Nissan Juke F15. Manual - part 209





DLK-16

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

SYSTEM (INTELLIGENT KEY SYSTEM)

After door is unlocked by door request switch operation and if 60 seconds or more passes without performing

the following operation, all doors are automatically locked. However, operation check function does not acti-

vate.

How To Change Auto Door Lock Operation Mode

Auto door lock operation mode can be changed using CONSULT.

Refer to

DLK-28, "INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)"

.

LIST OF OPERATION RELATED PARTS

Parts marked with

× are the parts related to operation.

BACK DOOR OPEN FUNCTION
BACK DOOR OPEN FUNCTION : System Diagram

INFOID:0000000012196586

BACK DOOR OPEN FUNCTION : System Description

INFOID:0000000012196587

While back door open in the permitted state, back door opens when back door opener switch is pressed after

back door opener request switch is operated.

BACK DOOR OPEN

Operating condition

• Door switch is ON (door is open)
• Door is locked
• Push switch is pressed

Door lock function

In

tel

lig

en

t Ke

y

Re

mo

te

 ke

yl

es

s en

try rec

e

ive

r

Do

or swi

tch

Doo

r re

qu

es

t s

w

itc

h

Do

or l

o

ck ac

tu

at

or

In

si

de

 ke

an

ten

na

O

ut

sid

e ke

y ant

en

na

Int

el

lig

en

t Ke

wa

rni

ng

 bu

zze

r

CAN co

mm

un

ic

at

io

sys

tem

BCM

Hazard warning

lamp

Pu

sh

-bu

tto

n i

gn

iti

on

swi

tch

Co

mb

in

at

ion

 met

er

Door lock/unlock function

×

×

×

×

×

×

×

×

Hazard and buzzer reminder function

×

×

×

×

×

Selective unlock function

×

×

×

×

×

×

Auto door lock function

×

×

×

×

JMKIA6136GB

SYSTEM (INTELLIGENT KEY SYSTEM)

DLK-17

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

• When the BCM detects that back door opener switch is pressed, it starts the outside key antenna (rear

bumper) and inside key antenna and transmits the request signal to the Intelligent Key. Then, check that the

Intelligent Key is near the back door.

• If the Intelligent Key is within the outside key antenna detection area, it receives the request signal and

transmits the key ID signal to the BCM via remote keyless entry receiver.

• BCM receives the key ID signal and compares it with the registered key ID.

• BCM opens back door, simultaneously unlocks all doors.

NOTE:

In selective unlock mode, only back door opens. All doors do not unlock.

OPERATION CONDITION

If the following conditions are satisfied, the back door can be opened.

OUTSIDE KEY ANTENNA DETECTION AREA

The outside key antenna detection area of back door open function

is in the range of approximately 80 cm (31.50 in) surrounding the

back door opener switch (1). However, this operating range depends

on the ambient conditions.

LIST OF OPERATION RELATED PARTS

Parts marked with

× are the parts related to operation.

REMOTE KEYLESS ENTRY FUNCTION

Back door open function

Operation condition

Back door open operation

• Vehicle speed is less than 5 km/h (3 MPH)
• 3 seconds or more after BCM outputs all doors lock signal
• Intelligent Key is outside of vehicle
• Intelligent Key is within outside key antenna detection area

JMKIA5804ZZ

Door lock function

In

te

lli

ge

nt Key

Re

mo

te ke

yl

es

s ent

ry rec

eiv

er

Ba

ck

 d

oo

r op

en

er

ac

tua

to

r

Do

or l

oc

ac

tua

to

r

In

si

de

 ke

y a

n

ten

n

a

O

u

ts

id

e

 k

ey

 an

te

nna

CAN co

mm

un

ic

ati

on

 sy

st

em

BCM

Ba

ck

 d

oo

r op

en

er

swit

ch

Co

mb

in

ati

on

 me

te

r

Back door open function

×

×

×

×

×

×

×

×

×

×

DLK-18

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

SYSTEM (INTELLIGENT KEY SYSTEM)

REMOTE KEYLESS ENTRY FUNCTION : System Diagram

INFOID:0000000012196588

REMOTE KEYLESS ENTRY FUNCTION : System Description

INFOID:0000000012196589

The Intelligent Key has the same functions as the remote control entry system. Therefore, it can be used in the

same manner as the remote controller by operating the door lock/unlock button.

OPERATION

Remote keyless entry system controls operation of the following items.

• Door lock/unlock

• Selective unlock function

• Hazard reminder function

• Auto door lock

OPERATION AREA

To check that the Intelligent Key works normally, use within 1 m (3 ft) range of each doors, however the opera-

ble range may differ according to surroundings.

DOOR LOCK/UNLOCK FUNCTION

• When door lock/unlock button of the Intelligent Key is pressed, lock signal or unlock signal transmitted from

Intelligent Key to BCM via remote keyless entry receiver.

• BCM receives the signal and compares it with the registered key ID to the vehicle.

• When BCM receives the door lock/unlock signal, it operates all door lock actuators and the hazard lamp

(lock: 2 times, unlock: 1 time) and horn chirp signal to IPDM E/R at the same time as a reminder.

• IPDM E/R honks horn (lock: 1 times) as a reminder

OPERATION CONDITION

If the following condition are satisfied, remote keyless entry operation is performed when the Intelligent Key is

operated.

SELECTIVE UNLOCK FUNCTION

• When an LOCK signal is transmitted from Intelligent Key, all doors are locked.

• When an UNLOCK signal is transmitted from Intelligent Key once, driver side door is unlocked.

• Then, if an UNLOCK signal is transmitted from Intelligent Key again within 60 seconds, all other doors are

unlocked.

How To Change Selective Unlock Operation Mode

Selective unlock operation mode can be changed using CONSULT.

JMKIA6159GB

Remote controller operation

Operation condition

Lock

• Panic alarm is not activated
• P position warning is not activated

Unlock

Panic alarm is not activated

SYSTEM (INTELLIGENT KEY SYSTEM)

DLK-19

< SYSTEM DESCRIPTION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

Refer to

DLK-26, "DOOR LOCK : CONSULT Function (BCM - DOOR LOCK)"

.

HAZARD AND HORN REMINDER FUNCTION

When doors are locked or unlocked by Intelligent Key, BCM blinks hazard warning lamps as a reminder and

transmits horn chirp signal to IPDM E/R. IPDM E/R sounds horn as a reminder.

The hazard and horn reminder has a horn chirp mode (C mode) and a non-horn chirp mode (S mode).

Operating Function of Hazard and Horn Reminder

Hazard and horn reminder does not operate if ignition switch ON position.

How to change hazard and horn reminder mode

With CONSULT

Refer to

DLK-28, "INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)"

.

Without CONSULT

When LOCK and UNLOCK signals are sent from the Intelligent Key for more than 2 seconds at the same time,

the hazard and horn reminder mode is changed and hazard warning lamp blinks and horn sounds as per the

following items:

AUTO DOOR LOCK FUNCTION

After door is unlocked by Intelligent Key button operation and if 60 seconds or more passes without performing

the following operation, all doors are locked. However, operation check function does not activate.

How To Change Auto Door Lock Operation Mode

Auto door lock operation mode can be changed using CONSULT.

Refer to

DLK-28, "INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)"

.

LIST OF OPERATION RELATED PARTS

Parts marked with

× are the parts related to operation.

C mode

S mode

Intelligent Key operation

Lock

Unlock

Back door

open

Lock

Unlock

Back door

open

Hazard warning lamp blinks

Twice

Once

Twice

Horn  sound

Once

JMKIA6362GB

Operating condition

• Door switch is ON (door is open)
• Door is locked
• Push switch is pressed
