DIAGNOSIS SYSTEM (AROUND VIEW MONITOR CONTROL UNIT)

Steering Angle Sensor Adjustment

Steering angle sensor neutral position can be adjusted and registered.

CAUTION:

For vehicles with VDC, adjust the steering angle sensor neutral position on the ABS actuator control

unit side.

Non-Viewable Area Reminder

ON/OFF setting of the non-viewable area reminder can be performed.

CONFIGURATION

Configuration includes functions as follows.

Function

Description

Read/Write Configuration

Before Replace ECU

Allows the reading of vehicle specification written in around view
monitor control unit to store the specification in CONSULT.

After Replace ECU

Allows the writing of the vehicle information stored in CONSULT
into the around view monitor control unit.

Manual Configuration

Allows the writing of the vehicle specification into the around view
monitor control unit by hand.

AV

NAVI CONTROL UNIT

AV-83

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ECU DIAGNOSIS INFORMATION

NAVI CONTROL UNIT

Reference Value

INFOID:0000000012202501

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA8067ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(R)

Ground Woofer amp. ON signal

Output

Ignition

switch

ON

—

12.0  V

2

(W)

3

(GR)

Sound signal front speaker
LH

Output

Ignition

switch

ON

Sound output.

4

(LG)

5

(V)

Sound signal rear speaker
LH

Output

Ignition

switch

ON

Sound output.

6

(G)

15

(V)

Steering switch signal A

Input

Ignition

switch

ON

Keep pressing SOURCE
switch.

0 V

Keep pressing SEEK UP
switch.

0.9 V

Keep pressing SEEK
DOWN switch.

1.9 V

Keep pressing TEL switch.

2.4 V

Except for above.

3.3 V

7

(L)

Ground ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

8

(L)

—

CAN–H

Input/

Output

—

—

—

SKIB3609E

SKIB3609E

AV-84

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITH NAVIGATION]

NAVI CONTROL UNIT

9

(V)

33

(GR)

Illumination control signal

Input

Ignition

switch

ON

• Lighting switch 1ST
• When meter illumination

is maximum

• Lighting switch 1ST
• When meter illumination

is step 11

• Lighting switch 1ST
• When meter illumination

is minimum

0 V

10

—

Shield

—

—

—

—

11

(G)

12

(R)

Sound signal front speaker
RH

Output

Ignition

switch

ON

Sound output.

13

(BR)

14

(Y)

Sound signal rear speaker
RH

Output

Ignition

switch

ON

Sound output.

16

(R)

15

(V)

Steering switch signal B

Input

Ignition

switch

ON

Keep pressing VOL DOWN
switch.

0 V

Keep pressing VOL UP
switch.

0.9 V

Keep pressing TEL END
switch.

1.9 V

Except for above.

3.3 V

17

(P)

—

CAN–L

Input/

Output

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

JPNIA1687GB

JPNIA1686GB

SKIB3609E

SKIB3609E

AV

NAVI CONTROL UNIT

AV-85

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

18

(Y)

Ground

Vehicle speed signal (8-
pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

NOTE:

The maximum voltage varies de-

pending on the specification

(destination unit).

19

(BR)

Ground Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

20

(B)

Ground Ground

—

Ignition

switch

ON

—

—

21

(G)

—

AUX audio signal RH

Input

—

—

—

22

(Y)

—

AUX audio signal ground

—

—

—

—

23

(L)

—

AUX audio signal LH

Input

—

—

0 V

25

(G)

Ground Reverse signal

Input

Ignition

switch

ON

Shift position is in R.

12.0 V

Shift position is in other
than R.

0 V

26

(BR)

29

(Y)

Sound signal woofer

Output

Ignition

switch

ON

Sound output.

30

(V)

33

(GR)

Illumination control signal

Input

Ignition

switch

ON

• Lighting switch 1ST
• When meter illumination

is maximum

• Lighting switch 1ST
• When meter illumination

is step 11

• Lighting switch 1ST
• When meter illumination

is minimum

0 V

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

JSNIA0012GB

SKIB3609E

JPNIA1687GB

JPNIA1686GB
