Nissan Juke F15. Manual - part 210





DLK-20

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

SYSTEM (INTELLIGENT KEY SYSTEM)

KEY REMINDER FUNCTION
KEY REMINDER FUNCTION : System Diagram

INFOID:0000000012196590

KEY REMINDER FUNCTION : System Description

INFOID:0000000012196591

Key reminder is the function that prevents the key from being left in the vehicle.

Key reminder has the following 3 functions.

Remote keyless entry functions

Int

ell

ig

en

t Ke

y

Doo

r swi

tch

Do

or l

oc

ac

tua

to

r

Pu

sh

-bu

tto

n i

g

ni

tion

 swi

tch

Inte

llige

nt

 Ke

y wa

rni

ng

bu

zz

er

CAN c

o

m

m

un

ica

tio

n sy

st

em

BCM

Co

mb

in

at

ion

 me

te

r

Hazard warning lamp

Horn

IP

DM E/

R

Door lock/unlock function

×

×

×

×

×

Hazard and horn reminder function

×

×

×

×

×

×

×

×

Selective unlock function

×

×

×

×

×

Auto door lock function

×

×

×

×

×

JMKIA5390GB

Key remainder func-

tion

Operation condition

Operation

Driver side door
closed*

Right after driver side door is closed under the following conditions
• Intelligent Key is inside the vehicle
• Driver side door is opened
• Driver side door is in unlock state

All doors unlock

Door is open to closed

Right after all doors are closed under the following conditions
• Intelligent Key is inside the vehicle
• Any door is opened
• All doors are locked.

• All doors unlock
• Honk Intelligent Key warn-

ing buzzer

Back door is closed

Right after back door is closed under the following conditions
• Intelligent Key is inside the vehicle
• All doors (except back door) are closed
• All doors (except back door) are locked

• All doors unlock
• Back door can open with

back door opener switch

• Honk Intelligent Key warn-

ing buzzer

SYSTEM (INTELLIGENT KEY SYSTEM)

DLK-21

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

*:If the door closing impact shocks the door lock knob, or contacts against baggage with the door lock knob might activate the door locks
accidentally but unlock operation is perform in these cases.

CAUTION:

• The above function operates when the Intelligent Key is inside the vehicle. However, there may be

times when the Intelligent Key cannot be detected, and this function does not operate when the Intel-

ligent Key is on the instrument panel, rear parcel shelf, or in the glove box. Also, this system some-

times does not operate if the Intelligent Key is in the door pocket for the open door.

WARNING FUNCTION
WARNING FUNCTION : System Description

INFOID:0000000012196592

OPERATION DESCRIPTION

The warning function are as per the following items and are given to the user as warning information and

warnings using combinations of Intelligent Key warning buzzer, combination meter buzzer, KEY warning lamp,

shift P warning lamp and engine start operation indicator lamp.

• Intelligent Key system malfunction

• OFF position warning

• P position warning

• ACC warning

• Take away warning

• Door lock operation warning

• Engine start information

• Intelligent Key low battery warning

• Key ID warning

OPERATION CONDITION

Operation condition of warning and information is as per the following table.

Warning/Information functions

Operation procedure

Intelligent Key system malfunction

A malfunction is detected on BCM and key warning lamp turns ON

OFF position warning

For internal

When condition A, B or condition C is satisfied
• Condition A
- Ignition switch: ACC position
- Door switch (driver side): ON (Door is open)
• Condition B
- Turn ignition switch from ON to OFF while door is open
• Condition C
- Intelligent Key backside is contacted to ignition switch while brake pedal is de-

pressed and ignition switch is LOCK or OFF (When the Intelligent Key battery
is discharged)

- Door switch (driver side): ON (Door is open)

For external*

OFF position warning (For internal) is in active mode, driver side door is closed
NOTE:
OFF position warning (for external) operates only when driver door is closed af-
ter each of P position warning, ACC warning, and OFF position warning (inter-
nal) sounds.

P position warning*

For internal

• Shift position: Except P position
• Engine is running to stopped (Ignition switch is ON to OFF)

For external

• P position warning (For internal) operates
• Door switch: ON to OFF (Door is open to close)
• Intelligent Key cannot be detected inside the vehicle

ACC warning*

• After P position warning operates, or when ignition switch is turned ON imme-

diately after P position warning operates

• Ignition switch: ACC position

DLK-22

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

SYSTEM (INTELLIGENT KEY SYSTEM)

*: M/T models do not apply.

WARNING METHOD

The following table shows the alarm or warning methods with chime.

*: M/T models do not apply.

LIST OF OPERATION RELATED PARTS

Parts marked with

× are the parts related to operation.

Take away warning

Door status changes
from open to close

• Ignition switch: Except LOCK position
• Door switch: ON to OFF (Door is open to close)
• Registered Intelligent Key is not detected inside the vehicle

Door status is open

• Door switch: ON (Door is open)
• Registered Intelligent Key is not detected inside the vehicle during Key ID ver-

ification for 5 seconds

Push button-ignition
switch operation

• Ignition switch: Except LOCK position
• Press push-button ignition switch
• Registered Intelligent Key is not detected inside the vehicle

Door lock operation warning

When door lock operation is requested while door lock operating condition of
door request switch not satisfied

Engine start information

Ignition switch is ON po-
sition

• Ignition switch: ON position
• Shift position: P position*
• Engine is stopped

Ignition switch is except
ON position

• Ignition switch: Except ON position
• Shift position: P position*
• Intelligent Key can be detected inside the vehicle

Intelligent Key low battery warning

BCM detects that Intelligent Key is low battery, after ignition switch is turned ON

Key ID warning

• Push-button ignition switch is pressed
• Registered Intelligent Key is not detected inside the vehicle

Warning/Information functions

Operation procedure

Warning/Information functions

“KEY” warn-

ing lamp

Shift P

warning

lamp

Warning chime

Engine start

operation in-

dicator lamp

Combination

meter buzzer

Intelligent

Key warning

buzzer

Intelligent Key system malfunction

Indicate

OFF position warning

For internal

Activate

For external*

Activate

P position warning*

For internal

Blink (yellow)

Indicate

Activate

For external

Active

ACC warning*

Activate

Take away warning

Door is open to close

Blink (yellow)

Activate

Activate

Door is open

Push-ignition switch opera-
tion

Activate

Door lock operation warning

Activate

Key ID warning

Blink (yellow)

Engine start information

Indicate

Intelligent Key low battery warning

Blink (green)

SYSTEM (INTELLIGENT KEY SYSTEM)

DLK-23

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

Warning function

In

te

llige

nt

 Key

Ig

n

iti

on swi

tch

Do

or swit

ch

Do

or requ

es

t s

w

itch

In

si

de

 ke

y an

ten

n

a

Out

si

de ke

y a

n

ten

n

a

In

te

llige

nt

 Key

 wa

rnin

bu

zz

er

Com

b

in

at

io

n m

e

te

r wa

rni

n

g bu

zz

er

CAN co

mm

un

ic

ati

on

 s

ys

tem

BC

M

S

hif

t P wa

rni

ng

 la

mp

E

ng

ine

 s

tart

 op

era

tio

ind

ic

ato

r l

am

p

“K

EY” warning lamp

Intelligent Key system malfunction

×

×

×

OFF position warning

For internal

×

×

×

×

For external

×

×

×

P position warning

×

×

×

×

×

×

ACC warning

×

×

×

×

Take away warning

Door is open or close

×

×

×

×

×

×

×

×

Door is open

×

×

×

×

×

×

Push-button ignition switch opera-
tion

×

×

×

×

×

×

×

Door lock operation warning

×

×

×

×

×

×

×

Key ID warning

×

×

×

×

×

Engine start information

×

×

×

×

×

×

Steering lock information

×

×

×

Intelligent Key low battery warning

×

×

×

×

×
