Indicator light, warning light, and information screen display list
6FUHHQ
&DXVH
'R WKLV 5HIHUHQFH
z FCM braking function of the Forward Collision Mit-
Refer to “FCM braking function” on page 5-101.
igation System (FCM) has been activated.
z The Forward Collision Mitigation System (FCM) is
Refer to “Forward Collision Mitigation System (FCM):
5
temporarily unavailable for some reason.
System problem warning” on page 5-105.
z There is a fault in the Forward Collision Mitigation
z Contact a certified Mitsubishi EV dealer to have the
System (FCM).
system checked.
Refer to “Forward Collision Mitigation System: Sys-
tem problem warning” on page 5-105.
z The Lane Departure Warning system (LDW) has
Refer to “Lane Departure Warning system (LDW)” on
detected that your vehicle is about to leave or has left
page 5-118.
the lane.
z There is a fault in the Lane Departure Warning sys-
z Contact a certified Mitsubishi EV dealer to have the
tem (LDW).
system checked.
Refer to “Lane Departure Warning system (LDW):
System problem warning” on page 5-120
z The Blind Spot Warning (BSW) sensor is temporar-
z When the warning display does not disappear after
ily not available for some reason such as the environ-
waiting for a while, contact a certified Mitsubishi EV
mental condition or increase of the sensor
dealer.
temperature.
Refer to “Blind Spot Warning (BSW): When the sen-
sor is temporarily not available” on page 5-112.
5-178
Features and controls
Indicator light, warning light, and information screen display list
6FUHHQ
&DXVH
'R WKLV 5HIHUHQFH
z
The Blind Spot Warning (BSW) does not operate
z
Immediately have your vehicle inspected at a certi-
normally because there are some malfunctions in the
fied Mitsubishi EV dealer.
sensor or the system.
Refer to “Blind Spot Warning (BSW): When there is
a malfunction in the system or the sensor” on page
5-112.
z
Foreign objects, such as dirt, snow or ice, adhere to
z
Remove a foreign object on the bumper surface
5
the bumper surface around the sensor.
around the sensor.
When the warning display does not disappear after
having cleaned the bumper surface around the sen-
sor, contact a certified Mitsubishi EV dealer.
Refer to “Blind Spot Warning (BSW): When there
are foreign objects on the sensor.” on page 5-112.
z
The Rear Cross Traffic Alert (RCTA) is detected the
z
Pay special attention to the rear of your vehicle.
vehicle approaching your vehicle.
Refer to “Rear Cross Traffic Alert (RCTA)” on page
5-114.
z There is a fault in the sensor.
z Contact a certified Mitsubishi EV dealer.
Refer to “Forward Collision Mitigation System
(FCM): System problem warning” on page 5-105.
Refer to “Lane Departure Warning System (LDW):
System problem warning” on page 5-120.
Refer to “Automatic High Beam (AHB): System
problem warning” on page 5-196.
Features and controls
5-179
Indicator light, warning light, and information screen display list
6FUHHQ
&DXVH
'R WKLV 5HIHUHQFH
z
The Forward Collision Mitigation System (FCM),
z After the temperature of the sensor has been in
Lane Departure Warning system (LDW) and Auto-
range, the system will automatically return to opera-
matic High Beam (AHB) is temporarily unavailable
tion.
due to the high or low temperature of the sensor.
Refer to “Forward Collision Mitigation System
(FCM): System problem warning” on page 5-105.
Refer to “Lane Departure Warning System (LDW):
5
System problem warning” on page 5-120.
Refer to “Automatic High Beam (AHB): System
problem warning” on page 5-196.
z
The sensor is temporarily unavailable due to condi-
Refer to “Forward Collision Mitigation System (FCM):
tions such as the adhesion of contaminants to the
System problem warning” on page 5-105.
sensor or windshield.
Refer to “Lane Departure Warning System (LDW): Sys-
This is not a malfunction.
tem problem warning” on page 5-120.
Refer to “Automatic High Beam (AHB): System prob-
lem warning” on page 5-196.
z
There is a fault in the system of Automatic High
z Contact a certified Mitsubishi EV dealer.
Beam (AHB).
Refer to “Automatic High Beam (AHB): System
problem warning” on page 5-196.
5-180
Features and controls
Indicator light, warning light, and information screen display list
2WKHU LQWHUUXSW GLVSOD\V
N00558201470
6FUHHQ
&DXVH
'R WKLV 5HIHUHQFH
z
When you pressed the power switch and
z
Place the select position in the “P” (PARK)
the operation mode become the ACC with-
position, depress the brake pedal more
out depress the brake pedal, this screen is
firmly than usual with the right foot. Then,
displayed.
press the power switch.
5
This screen will be displayed repeatedly at
Refer to “Starting the Plug-in Hybrid EV
regular intervals while the operation mode
System” on page 5-14.
of the power switch is put in ACC.
z
When Plug-in Hybrid EV System does not
start even if the operation mode of the
power switch is put in ON, this screen is
displayed.
z
When starting the Plug-in Hybrid EV Sys-
z
Place the select position in the “P” (PARK)
tem, you pressed the power switch without
position by pressing the electrical parking
select position in the “P” (PARK) position.
switch, depress the brake pedal more
firmly than usual with the right foot. Then,
press the power switch.
Refer to “Starting the Plug-in Hybrid EV
System” on page 5-14.
z
Driving power is restricted by the safety
z
You do not have to take any actions. The
system as the Plug-in Hybrid EV System
restriction on the driving power will be
has become too hot or too cold.
released when the Plug-in Hybrid EV Sys-
tem returns to the normal temperature.
Features and controls
5-181
Indicator light, warning light, and information screen display list
6FUHHQ
&DXVH
'R WKLV 5HIHUHQFH
z
The vehicle had not been refueled approxi-
z
Refill the 4 gallons (15 liters) more at one
mately 4 gallons (15 liters) or more at one
time. This display will disappear.
time for nearly 3 months.
If the fuel remaining display will be below
This display may appear frequently
half, you can refill the fuel more than
depending on the use conditions of your
4 gallons (15 liters) certainly.
vehicle such as when the fuel has been
z
If you cannot refill the fuel due to large
5
staying in the fuel tank for a long time.
amount of the remaining fuel, start the
engine and drive the vehicle enough to
reduce the fuel level to approximately half
tank.
z
If the vehicle had not been refueled
z
Refill the 4 gallons (15 liters) more at one
approximately 4 gallons (15 liters) or more
time. This display and battery charge mode
at one time for three months, the engine
display will disappear, and the engine will
starts automatically for the maintenance of
not automatically start for maintenance.
the engine or the fuel system components
If the fuel remaining display will be below
while the ready indicator is illuminated.
half, you can refill the fuel more than
This display may appear frequently
4 gallons (15 liters) certainly.
depending on the use conditions of your
z
If you cannot refill the fuel due to large
vehicle such as when the fuel has been
amount of the remaining fuel, start the
staying in the fuel tank for a long time.
engine and drive the vehicle enough to
When the engine is running, the main drive
reduce the fuel level to approximately half
lithium-ion battery is charged and the bat-
tank.
tery charge mode display (
)
is displayed, but the main drive lithium-ion
battery will not be full charge.
5-182
Features and controls
Indicator light, warning light, and information screen display list
6FUHHQ
&DXVH
'R WKLV 5HIHUHQFH
z The accelerator pedal has been depressed
z When you start the vehicle, be sure to
when the select position is in the “N”
check the select position display and make
(NEUTRAL) position.
sure the select position is in the “D”
(DRIVE) or “R” (REVERSE) position.
Then depress the accelerator pedal.
Refer to “Select Position display” on page
5-58.
5
z The selector lever has been operated when
z Operate the selector lever while depressed
the select position is in “P” (PARK) posi-
firmly on the brake pedal.
tion and the brake pedal is not depressed.
The operation status of each system is displayed on the information screen. For further details, refer to the appropriate page for each system.
6FUHHQ
6\VWHP RSHUDWLRQ VWDWXV
5HIHUHQFH
z When charging of the main drive lithium-
Refer to “Normal charging” on page 3-20.
ion battery is completed.
z When “NORMAL” mode of S-AWC is
Refer to “S-AWC drive mode” on page 5-62.
selected.
Features and controls
5-183
Indicator light, warning light, and information screen display list
6FUHHQ
6\VWHP RSHUDWLRQ VWDWXV
5HIHUHQFH
z When “SNOW” mode of S-AWC is
Refer to “S-AWC drive mode” on page 5-62.
selected.
z When “LOCK” mode of S-AWC is
Refer to “S-AWC drive mode” on page 5-62.
5
selected.
z When the mode is changed by the ECO
Refer to “ECO mode switch” on page 5-199.
mode switch.
z When the EV priority mode is activated.
Refer to “EV switch” on page 5-66.
z When the battery save mode is activated.
Refer to “Battery save mode” on page 5-69.
z When the battery charge mode is acti-
Refer to “Battery charge mode” on page
vated.
5-69.
5-184
Features and controls
Indicator light, warning light, and information screen display list
6FUHHQ
6\VWHP RSHUDWLRQ VWDWXV
5HIHUHQFH
z When the SPORT mode is activated.
Refer to “SPORT mode switch” on page
5-71.
z When the Forward Collision Mitigation
Refer to “FCM ON/OFF switch” on page
System (FCM) is activated or the timing
5-104.
5
of an alarm is changed.
z When the Forward Collision Mitigation
Refer to “FCM ON/OFF switch” on page
System (FCM) is deactivated.
5-104.
This informs you that a periodic inspection is due.
6FUHHQ
'R WKLV
Have an inspection made by a certified Mitsubishi EV dealer. For further details, refer to
“Service reminder” on page 5-149.
Features and controls
5-185
Indicators
The rest time can be set.
6FUHHQ
'R WKLV
Park the vehicle in a safe place, stop the Plug-in Hybrid EV System, and take a rest.
Use this display as rough guide for taking rests during a long drive.
The interval from the start of your trip until this message is displayed can be set.
Refer to “Changing the function settings” on page 5-153.
5
The display and buzzer alert the driver when the set time is reached. If you continue to drive
without having a rest, the buzzer sounds approximately every 5 minutes to encourage you to
take a rest.
z In the following cases, the time driven is reset and the display returns to the previous
display screen. After this, when the set time is reached again, the display and buzzer
encourage you to take a rest.
• The buzzer sounds 3 times.
• The operation mode is put in OFF.
• The multi-information display switch is held (for approximately 2 seconds or more).
,QGLFDWRUV
NOTE
)URQW IRJ OLJKW LQGLFDWRU
N00519900127
z If the indicator flashes faster than usual or if
N00520201257
the indicator stays on without flashing, check
This indicator comes on while the front fog
for a malfunctioning turn signal light bulb or
7XUQ VLJQDO LQGLFDWRUV +D]DUG
lights are on.
turn signal connection.
ZDUQLQJ OLJKWV
N00520000216
3RVLWLRQ LQGLFDWRU
The arrows will flash in time with the corre-
+LJK EHDP LQGLFDWRU
N00551301065
sponding exterior turn signals when the turn
N00520100086
This indicator light illuminates while the
signal lever is used.
parking lights are on.
A blue light comes on when the headlights
are on high beam.
Both arrows will flash when the hazard warn-
ing flasher switch is pressed.
5-186
Features and controls
Warning lights
5HDG\ LQGLFDWRU
:DUQLQJ OLJKWV
CAUTION
N00573201035
N00520300147
z
If the brake warning light and the Anti-lock
braking system warning light are illuminated
The ready indicator keeps flashing until Plug-
at the same time, the braking force distribu-
in Hybrid EV System is activated. When the
%UDNH ZDUQLQJ OLJKW DQG EX]]HU
tion function will not operate, so the vehicle
Plug-in Hybrid EV System has activated nor-
N00520401608
may be destabilized during sudden braking
mally and the vehicle becomes ready to run,
This light comes on when the operation mode
under the following conditions.
the indicator stops flashing and stays lit.
is put in ON, and goes off after a few seconds.
• When the brake warning light does not go
Refer to “Starting the Plug-in Hybrid EV Sys-
5
Always make sure that the light goes off
out even when the parking brake is
tem” on page 5-14.
released.
before driving.
If the indicator keeps flashing, the vehicles
• When the brake warning light stays on
A warning is also displayed in the multi-
cannot drive.
while driving.
information display.
• If the above occurs, avoid sudden braking
The warning light also illuminates after start-
and high-speed driving. Park the vehicle in
&KDUJLQJ LQGLFDWRU
ing the Plug-in Hybrid EV system under the
a safe place, and contact a certified
N00573301049
following conditions.
Mitsubishi EV dealer as soon as possible.
This indicator flashes when the EV charging
z
The vehicle should be brought to a halt in the
z When the parking brake is still applied.
cable (normal charger or quick charger) is
following manner when brake performance
z When the brake fluid level is low.
connected.
is deteriorated.
z When the brake system circuit is not
After that, the indicator switches to being
• Confirm that the vehicle slows down when
working properly.
illuminated when charging starts and goes out
you press down on the brake pedal harder
than usual. In some cases, the brake pedal
when charging is completed.
When the vehicle is moving at more than 5
may go all the way to the floor.
mph (8 km/h) and parking brake applied, a
• Should the brakes fail, use regenerative
NOTE
buzzer will sound to inform the driver that the
brake to reduce your speed and keep pull-
z Although it is possible to start the Plug-in
parking brake is not properly release.
ing the Electric parking brake switch.
Hybrid EV System if quick charging has not
(Refer to “Electric parking brake” on page
finished normally, the charging indicator is
Before driving, be sure that the parking brake
5-45)
continuously blinking.
is fully released and brake warning light is
Depress the brake pedal to illuminate the
Refer to “Charging troubleshooting guide”
off.
stop lights to alert the vehicles behind you.
on page 3-46.
Features and controls
5-187
Warning lights
lem is detected in one of these systems, this
(OHFWULF SDUNLQJ EUDNH ZDUQLQJ
CAUTION
indicator illuminates or flashes. When the
OLJKW
z
If the engine malfunction indicator comes on
operation mode is put in ON, this indicator
while the Plug-in Hybrid EV system is run-
N00591200072
normally comes on and goes off after the
ning, avoid driving at high speeds.
This warning light will illuminate when there
Plug-in Hybrid EV system has started.
During vehicle operation with the indicator
is a fault in the Electric parking brake system.
on, the vehicle may not accelerate when you
This indicator will come on if the fuel tank
Normally, this warning light illuminates
depress the accelerator pedal.
filler cap is not properly tightened. If this
when the operation mode is put in ON, and
5
indicator comes on and stays on after refuel-
goes off in a few seconds.
ing, stop the Plug-in Hybrid EV system and
NOTE
check that the cap is properly tightened. (Turn
z
Do not disconnect the 12 V starter battery
CAUTION
the cap clockwise until you hear clicking
cable when the engine malfunction indicator
z
When the warning light remains on or does
sounds.)
(“SERVICE ENGINE SOON” or “Check
not come on, there is the possibility that the
If this indicator does not go off after several
engine light”) is on.
parking brake cannot be operated or
seconds or lights up while driving, have the
The engine electronic control module stores
released. Immediately contact the nearest
system checked as soon as possible at a certi-
critical OBD information (especially exhaust
certified Mitsubishi EV dealer. When the
fied Mitsubishi EV dealer.
emission data), which may be lost if the 12 V
warning light comes on during driving,
starter battery cable is disconnected while
immediately stop the vehicle in a safe place,
the engine malfunction indicator is on. This
and contact a certified Mitsubishi EV dealer.
CAUTION
will make it difficult to diagnose the cause of
If you inevitably have to park, park the vehi-
z
Driving for a long time with the engine mal-
future problems.
cle on level and stable ground, shift the
function indicator on may cause more dam-
select position in “P” (PARK) position and
age to the emission control system. This
place chocks or blocks.
could also affect fuel economy and drivabil-
9 VWDUWHU EDWWHU\ FKDUJLQJ
ity.
z
If this indicator does not come on when the
V\VWHP ZDUQLQJ OLJKW
(QJLQH PDOIXQFWLRQ LQGLFDWRU
operation mode is put in ON, have the sys-
N00520601336
tem checked at a certified Mitsubishi EV
³6(59,&( (1*,1( 6221´
This light comes on in the event of a malfunc-
dealer.
RU ³&KHFN HQJLQH OLJKW´
tion in the charging system or when the oper-
ation mode is put in ON. When the Plug-in
N00520501843
Hybrid EV System is started and the ready
This indicator is a part of the onboard diag-
indicator illuminates, the light should go out.
nostic
(OBD) system which monitors the
emissions or engine control system. If a prob-
5-188
Features and controls
Information screen display
Check to make sure that the light has gone
CAUTION
CAUTION
out before driving.
z If the warning light illuminates and
“EV
z If the light illuminates while the Plug-in
SYSTEM SERVICE REQUIRED STOP
Hybrid EV System is operating, we recom-
CAUTION
SAFELY” warning is displayed on the multi-
mend you to have the vehicle inspected by a
z If the warning light stays on after the ready
information display while the Plug-in Hybrid
certified Mitsubishi EV dealer.
indicator illuminates, there may be a prob-
EV System is running, park your vehicle in a
lem with the charging system for the 12 V
safe place as soon as possible and contact a
starter battery.
certified Mitsubishi EV dealer to have the
,QIRUPDWLRQ VFUHHQ GLVSOD\
5
• Immediately park your vehicle in a safe
system checked.
N00558301051
place and contact a certified Mitsubishi EV
dealer to have the system checked.
• Do not charge the 12 V starter battery.
%UDNH ZDUQLQJ GLVSOD\
N00558401195
3OXJ LQ +\EULG (9 6\VWHP
ZDUQLQJ OLJKW
5HJHQHUDWLYH EUDNH ZDUQLQJ
N00588800032
OLJKW
This warning light will illuminate when there
N00588900033
is a fault at the Plug-in Hybrid EV System.
This warning is displayed if the vehicle is
Refer to “Service precautions” on page 9-2.
This warning light will illuminate when the
being driven with the parking brake still
Normally, this warning light illuminates
regenerative brake cannot be used, while the
applied. The warning light in the instrument
when the operation mode of the power switch
Plug-in Hybrid EV System is running.
cluster only comes on when the parking brake
is put in ON, and goes off after a few seconds.
The warning is also displayed on the multi-
is applied.
information display.
Normally, this warning light illuminates
CAUTION
when the operation mode of the power switch
z If a vehicle is driven without releasing the
is put in ON, and goes off after the Plug-in
parking brake, the brakes will overheat,
Hybrid EV System is activated.
resulting in ineffective braking and possible
brake failure.
If this warning is displayed, release the park-
ing brake.
Features and controls
5-189
Combination headlights and dimmer switch
CAUTION
CAUTION
• Should the brakes fail, use regenerative
z If this warning display comes on when the
braking to reduce your speed and keep pull-
engine oil level is proper, have your vehicle
ing the Electric parking brake switch.
checked at a certified Mitsubishi EV dealer.
(Refer to “Electric parking brake” on page
5-45)
When the operation mode of the power
Depress the brake pedal to illuminate the
NOTE
switch is put in ON, if the brake fluid is low,
stop lights to alert the vehicles behind you.
5
this warning is displayed.
z The oil pressure warning display does not
show the amount of oil. The oil level must be
The warning light in the instrument cluster
checked using the dipstick.
also illuminates.
2LO SUHVVXUH ZDUQLQJ GLVSOD\
N00558701130
CAUTION
&RPELQDWLRQ KHDGOLJKWV DQG
z
If this warning stays on and does not go out
while driving, there is a danger of ineffective
GLPPHU VZLWFK
braking. If this happens, park the vehicle in a
N00522502004
safe place, and contact a certified Mitsubishi
EV dealer.
If the engine oil pressure drops while the
+HDGOLJKWV
z
If the brake warning display, brake warning
Plug-in Hybrid EV System is running, the
light, and the Anti-lock braking system
warning display is displayed on the informa-
warning light are illuminated at the same
tion screen in the multi-information display.
NOTE
time, the braking force distribution function
will not operate, so the vehicle may be desta-
z Do not leave the headlights and other lights
bilized during sudden braking. Avoid sudden
on for a long period of time when the Plug-in
CAUTION
braking and high-speed driving. Park the
Hybrid EV System is not running. The 12 V
z If the vehicle is driven while the engine oil is
vehicle in a safe place, and contact a certified
starter battery will run down.
low, or the oil level is normal but the warn-
Mitsubishi EV dealer.
ing is displayed, the engine may overheat
z
The vehicle should be brought to a stop when
and damage may result.
brake performance has deteriorated.
z If the warning is displayed while the Plug-in
• Confirm that the vehicle slows down when
Hybrid EV System is running, park your
you press down on the brake pedal harder
vehicle in a safe place as soon as possible
than usual. In some cases, the brake pedal
and check the engine oil level.
may go all the way to the floor.
5-190
Features and controls
Combination headlights and dimmer switch
Headlights and other lights on
NOTE
Vehicles without “OFF” position
z When it rains, or when the vehicle has been
washed, the inside of the lens sometimes
NOTE
becomes foggy. This is the same as when
z Once the daytime running light come on,
window glass mists up on a humid day, and
they do not go out until the operation mode
does not indicate a problem. When the light
is changed to OFF or ACC.
is switched on, the heat will dry out the fog.
However, if water collects inside the light,
5
have it checked by a certified Mitsubishi EV
[When the Plug-in Hybrid EV System is not
dealer.
running, or when the Plug-in Hybrid EV Sys-
Rotate the switch to operate the lights.
tem is running but the parking brake is not
The combinations of switch operations and
released]
illuminated lights differ in accordance with
Vehicles with “OFF” position
the following conditions.
The Plug-in Hybrid EV System starts when
the lights are off.
[When the Plug-in Hybrid EV System is
started, and the parking brake is released]
OFF
All lights off
Headlights and other lights turn on
The daytime running lights illumi-
OFF
AUTO
and off automatically in accor-
nated
dance with outside light level.
The daytime running lights illumi-
Parking, tail, front and rear side-
nated (when it is light outside the
marker lights, license plate, instru-
vehicle)
AUTO
ment panel lights and downlight on
Headlights and other lights turn on
and off automatically in accor-
Headlights and other lights on
dance with outside light level.
The daytime running lights illumi-
nated
Tail, front and rear side-marker
lights, license plate, instrument
panel lights and downlight on
Features and controls
5-191
Combination headlights and dimmer switch
tion again after stopping the Plug-in Hybrid
NOTE
/LJKW DXWR FXWRXW IXQFWLRQ
EV System, the approximately
3-minute
z On vehicles with “OFF” position, the sensi-
KHDGOLJKWV DQG RWKHU OLJKWV
auto-cutout function described above will not
tivity of the automatic on/off control can be
N00532601681
work. The lights (the parking lights, tail lights
adjusted.
z If the operation mode is changed to OFF
and license plate lights) will stay on and will
For further information, please contact a cer-
or ACC and the driver’s door is opened
not turn off automatically.
tified Mitsubishi EV dealer.
with the combination headlights and dim-
On vehicles equipped with the Smartphone-
link Display Audio (SDA), screen operations
mer switch in the “
” or “
” position,
5
/(' KHDGOLJKW ZDUQLQJ OLJKW LI
can be used to make the adjustment.
the lights automatically turn off.
Refer to the separate owner’s manual for
z If the operation mode is changed to OFF
VR HTXLSSHG
details.
or ACC and the driver’s door is not
N00584500031
z Do not cover the sensor (A) for the automatic
opened with the combination headlights
This warning light will illuminate when there
on/off control by affixing a sticker or label to
and dimmer switch in the “
” or “
the windshield.
is a malfunction in the LED headlights.
position, the lights automatically turn off
after approximately 3 minutes.
NOTE
z The light auto-cutout function can be deacti-
vated.
See a certified Mitsubishi EV dealer for
details.
For vehicles equipped with the Smartphone-
z
If the lights do not turn on or off with the
link Display Audio (SDA), adjustments can
switch in the
“AUTO” position, manually
be made using screen operations. For further
operate the switch. Have the system checked
details, refer to the separate owner’s manual.
by a certified Mitsubishi EV dealer.
NOTE
:KHQ \RX ZDQW WR NHHS WKH OLJKWV
z
If the warning light illuminates, there may be
a malfunction in the unit. Contact a certified
RQ
Mitsubishi EV dealer to have the system
checked.
If the combination headlights and dimmer
switch is turned to the “
” or “
” posi-
5-192
Features and controls
Combination headlights and dimmer switch
+HDGOLJKW UHPLQGHU EX]]HU
$XWRPDWLF +LJK %HDP $+% LI
N00549801265
VR HTXLSSHG
If the driver’s door is opened with the opera-
N00591300073
tion mode is put in OFF or ACC, or if the
The Automatic High Beam (AHB) turns the
operation mode is changed to OFF while the
high beam light on or off automatically
lights are on, the tone will sound to remind
according to surrounding light conditions.
you to turn off the lights.
The sensor (A) detects
lights, such as the
5
lights of an oncoming
vehicle,
a
vehicle
In either case, the lights will turn off automat-
ahead or street lights.
ically and so will the tone. Or you can turn
the light switch to the “OFF” position (if so
equipped) or “AUTO” position to stop the
tone.
+HDGOLJKW IODVKHU
N00550001212
'LPPHU KLJK ORZ EHDP
You can flash the high beams by pulling the
lever gently toward you (2). The lights will
FKDQJH
go back to normal when you let go. While the
N00549901178
high beam is on, you will see a blue light on
To change the headlights from high beam to
the instrument panel.
low beam and vice versa, pull the turn signal
lever to
(1). Switch the headlights to low
NOTE
beam as a courtesy whenever there are
z You can flash the high beams by pulling the
oncoming vehicles, or when there is traffic
WARNING
lever toward you, even if the light switch is
moving ahead of you. An illuminated blue
z
'R QRW UHO\ VROHO\
RQ
WKH
$+%
$OZD\V
off.
light in the instrument cluster indicates when
REVHUYH VXUURXQGLQJ WUDIILF DQG OLJKW FRQ
z If you turn the lights off with the head lights
the headlights are on high beam.
GLWLRQV
,I QHFHVVDU\ PDQXDOO\ WXUQ WKH
set to high beam illumination, the headlights
KLJK EHDPV RQ RU RII
are automatically returned to their low-beam
5HIHU WR
³'LPPHU KLJK ORZ EHDP
setting when the light switch is next turned
FKDQJH ´ RQ SDJH
to the “
” position.
Features and controls
5-193
Combination headlights and dimmer switch
2. The AHB indicator will go off.
+RZ WR XVH WKH $+%
3. The AHB switch is pressed again, the
N00593600096
AHB will be activated.
1. Rotate the light switch to “
” position
or
“AUTO” position when the Plug-in
6ZLWFKLQJ WR KLJK EHDP
Hybrid EV System is running.
2. Press the AHB switch.
1. Pull the turn signal lever toward you.
The AHB is activated and the indicator is
2. The AHB indicator will go off and the
5
illuminated.
high beam indicator illuminates.
If the AHB switch is pressed again, the
3. The AHB switch is pressed again, the
AHB will be deactivated and AHB indica-
AHB will be activated.
tor will go off.
NOTE
$XWRPDWLF VZLWFKLQJ FRQGLWLRQV
z
If the headlights are on when the light switch
N00593700068
is in the “AUTO” position, the AHB works.
z
You can switch the headlight beams
The high beam headlights illuminate when all
(high/low) manually by operating the lever
of the following conditions are met:
even if the AHB is working.
Refer to “Dimmer (high/low beam change)”
z Your vehicle speed exceeds approxi-
on page 5-193.
mately 33 mph (53 km/h).
If the lever is operated manually, the AHB
z It is dark ahead of your vehicle.
indicator will go off and the AHB will be
z There are no vehicles in front or oncom-
deactivated.
ing vehicles, or none of their exterior
Refer to “Manual switching” on page 5-194.
lights are illuminating.
z
The AHB is not deactivated when you pull
the lever slightly (operation of the headlight
The low beam headlights illuminate when
flasher).
any of the following conditions occur:
z Your vehicle speed does not exceed
„ 0DQXDO VZLWFKLQJ
approximately 28 mph (45 km/h).
z It is bright ahead of your vehicle.
6ZLWFKLQJ WR ORZ EHDP
z An exterior light of a vehicle in front or
oncoming vehicle is illuminating.
1. Pull the turn signal lever toward you.
5-194
Features and controls
Combination headlights and dimmer switch
NOTE
NOTE
NOTE
z
The headlights may not be switched from
z
The AHB recognises environmental condi-
• When lights of the vehicle in front or head-
high beam to low beam under the following
tions by sensing a light source ahead of your
lights of an oncoming vehicle blend into the
circumstances.
vehicle. Therefore, you may feel like some-
other lights.
• A vehicle in front or oncoming vehicle is
thing is not quite right when the headlight
• The rear end of a vehicle in front (such as a
hindered by any object such as continuous
beams are switched automatically.
container truck) reflect a strong light.
bends, elevated median/island, traffic signs,
z
The AHB may not detect a light vehicle such
• Your vehicle's headlight is broken or dirty.
roadside trees.
as a bicycle.
• Your vehicle is inclined due to a flat tire or
5
• Your vehicle passes an oncoming vehicle
z
The AHB may not detect an ambient bright-
towing.
suddenly on a bend with poor visibility.
ness precisely. This causes the traffic to be
• The warning display appears.
• Another vehicle crosses ahead of your vehi-
dazzled by high beam or the low beam to be
(Refer to
“System problem warning” on
cle.
maintained. In such cases, you should switch
page 5-196.)
z
The headlights may remain at low beam (or
the headlight beams manually.
z
Observe the precautions below to maintain
be switched from high beam to low beam)
• In bad weather (heavy rain, fog, snow or
good usage conditions:
when a reflective object
(e.g. street light,
sandstorm).
• Do not attempt to disassemble the sensor.
traffic signal, noticeboard and signboard)
• The windshield is dirty or fogged up.
• Do not affix a sticker or label on the wind-
reflects light.
• The windshield is cracked or broken.
shield near the sensor.
z
Any of the following factors may influence
• The sensor is deformed or dirty.
• Avoid overload.
the headlight beam switching timing:
• A light, which is similar to the headlights or
• Do not modify your vehicle.
• How brightly the exterior lights of a vehicle
tail lights, is shining around your vehicle.
• When the windshield is replaced, use the
in front or oncoming vehicle illuminate.
• A vehicle in front or oncoming vehicle is
Mitsubishi Motors genuine parts.
• Movement or direction of a vehicle in front
driven without lights, the exterior lights are
or oncoming vehicle.
dirty or discoloured, or the direction of the
7R DGMXVW WKH VHQVLWLYLW\ RI WKH VHQVRU
• Only right or left exterior light of a vehicle
headlight beams is adjusted improperly.
in front or oncoming vehicle is illuminat-
• It becomes dark and bright suddenly and
The sensitivity of the sensor can be temporar-
ing.
continuously around your vehicle.
ily lowering in the following ways.
• A vehicle in front or oncoming vehicle is a
• Your vehicle is driven on uneven surfaces.
motorcycle.
• Your vehicle is driven on a winding road.
1. Park your vehicle in a safe place and the
• Road conditions (gradient, bends and road
• A reflective object such as a noticeboard or
operation mode of the power switch is put
surface).
a mirror reflects a light ahead of your vehi-
in OFF.
• The number of occupants and luggage load.
cle.
2. Press the AHB switch more than 15 times
within 5 seconds after operation mode is
turned on.
Features and controls
5-195
Combination headlights and dimmer switch
6\VWHP SUREOHP ZDUQLQJ
„ :LQGVKLHOG LV GLUW\
NOTE
N00593800069
z If the sensor or its surrounding area becomes
If a problem occurs with the system, the fol-
extremely high temperature when parking
If the AHB determines that its performance
the vehicle under a blazing sun, the “AHB
lowing warning display will appear to the
has been degraded, the warning display will
SERVICE REQUIRED” warning display
type of the problem.
appear.
may appear.
This can occur when
If the message remains even after the tem-
„ 7KH $+% GHDFWLYDWLRQ GXH WR IDXOW
perature of the sensor or its surrounding area
5
z Foreign objects, such as dirt, snow or ice,
has been in range, please contact a certified
adhere to the windshield of the sensor
If a failure is detected in the system, the fol-
Mitsubishi EV dealer.
portion.
lowing warning display will appear and the
z In adverse weather conditions, such as
AHB will automatically be turned off.
rain, snow, sand storms, etc.
If the warning display remains even after the
„ 6HQVRU LV WRR KRW RU FROG
z A front vehicle or an oncoming vehicle is
operation mode of the power switch is put in
If the AHB becomes temporarily unavailable
splashing water, snow or dirt.
OFF and then turned back to ON, please con-
due to the high or low temperature of the sen-
tact a certified Mitsubishi EV dealer.
sor, the following warning display will
When the sensor performance returns, the
appear.
AHB will resume operation.
[When the AHB is malfunctioning]
After the temperature of the sensor has been
If the warning display does not disappear
in range, the system will automatically return
after waiting for a while, there is a possibility
to operation.
that the sensor has a malfunction. Contact a
If the warning display does not disappear
certified Mitsubishi EV dealer for inspection
after waiting for a while, there is a possibility
of the sensor.
that the AHB has a malfunction. Contact a
[When the sensor is malfunctioning]
certified Mitsubishi EV dealer for inspection
of the system.
5-196
Features and controls
Combination headlights and dimmer switch
4. The headlights will come on in the low
:HOFRPH OLJKW
NOTE
beam setting for approximately 30 sec-
N00563201319
For details, consult a certified Mitsubishi EV
onds. After the headlights go off, the
dealer.
This function turns on the front side-marker
headlights can be turned on again in the
On vehicles equipped with the Smartphone-
and parking lights for approximately 30 sec-
low beam setting for approximately 30
link Display Audio (SDA), screen operations
onds after the UNLOCK button on the
seconds by pulling the turn signal lever
can be used to make the adjustment.
F.A.S.T.-Key is pressed when the combina-
toward you within 60 seconds of putting
Refer to the separate owner’s manual for
tion headlights and dimmer switch is in the
details.
the operation mode in OFF. To turn on the
“OFF” position (if so equipped) or “AUTO”
5
headlights again after 60 seconds of put-
position. The welcome light function will
ting the operation mode in OFF, repeat the
&RPLQJ KRPH OLJKW
operate only when it is dark outside the vehi-
process from step 1.
N00547301240
cle.
This function turns on the headlights in the
NOTE
low beam setting for approximately 30 sec-
NOTE
z
While the coming home light function is
onds after the operation mode is put in OFF.
z
While the welcome light function is operat-
operating, perform one of the following
ing, perform one of the following operations
operations to cancel the function.
1. Turn the combination headlights and dim-
to cancel the function.
mer switch to the “OFF” position (if so
• Pull the turn signal lever toward you.
• Press the LOCK button on the F.A.S.T.-
equipped) or “AUTO” position.
• Turn the combination headlights and dim-
Key.
2. Put the operation mode in OFF.
mer switch to the “
” or “
” position
• Turn the combination headlights and dim-
3. Within 60 seconds of putting the opera-
or put the operation mode in ON.
mer switch to the “
” or “
” position.
tion mode in OFF, pull the turn signal
• Put the operation mode in ON.
• Put the operation mode in ON.
lever toward you.
z
It is possible to modify functions as follows:
z
It is possible to modify functions as follows:
• The time that the headlights remain on can
• The headlights can be set to come on in the
be changed.
low beam setting.
• The coming home light function can be
• The welcome light function can be deacti-
deactivated.
vated.
For details, consult a certified Mitsubishi EV
dealer.
On vehicles equipped with the Smartphone-
link Display Audio (SDA), screen operations
can be used to make the adjustment.
Refer to separate owner’s manual for details.
Features and controls
5-197
Turn signal lever
7XUQ VLJQDO OHYHU
NOTE
+D]DUG ZDUQLQJ IODVKHU
N00522601620
z
A light in the instrument panel flashes to
VZLWFK
show when the front and rear turn signal
When changing lanes, or making a gradual
N00522701386
lights are working properly.
turn, hold the lever in the “lane change” posi-
If this light flashes faster than usual, check
tion (1). It will return to the neutral position
for a burned out turn signal light bulb or mal-
when you let go. Use the full position (2)
functioning connection in the signal.
when making a normal turn. The lever will
If the panel light does not come on when the
5
return to the neutral position when the turn is
lever is moved, check for a blown fuse or a
complete. There may be times when the lever
burned out bulb in the panel.
does not return to the neutral position. This
Have the system inspected by a certified
Mitsubishi EV dealer.
usually happens when the steering wheel is
z
It is possible to modify functions as follows:
turned only slightly. You can easily return the
• Deactivate the turn signal light
3-flash
lever by hand.
function for lane changes.
Also, when you move the lever to (1) slightly
• Adjust the time required to operate the
If you press the flasher switch, the front and
then release it, the turn signal lights and the
lever for the 3-flash function.
indicator light in the instrument cluster will
rear turn signals will flash intermittently, and
See a certified Mitsubishi EV dealer for
flash three times.
so will the hazard warning lights. This is an
details.
emergency warning system and should not be
For vehicles equipped with the Smartphone-
used when the vehicle is in motion, except for
link Display Audio (SDA), adjustments can
emergencies.
be made using screen operations. For further
If you need to leave your vehicle, the flashers
details, refer to the separate owner’s manual.
will keep working after the operation mode is
z
It is possible to change the tone of a sound-
ing buzzer as the turn signal lights flash.
put in OFF.
Refer to “Changing the turn-signal sound”
on page 5-158.
NOTE
z If the flashers are used for several hours, the
12 V starter battery will run down. This
could make it difficult or impossible to
restart your vehicle.
5-198
Features and controls















Content      ..     13      14      15      16     ..
