F12

G/4

: Heated oxygen sensor 2 (bank 2)

C2

F67

L/4

: To F250

E2

F13

L/4

: Heated oxygen sensor 2 (bank 1)

G2

F71

B/2

: ATP switch (part time 4WD system)

B1

F14

W/24

: To E5

G1

F72

B/8

: Transfer control device (part time 4WD
  system)

C4 F15

L/2

: EVAP canister purge volume control
  solenoid valve

F1

F73

GR/2

: Wait detection switch (part time 4WD
  system)

D4 F16

—

: Engine ground

F1

F74

GR/2

: 4LO switch (part time 4WD system)

C4 F18

GR/2

: Fuel injector No. 2

Injector sub-harness

C3 F19

B/2

: VIAS control solenoid valve

D2

F201

G/4

: To F44

D4 F20

GR/2

: Fuel injector No. 4

C3

F202

GR/2

: Fuel injector No. 1

D3 F21

W/2

: Condenser-1

C3

F203

GR/2

: Fuel injector No. 3

D3 F22

GR/2

: Fuel injector No. 6

C3

F204

GR/2

: Fuel injector No. 5

E3

F23

B/3

: Camshaft position sensor (PHASE)
  (bank 2)

Ignition coil sub-harness

D2 F24

GR/2

: Engine coolant temperature sensor

D2

F225

G/8

: To F26

C3 F26

G/8

: To F225

B3

F226

GR/3

: Ignition coil No. 1 (with power transistor)

B1

F32

W/16

: To E2

B3

F227

GR/3

: Ignition coil No. 3 (with power transistor)

B2

F33

W/16

: To E19

C3

F228

GR/3

: Ignition coil No. 5 (with power transistor)

D3 F44

G/4

: To F201

B3

F229

G/2

: Intake valve timing control solenoid
  valve (bank 1)

A4

F46

B/3

: Power steering pressure sensor

Knock sensor sub-harness

B3

F50

B/6

: Electric throttle control actuator

C3

F250

L/4

: To F67

D5 F51

G/2

: Intake valve timing control solenoid
  valve (bank 2)

C1

F251

B/2

: Knock sensor (bank 1)

C5 F53

B/6

: Mass air flow sensor

C5

F252

B/2

: Knock sensor (bank 2)

B1

F54

B/81

: ECM

2010 Pathfinder

PG

HARNESS

PG-51

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

ENGINE CONTROL HARNESS (VK56DE)

ABMIA1376GB

D5 F3

B/1

: A/C Compressor

E4

F49

GR/3

: Ignition coil No. 5 (with power transistor)

C5 F4

GR/1

: Oil pressure switch

C5

F50

B/6

: Electric throttle control actuator

B4

F6

GR/3

: Ignition coil No. 2 (with power transistor)

C2

F52

GR/3

: Ignition coil No. 8 (with power transistor)

C4 F7

GR/3

: Ignition coil No. 4 (with power transistor)

C4

F53

B/6

: Mass air flow sensor

C3 F8

GR/3

: Ignition coil No. 6 (with power transistor)

F1

F55

B/2

: ATP switch (all-mode 4WD system)

2010 Pathfinder

PG-52

< COMPONENT DIAGNOSIS >

HARNESS

E2

F14

G/10

: A/T assembly

G2

F56

B/8

: Transfer terminal cord assembly

D5 F10

—

: Engine ground

G1

F57

B/2

: Transfer motor (all-mode 4WD)

B2

F14

W/24

: To E5

F2

F58

GR/6

: Transfer control device (all-mode
   4WD system)

D5 F16

—

: Engine ground

F2

F59

B/2

: Wait detection switch (all-mode 4WD system)

E3

F17

GR/1

: Starter motor

F1

F60

GR/2

: Neutral-4LO switch (all-mode 4WD system)

C4 F18

GR/2

: Fuel injector No. 2

D5

F61

G/2

: Intake valve timing control solenoid valve
  (bank 1)

C4 F20

GR/2

: Fuel injector No. 4

C5

F62

B/3

: Intake valve timing control position sensor
  (bank 1)

D4 F21

W/2

: Condenser-1

C2

F63

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 2)

D3 F22

GR/2

: Fuel injector No. 6

C4

F64

B/3

: Intake valve timing control position sensor
  (bank 2)

D2 F25

B/3

: Camshaft position sensor (PHASE)

B3

F68

GR/2

: Water valve

E3

F27

G/4

: Heated oxygen sensor 2 (bank 1)

E4

F69

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 1)

D1 F28

G/4

: Heated oxygen sensor 2 (bank 2)

F1

F71

B/2

: ATP switch (part time 4WD system)

D3 F29

B/3

: Crankshaft position sensor (POS)

F2

F72

B/8

: Transfer control device (part time 4WD system)

C4 F30

GR/2

: Fuel injector No. 1

F2

F73

GR/2

: Wait detection switch (part time 4WD system)

D3 F31

GR/2

: Fuel injector No. 8

G1

F74

GR/2

: 4LO switch (part time 4WD system)

C2 F32

W/16

: To E2

B4

F75

G/2

: Intake valve timing control solenoid valve
  (bank 2)

C3 F33

W/16

: To E19

D4

F76

L/2

: EVAP canister purge volume control solenoid
  valve

B2

F35

W/2

: To E52

B4

F78

B/3

: Power steering pressure sensor

D4 F38

B/6

: To F275

B2

F79

B/81

: ECM

D4 F41

GR/2

: Fuel injector No. 3

Knock sensor sub-harness

D4 F42

GR/2

: Fuel injector No. 5

D2

F213 GR/2

: Engine coolant temperature sensor

E4

F43

GR/3

: Ignition coil No. 7 (with power transistor)

D3

F253 B/2

: Knock sensor (bank 1)

D3 F45

GR/2

: Fuel injector No. 7

C3

F254 B/2

: Knock sensor (bank 2)

E5

F47

GR/3

: Ignition coil No. 1 (with power transistor)

C5

F275 B/6

: To F38

E5

F48

GR/3

: Ignition coil No. 3 (with power transistor)

2010 Pathfinder

PG

HARNESS

PG-53

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

CHASIS HARNESS

ABMIA1377GB

F2

C1

SMJ

: To E41

Trailer sub-harness

D2 C5

GR/5

: Fuel level sensor unit and fuel pump

A4

C124

GR/8

: To C50

A3

C6

B/2

: EVAP canister vent control valve

B4

C125

GR/8

: To C51

A3

C7

GR/3

: EVAP control system pressure sensor

B4

C126

B/7

: Trailer (with trailer tow 7-pin)

C4 C13

GR/4

: Rear wheel sensor assembly

A4

C127

GR/2

: Rear bumper antenna

2010 Pathfinder

PG-54

< COMPONENT DIAGNOSIS >

HARNESS

BODY HARNESS

B3

C50

GR/8

: To C124

B4

C128

B/4

: Trailer (with trailer tow 4-pin)

B4

C51

GR/8

: To C125

A4

C150

B/2

: C52

A4

C52

B/2

: To C150

ABMIA0349GB

D4 B6

W/12

: To D201

B3

B77

W/18

: To M210

B5

B7

—

: Body ground

B4

B78

Y/2

: To B157

2010 Pathfinder

PG

HARNESS

PG-55

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

C3 B8

W/3

: Front door switch LH

B2

B80

W/2

: Vanity lamp LH

B3

B9

Y/12

: Air bag diagnosis sensor unit

B2

B81

W/2

: Vanity lamp RH

B4

B10

Y/2

: Front LH side air bag module

B1

B82

Y/2

: RH side front curtain air bag module

B5

B12

W/3

: Seat belt buckle switch LH

B2

B83

B/10

: Sunroof motor assembly

D4 B14

Y/2

: Front LH seat belt pre-tensioner

Front seat LH harness

C5 B15

Y/2

: LH side air bag (satellite) sensor

B5

B200

W/16

: To B37

F3

B18

W/3

: Rear door switch LH

C4 B202

W/32

: Driver seat control unit

G2 B19

—

: Body ground

C4 B203

W/16

: Driver seat control unit

G3 B35

W/6

: Rear combination lamp LH

C4 B204

GR/5

: Sliding motor LH (with automatic drive
  positioner)

B4

B37

W/16

: To B200

C4 B205

W/4

: To B231

C2 B38

Y/2

: LH side front curtain air bag module

B4

B206

GR/5

: Lifting motor (front) (with automatic drive
  positioner)

A4

B40

W/8

: To E34

C4 B207

GR/5

: Lifting motor (rear) (with automatic drive
  positioner)

B5

B42

W/2

: To E36

C5 B208

W/10

: Power seat switch LH (with automatic drive
  positioner)

G2 B43

W/8

: To D401

B4

B209

W/3

: Front seat heater LH

G2 B48

W/6

: To D402

C5 B211

W/10

: Power seat switch LH (without automatic
  drive positioner)

F2

B54

Y/2

: LH side rear curtain air bag module

C4 B214

GR/2

: Sliding motor LH (without automatic drive
  positioner)

A5

B69

SMJ

: To M40

D4 B215

W/2

: Reclining motor LH (without automatic
  drive positioner)

E3

B72

W/8

: Subwoofer

B4

B216

GR/2

: Lifting motor (front) (without automatic
  drive positioner)

C3 B73

B/6

: Yaw rate/side/decel G sensor

D4 B217

GR/2

: Lifting motor (rear) (without automatic drive
  positioner)

C4 B74

GR/8

: BOSE speaker amp.

C4 B231

W/4

: To B205

C4 B75

B/24

: BOSE speaker amp.

D4 B232

B/4

: Reclining motor LH (with automatic drive
  positioner)

C1 B76

W/16

: Video monitor
