DTC P0075, P0081 IVT CONTROL SOLENOID VALVE EC-179 C D E F G H I J K L M A EC 2006 Pathfinder DTC P0075, P0081 IVT CONTROL SOLENOID VALVE PFP:23796 Component Description UBS00KBT Intake valve timing control solenoid valve is activated by ON/OFF CONSULT-II Reference Value in Data Monitor Mode UBS00KBU Specification data are reference values. On Board Diagnosis Logic UBS00KBV DTC Confirmation Procedure UBS00KBW NOTE: WITH CONSULT-II 1. Turn ignition switch ON. 2. Select “DATA MONITOR” mode with CONSULT-II. 3. Start engine and let it idle for 5 seconds. 4. If 1st trip DTC is detected, go to EC-184, "Diagnostic Procedure" . WITH GST Following the procedure “WITH CONSULT-II” above. PBIB1842E MONITOR ITEM CONDITION SPECIFICATION INT/V SOL (B1) ● Engine: After warming up ● Shift lever: P or N ● Air conditioner switch: OFF ● No load Idle 0% - 2% 2,000 rpm Approx. 0% - 50% DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0075 Intake valve timing control An improper voltage is sent to the ECM ● Harness or connectors ● Intake valve timing control solenoid valve P0081 SEF058Y |
