Nissan Murano. Manual - part 124

AV-274

< SYMPTOM DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

NORMAL OPERATING CONDITION

Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other
sources, is not a malfunction.

NOTE:

• Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking

the signal.

• Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the

antenna and the waves reflected by mountains or buildings.

RELATED TO HANDS-FREE PHONE

Symptom

Cause and Counter measure

Cannot play

Check if the CD was inserted correctly.

Check if the CD is scratched or dirty.

Check if there is condensation inside the player, and if there is, wait until the condensation is gone
(about 1 hour) before using the player.

If there is a temperature increase error, the player will play correctly after it returns to the normal
temperature.

If there is a mixture of music CD files (CD-DA data) and MP3/WMA files on a CD, only the music
CD files (CD-DA data) will be played.

Files with extensions other than “.MP3 (.mp3)” or “.WMA (.wma)” cannot be played. In addition,
the character codes and number of characters for folder names and file names should be in com-
pliance with the specifications.

Check if the disc or the file is generated in an irregular format, This may occur depending on the
variation or the setting of MP3/WMA writing applications or other text editing applications.

Check if the finalization process, such as session close and disc close, is done for the disc.

Check if the CD is protected by copyright.

Disks recorded in live file system format are not supported. (For Microsoft Windows Vista, check
the settings.)

Poor sound quality

Check if the CD is scratched or dirty.

It takes a relatively long time before
the music starts playing.

If there are many folder or file levels on the MP3/WMA CD, or if it is a multisession disc, some
time may be required before the music starts playing.

Music cuts off or skips

The writing software and hardware combination might not match, or the writing speed, writing
depth, writing width might not match the specifications. Try using the slowest writing speed.

Skipping with high bit rate files

Skipping may occur with large quantities if data such as for high bit rate data.

Move immediately to the next song
when playing

When a non-MP3/WMA file has been given an extension of “.MP3 (.mp3)” or “.WMA (.wma)”
when play is prohibited by copyright protection, the player will skip to the next song.

The songs do not play back in the
desired order.

The playback order is the order in which the files were written by the software, so the files might
not play in the desired order.

Poor reception only from a certain
radio broadcast station.

Check incoming radio wave signal strength of applicable broadcast station.

Buzz/rattle sound from speaker

The majority of rattle sounds are not indicative of an issue with the speaker, usually something
nearby the speaker is causing the rattle.

NORMAL OPERATING CONDITION

AV-275

< SYMPTOM DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

Symptom

Cause and Counter measure

Does not recognize cellular phone connection. (No connection is
displayed on the display at the guide.)

Some Bluetooth

enabled cellular phones may not be recognized

by the in-vehicle phone module. Refer to “RELATED TO HANDS-
FREE PHONE (Check Compatibility)” of MULTI AV SYSTEM
SYMPTOM.

Cannot use hands-free phone

Customer will not be able to use a hands-free phone under the fol-
lowing conditions.
• The vehicle is outside of the telephone service area.
• The vehicle is in an area where it is difficult to receive radio

waves; such as in a tunnel, in an underground parking garage,
near a tall building or in a mountainous area.

• The cellular phone is locked to prevent it from being dialed.
NOTE:

While a cellular phone is connected through the Bluetooth

wire-

less connection, the battery power of the cellular phone may dis-

charge quicker than usual. The Bluetooth

Hands-Free Phone

System cannot charge cellular phones.

The other party's voice cannot be heard by hands-free phone.

When the radio wave condition is not ideal or ambient sound is too
loud, it may be difficult to hear the other person's voice during a
call.

Poor sound quality

Do not place the cellular phone in an area surrounded by metal or
far away from the in-vehicle phone module to prevent tone quality
degradation and wireless connection disruption.
