MWI-18
< SYSTEM DESCRIPTION >
SYSTEM
• The combination meter can be diagnosed with CONSULT.
METER CONTROL FUNCTION LIST
System
Description
Reference
Measuring in-
struments
Speedometer
Indicates vehicle speed.
MWI-21,
"SPEEDOME-
TER : System De-
scription"
Tachometer
Indicates engine speed.
MWI-22, "TA-
CHOMETER :
System Descrip-
tion"
Engine coolant temperature gauge
Indicates engine coolant temperature.
MWI-22, "EN-
GINE COOLANT
TEMPERATURE
GAUGE : System
Description"
Fuel gauge
Indicates fuel level.
MWI-22, "FUEL
GAUGE : System
Description"
Warning lamp/indicator lamp
The warning lamp/indicator lamp turns ON
or turns OFF, according to system malfunc-
tion or vehicle condition.
MWI-10, "METER
SYSTEM : De-
sign"
Meter illumi-
nation control
Buck light illumination control function
The operation of the illumination control
switch allows the brightness adjustment of
meter illumination.
MWI-68, "METER
ILLUMINATION
CONTROL : Sys-
tem Description"
Meter effect
function
Engine-start effect function
Meter illumination at ignition switch ON from
OFF to produce illumination effects.
MWI-69, "METER
EFFECT FUNC-
TION : System
Description"
Driver welcome function
Controls meter illumination to produce illu-
mination effects when getting in the vehicle.
Information display
The Information display displays status, ac-
cording to system malfunction or vehicle
condition.
