AV-56 < REMOVAL AND INSTALLATION > [BASE AUDIO] MICROPHONE MICROPHONE Removal and Installation INFOID:0000000011010049 REMOVAL 1. Remove the map lamp assembly. Refer to 2. Disconnect the microphone connector from the map lamp assembly . 3. Release the microphone pawls, then remove the microphone . INSTALLATION Installation is in the reverse order of removal. : Pawl ALNIA1366ZZ |
