REAR POWER WINDOW SWITCH

Exploded View

INFOID:0000000003857780

Removal and Installation

INFOID:0000000003857781

REMOVAL

1.

Remove the rear power window switch finisher (2).
Refer to

INT-36, "Exploded View"

 and

INT-36, "Removal and

Installation"

.

2.

Rear power window switch (1) is removed from rear power win-
dow switch finisher (2) using flat-bladed screw driver (A) etc.

CAUTION:

Never fold pawl of rear power window switch finisher.

INSTALLATION

Install in the reverse order of removal.

1.

Rear power window switch

2.

Rear power window switch finisher

JMKIA2562ZZ

JMKIA2563ZZ

PWO

PWO-1

ELECTRICAL & POWER CONTROL

C

D

E

F

G

H

I

J

K

L

B

SECTION

PWO

A

O

P

N

CONTENTS

POWER OUTLET

COMPONENT DIAGNOSIS  ..........................

2

CIGARETTE LIGHTER  .......................................

2

Wiring Diagram - CIGARETTE LIGHTER -  ...............

2

POWER SOCKET  ...............................................

4

Wiring Diagram - POWER SOCKET - .......................

4

PRECAUTION ...............................................

6

PRECAUTIONS ...................................................

6

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ..................................................................

6

ON-VEHICLE REPAIR ..................................

7

CIGARETTE LIGHTER  ......................................

7

Exploded View ..........................................................

7

Removal and Installation  ..........................................

7

POWER SOCKET  ..............................................

8

Exploded View ..........................................................

8

Removal and Installation  ..........................................

8

PWO-2

< COMPONENT DIAGNOSIS >

CIGARETTE LIGHTER

COMPONENT DIAGNOSIS

CIGARETTE LIGHTER

Wiring Diagram - CIGARETTE LIGHTER -
